DODGE RAM 2500 DIESEL 2007 3.G Owners Manual

•Off-road or desert operation.
•Extensive operation at high engine speeds (greater
than 2900 rpm) and loads (greater than 70% throttle).
NOTE: Most vehicles are operated under the conditions
listed for Schedule B.
NOTE: IfANY of these apply to you then change your
coolant every 101,250 miles (162 000 km) or 60 months,
whichever comes first and follow schedule “B” of the
 Maintenance Schedules section of this manual.
Second is Schedule “A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule B.
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•Check the engine oil level about 15 minutes after a
fully warmed engine is shut off. Checking the oil level
while the vehicle is on level ground will improve the
accuracy of the oil level reading. Add oil only when
the level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required. When refilling the washer fluid reservoir,
take some washer fluid and apply it to a cloth or towel
and wipe clean the wiper blades, this will help blade
performance.
MAINTENANCE SCHEDULES 451
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the batteries and clean and tighten the termi-
nals as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder, and transmission and transfer case (if
equipped), add as needed.
•Check Filter Minder™. Replace air cleaner filter
element if necessary.
•Check all lights and all other electrical items for correct
operation.
•Drain water from the fuel filter. At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the U-Joints ( if equipped) and front suspen-
sion components.
•Check the automatic transmission fluid level.
•Check the manual transmission fluid level.
•Check the coolant level, hoses, and clamps.
•Lubricate outer tie rod ends.
•Lubricate Front Drive Shaft Fittin
452 MAINTENANCE SCHEDULES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “B”
Follow schedule “B” if you usually operate your vehicle
under one or more of the following conditions.
•Frequent short trips where the engine does not achieve
full operating temperature (operating temperature de-
fined as 190° F (66 ° C ) coolant temperature).
•Extensive engine idling (over 10 minutes per hour of
operation) at ambient temperatures less than 32° F (0°
C).
•Driving in dusty conditions.
•Frequent trailer towing.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert operation.
•Extensive operation at high engine speeds (greater
than 2900 rpm) and loads (greater than 70% throttle).
NOTE: IfANY of these apply to you then change your
coolant every 101,250 miles (162 000 km) or 60 months,
whichever comes first and follow schedule “B” of the
 Maintenance Schedules section of this manual.
SCHEDULE “B” 453
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 3,750 7,500 11,250 15,000 18,750
(Kilometers) (6 000) (12 000) (18 000) (24 000) (30 000)
Change engine oil and engine oil filter. X X
Lubricate Front Drive Shaft Fitting (2500/3500,
4X4). X X XXX
Rotate tires. X X
Check spare tire for proper pressure and correct
stowage. XX
Lubricate outer tie rod ends 2500/3500 (4X4) mod-
els. XX
Replace fuel filter element. X
Change rear axle fluid. X
Change front axle fluid (4X4). X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
454 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 22,500 26,250 30,000 33,750 37,500
(Kilometers) (36 000) (42 000) (48 000) (54 000) (60 000)
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/3500,
4X4). X X XXX
Rotate tires. X X X
Check spare tire for proper pressure and correct
stowage. XXX
Lubricate outer tie rod ends 2500/3500 (4X4) mod-
els. XXX
Inspect drive belt, replace as required. X
Replace fuel filter element. X
Change rear axle fluid. X
Change front axle fluid (4X4). X
Check transfer case fluid level (4X4). X
Drain and refill automatic transmission fluid. Re-
place filter and adjust bands (48RE only). X
SCHEDULE “B” 455
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 41,250 45,000 48,750 52,500 56,250
(Kilometers) (66 000) (72 000) (78 000) (84 000) (90 000)
Change engine oil and engine oil filter. X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4)
models. X X XXX
Rotate tires. X X
Check spare tire for proper pressure and correct
stowage. XX
Lubricate outer tie rod ends 2500/3500 (4X4). X X
Inspect drive belt, replace as required. X
Replace fuel filter element. X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Change rear axle fluid. X
Change front axle fluid (4X4). X
456 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 60,000 63,750 67,500 71,250 75,000
(Kilometers) (96 000) (102 000) (108 000) (114 000) (120 000)
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/3500,
4X4). X X XXX
Flush and replace engine coolant at 60 months, if
not replaced at 102,000 miles (163 000 km). X
Rotate tires. X X X
Check spare tire for proper pressure and correct
stowage. XXX
Lubricate outer tie rod ends 2500/3500 (4X4) mod-
els. XXX
Inspect drive belt, replace as required. X
Replace fuel filter element. X X
Inspect front wheel bearings. X
Change rear axle fluid. X X
Change front axle fluid (4X4). X X
SCHEDULE “B” 457
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 60,000 63,750 67,500 71,250 75,000
(Kilometers) (96 000) (102 000) (108 000) (114 000) (120 000)
Change 6-spd manual transmission (G-56) fluid
2500/3500. X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Drain and refill transfer case fluid (4X4). X
Drain and refill automatic transmission fluid and
change main sump filter (545 RFE only). X
Drain and refill automatic transmission fluid. Re-
place filter and adjust bands (48RE only). X
458 SCHEDULE “B”
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 78,750 82,500 86,250 90,000 93,750
(Kilometers) (126 000) (132 000) (138 000) (144 000) (150 000)
Change engine oil and engine oil filter. X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4). X X X X X
Rotate tires. X X
Check spare tire for proper pressure and correct stowage. X X
Lubricate outer tie rod ends 2500/3500 (4X4) models. X X
Inspect drive belt, replace as required. X
Change rear axle fluid. X
Change front axle fluid (4X4). X
Check transfer case fluid level (4X4). X
Replace fuel filter element. X
Inspect front wheel bearings. X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Drain and refill automatic transmission fluid. Replace filter
and adjust bands (48RE only). X
SCHEDULE “B” 459
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 97,500 100,000 101,250 105,000 108,750 112,500
(Kilometers) (156 000) (160 000) (162 000) (168 000) (174 000) (180 000)
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4). X X XXXX
Flush and replace engine coolant, if not replaced at
60 months. X
Rotate tires. X X X
Check spare tire for proper pressure and correct
stowage. XXX
Lubricate outer tie rod ends 2500/3500 (4X4) models. X X X
Flush and replace engine coolant. X
Inspect drive belt, replace as required. X
Replace fuel filter element. X
Change rear axle fluid. X
Change front axle fluid (4X4). X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
460 SCHEDULE “B”
