DODGE RAM 2500 DIESEL 2007 3.G Owners Manual

Miles 116,250 120,000 123,750 127,500 131,250 135,000
(Kilometers) (186 000) (192 000) (198 000) (204 000) (210 000) (216 000)
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/
3500, 4X4). X X XXXX
Rotate tires. X X X
Check spare tire for proper pressure and cor-
rect stowage. XXX
Flush and replace engine coolant at 120
months, if not replaced at 102,000 miles (163
000 km). X
Lubricate outer tie rod ends 2500/3500 (4X4)
models. XXX
Clean engine air filter assembly. X
Adjust valve lash clearance. X
Inspect drive belts, replace as required. X
Drain and refill transfer case fluid (4X4). X
Replace fuel filter element. X X
SCHEDULE “B” 461
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 116,250 120,000 123,750 127,500 131,250 135,000
(Kilometers) (186 000) (192 000) (198 000) (204 000) (210 000) (216 000)
Inspect front wheel bearings. X
Change rear axle fluid. X X
Change front axle fluid (4X4). X X
Change 6-spd manual transmission (G-56)
fluid 2500/3500. X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Drain and refill automatic transmission fluid
and change main sump and spin-on cooler
return filter (if equipped) (545 RFE only). X
Drain and refill automatic transmission fluid.
Replace filter and adjust bands (48RE only). X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
462 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “A”
Miles 7,500 15,000 22,500 30,000 37,500
(Kilometers) (12 000) (24 000) (36 000) (48 000) (60 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct stow-
age. X X XXX
Lubricate outer tie rod ends 2500/3500 (4X4) models. X X X X X
Check transfer case fluid level (4X4). X
Replace fuel filter element. X X
Inspect drive belts, replace as necessary. X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Inspect front wheel bearings. X
SCHEDULE “A” 463
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (96 000) (108 000) (120 000)
[Months] [36] [42] [48] [54] [60]
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct stowage. X X X X X
Lubricate outer tie rod ends 2500/3500 (4X4) models. X X X X X
Check transfer case fluid level. X
Flush and replace engine coolant at 60 months, if not re-
placed at 102,000 miles (163 000 km). X
Inspect drive belts, replace as necessary. X X
Replace fuel filter element. X X X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Inspect front wheel bearings. X
Replace fuel filter element. X
464 SCHEDULE “A”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 82,500 90,000 97,500 100,000 105,000
(Kilometers) (132 000) (144 000) (156 000) (160 000) (168 000)
[Months] [66] [72] [78] [84]
Change engine oil and engine oil filter. X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct stowage. X X X X X
Lubricate outer tie rod ends 2500/3500 (4X4) models. X X X X X
Flush and replace engine coolant, if not replaced at 60 mos. X
Check transfer case fluid level (4X4). X
Inspect drive belt, replace as required. X
Replace fuel filter element. X X
Inspect front wheel bearings. X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Drain and refill automatic transmission fluid. Replace filter
and adjust bands (48 RE only). X
SCHEDULE “A” 465
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/
3500, 4X4). X X XXXX
Rotate tires. X X X X X X
Check spare tire for proper pressure and cor-
rect stowage. X X XXXX
Lubricate outer tie rod ends 2500/3500 (4X4)
models. X X XXXX
Flush and replace engine coolant at 120
months, if not replaced at 100,000 miles (160
000 km). X
Inspect drive belt, replace as required. X X
Drain and refill transfer case fluid (4X4). X
Check tranfer case fluid level (4X4). X
Replace fuel filter element. X X X
466 SCHEDULE “A”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Inspect front wheel bearings. X X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Adjust valve lash clearance. X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
SCHEDULE “A” 467
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service
For Your Vehicle .......................470
▫ Prepare For The Appointment ............470
▫ Prepare A List ........................470
▫ Be Reasonable With Requests .............470

If You Need Assistance ...................470

Warranty Information (U.S. Vehicles Only) .....473

Mopar Parts.........................473

Reporting Safety Defects ..................473
▫ In Canada ..........................473

Publication Order Forms ..................474

Department Of Transportation Uniform
Tire Quality Grades .....................475
▫ Treadwear ..........................475
▫ Traction Grades ......................475
▫ Temperature Grades ...................476
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
470 IF YOU NEED CONSUMER ASSISTANCE
