UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
mMirrors...............................75
NInside Mirror.........................75
NAutomatic Dimming MirrorÐ If Equipped....76
NOutside Mirrors.......................76
NExterior Mirrors Folding Feature...........77
NElectronic Power Mirrors Ð If Equipped......77
NElectric Rear Window Defroster And Heated
Sideview Mirrors Ð If Equipped...........78
NTrailer Towing Mirrors Ð If Equipped.......79mHands±Free Communication (UConnectŸ) Ð If
Equipped.............................79
NOperation............................81
NPhone Call Features....................85
NAdvanced Phone Connectivity.............87
NUConnectŸ System Features..............89
mSeats.................................91
N40-20-40 Front Seat.....................92
NReclining Seats........................93
3

NAdjustable Head Restraints...............93
NManual Rotary Lumbar Support
Adjustment Ð If Equipped...............94
NPower Seats Ð If Equipped...............95
NHeated Seats Ð If Equipped..............96
mTo Open And Close The Hood..............97
mLights................................99
NInterior Lights........................99
NBattery Saver........................100
NHeadlamp Delay Ð If Equipped..........101
NHeadlights, Parking Lights, Panel Lights.....101
NDaytime Running Lights (Canada And Fleet
Vehicles Only).......................102
NLights-On Reminder...................102NFog Lights Ð If Equipped...............102
NCargo Light.........................103
mMultifunction Control Lever...............103
NTurn Signals.........................103
NPassing Light........................104
NHigh Beam / Low Beam Select Switch......104
NWindshield Wipers....................105
NWindshield Washers...................106
mTilt Steering Column....................107
mDriver Adjustable Pedals Ð If Equipped......108
NAdjustment.........................108
mElectronic Speed Control Ð If Equipped......109
NTo Activate..........................109
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NTo Set At A Desired Speed...............110
NTo Deactivate........................110
NTo Resume Speed.....................110
NTo Vary The Speed Setting...............111
NTo Accelerate For Passing...............111
mOverhead ConsoleÐ If Equipped...........112
NCourtesy/Reading Lights................113
mOverhead Console With Compass/Temperature
Mini-Trip Computer Ð If Equipped..........113
NUS/M Button........................114
NReset Button.........................114
NGlobal Reset.........................115
NStep Button.........................115NAverage Fuel Economy (AVG ECO)........115
NDistance To Empty (DTE)...............115
NTrip Odometer (ODO)..................116
NElapsed Time (ET).....................116
NC/T Button.........................117
NAutomatic Compass Calibration...........117
NManual Compass Calibration.............118
NTo Put Into a Calibration Mode...........118
NOutside Temperature...................119
mGarage Door Opener Ð If Equipped.........120
NProgramming Homelink................121
NCanadian Programming/Gate Programming . . 123
NUsing Homelink......................124
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73
3

NErasing Homelink Buttons...............124
NReprogramming a Single Homelink Button . . . 125
NSecurity............................125
mElectrical Power Outlets..................126
mCigar Lighter And Ash Receiver............127
mCupholders...........................128
NFront Instrument Panel Cupholders Ð
Automatic Transmission Only............128
NRear Cupholder Ð Quad Cab Ð If
Equipped...........................128mStorage..............................129
NCenter Storage Compartment Ð If Equipped . . 129
NStorage And Seats Ð If Equipped..........130
mFold Flat Load Floor Ð If Equipped.........130
NFold Flat Load Floor Ð If Equipped........130
mPickup Box...........................133
mSlide-In Campers.......................135
NCamper Applications...................135
mEasy-Off Tailgate.......................135
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Mirror
The mirror should be adjusted to center on the view
through the rear window.
Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
3

Automatic Dimming MirrorÐ If Equipped
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn the feature
on or off by pressing the button at the base of the mirror.
A light in the button will indicate when the dimming
feature is activated.CAUTION!
To avoid damage to the mirror during cleaning,
never spray any cleaning solution directly onto the
mirror. Apply the solution onto a clean cloth and
wipe the mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic with a slight
overlap of the view obtained on the inside mirror.
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Vehicles and other objects seen in a right side convex
mirror will look smaller and farther away than they
really are. Relying too much on your right side
convex mirror could cause you to collide with an-
other vehicle or other object. Use your inside mirror
when judging the size or distance of a vehicle seen
in the right side convex mirror. Some vehicles will
not have a convex right side mirror.
Exterior Mirrors Folding Feature
All exterior mirrors are hinged and may be moved either
forward or rearward to resist damage. The hinges have
three detent positions; full forward, full rearward, and
normal.
Electronic Power Mirrors Ð If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
3

The controls for the power mirrors are located on the
driver's door trim panel.
Set the top switch to the left or right for the left or right
mirror, and set it to the center off position to preventaccidentally moving a mirror when you are finished
adjusting the mirror. To adjust a mirror, select left or right
with the top switch, and press one of the four arrows for
the direction you want the mirror to move.
Electric Rear Window Defroster and Heated
Sideview Mirrors Ð If Equipped
The Electric Rear Window Defroster and Heated
side view mirrors are activated by pressing the
heated grid button, located on the Climate Control panel,
with the ignition On. Turning Off the ignition will
deactivate the Electric Rear Window Defroster and
Heated side view mirrors feature. These features also
turn off after activation, when 15 minutes have elapsed.
To reactivate, simply press the button again.
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Trailer Towing Mirrors Ð If Equipped
These mirrors are designed with an adjustable mirror
head to provide a greater vision range when towing
extra-wide loads. To change position inboard or out-
board, the mirror head should be rotated (flipped Out or
In). A small blindspot mirror is integrated onto the main
mirror surface.
HANDS±FREE COMMUNICATION (UConnectŸ) Ð
IF EQUIPPED
UConnectŸ is a voice-activated, hands-free, in-vehicle
communications system. UConnectŸ; allows you to dial
your cellular phone using simple voice commands (e.g.,
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79
3

ªCallº or ªDialº). Your cellular phone's audio is trans-
mitted through your vehicle's stereo system; the system
will automatically mute your radio before receiving or
sending a call.
UConnectŸ allows you to transfer calls between the
system and your cellular phone as you enter or exit your
vehicle, and enables you to mute the system's micro-
phone for private conversations.
The UConnectŸ; phone book enables you to store up to
32 names and four numbers per name. This system is
driven through your BluetoothŸ Hands-Free Profile
cellular phone. UConnectŸ features BluetoothŸ technol-
ogy - the global standard that enables different electronic
devices to connect to each other without wires or a
docking station, so UConnectŸ works no matter where
you stow your cellular phone (be it your purse, pocket, or
briefcase). UConnectŸ allows up to seven cellularphones to be linked to the system, and it is available in
English, French, or Spanish formats (as equipped).
The rearview mirror contains the microphone for the
system and the control buttons that will enable you to
access the system. The diagram below shows the mirror
with the appropriate buttons. Individual button behavior
is discussed in the ªOperationº Section.
