DODGE RAM SRT-10 2006 Service Repair Manual

ELEMENT-AIR CLEANER
REMOVAL
1. Unclip the air cleaner cove (1) and release the top
of the air cleaner housing assembly.
2. Pull the air filter element up and out of the air
cleaner housing assembly.

INSTALLATION
1. Install the air filter element (2) into the housing
assembly (3).
2. Position the alignment tabs (3) of the housing
cover (1) into the lower housing assuring the posi-
tion of the interlocking tabs.
3. Clip and snap the air cleaner housing cover retain-
ers (2).

HOUSING-AIR CLEANER
REMOVAL
1. Disconnect the air inlet duct (1) and crankcase
ventilation hose from the air cleaner housing (2).
2. Remove the air cleaner housing fastener (6) on the
front core support.
3. Lift up and remove the housing off of the guide
pins (2) and grommets.

INSTALLATION
1. Position the housing (3) over the guide pins (2) and
pushdowntoseat.
2. Install and tighten the housing fasteners (6).
3. Connect the throttle body air inlet duct (1) and
crank case ventilation hose to the air cleaner hous-
ing cover (2).

MOUNTS-ENGINE
REMOVAL
NOTE: This procedure covers either the left or
right engine mount.
1. Raise vehicle on hoist.
2. Support oil pan with suitable jack.
3. Loosen engine mount (1) to block bolts or.
4. Loosen engine mount (2) to frame nut
5. Raise engine with jack. Remove engine mount to
block bolts.
6. Remove engine mount or.

INSTALLATION
NOTE: This procedure covers either the left or
right engine mount.
1. With engine raised, position engine mount (2) onto
engine and install bolts. Tighten bolts to 41 Nꞏm
(30 ft. lbs.) or.
2. Lower engine with jack while guiding engine mount
(1) studs into frame slots.
3. Install engine mount to frame nut. Tighten nut to
102 Nꞏm (75 ft. lbs.) or.
4. Remove jack.
5. Lower vehicle.

MANIFOLD-INTAKE
DIAGNOSIS AND TESTING
INTAKE MANIFOLD LEAKS
An intake manifold air leak is characterized by lower than normal manifoldvacuum, rough idle, or engine misfire.
WARNING: USE EXTREME CAUTION WHEN THE ENGINE IS OPERATING. DO NOT STAND IN ADIRECT LINE
WITH THE FAN. DO NOT PUT YOUR HANDS NEAR THE PULLEYS, BELT OR THE FAN. DO NOT WEAR
LOOSE CLOTHING.
1. Start the engine.
2. Spray a small stream of water (Spray Bottle) at the suspected leak area.
3. If engine RPM’S change, the area of the suspected leak has been found.
4. Repair as required.
REMOVAL
NOTE: Care must be taken to protect the intake
manifold powder coating from scrapes and abra-
sions.
1. Perform the fuel system pressure release proce-
dure,before attempting any repairs.(Refer to 14
- FUEL SYSTEM/FUEL DELIVERY - STANDARD
PROCEDURE - FUEL SYSTEM PRESSURE
RELEASE PROCEDURE).
2. Disconnect negative battery cable.
3. Disconnect throttle body air inlet duct, IAT sensor,
CCV hose and remove air cleaner cover (Refer to
9 - ENGINE/AIR INTAKE SYSTEM - REMOVAL).
4. Disconnect throttle cable (2) from throttle cam.
Remove throttle cable from bracket and set aside.
5. Disconnect speed control cable from throttle cam
and set aside.

6. Disconnect brake booster vacuum hose from the
intake manifold and set aside.
WARNING: WRAP A SHOP TOWEL AROUND FUEL
LINE TO CATCH ANY GASOLINE SPILLAGE.
7. Disconnect fuel line quick connect fitting from fuel
rail (Refer to 14 - FUEL SYSTEM/FUEL DELIV-
ERY/QUICK CONNECT FITTING - STANDARD
PROCEDURE).
8. Disconnect the following electrical connectors:
Left cylinder head fuel injectors
MAP sensor
Engine Coolant Temperature (ECT) Sensor
Idle Speed Control Sensor (ISC)
Throttle Position Sensor (TPS) (1)
Right cylinder head fuel injectors
9. Carefully separate the fuel injector harness push
pins from the intake manifold.

10. Disconnect the purge solenoid hose from beneath
thethrottlebody.
11. Disconnect CCV hoses from left and right cylinder
head covers.
CAUTION: Care must be taken when removing the
No. nine cylinder inside intake manifold bolt. Fail-
ure to do so may result in personal injury or pos-
sible damage.
12. Remove the intake manifold bolts and intake man-
ifold (2).
13. Cover the intake manifold openings with a suit-
able cover when servicing to prevent any debris
from entering cylinder heads.
INSPECTION
1. Inspect manifold for cracks or other damage.
2. Inspect manifold sealing surfaces for damage.

INSTALLATION
CAUTION: When cleaning the intake manifold and
cylinder head mating surfaces, do not use a metal
scraper because the surfaces could be cut or
ground. Instead, use a wooden or plastic scraper.
NOTE: Care must be taken to protect the intake
manifold powder coat from possible scrapes and
abrasions.
1. Clean gasket surfaces and remove covering from
intake manifold openings.
2. Carefully install the intake manifold gaskets (2) and
alignment pins (1).
3. Set the intake manifold in position on the engine.
Install intake manifold bolts and tighten initially to 1
Nꞏm (10 in. lbs.). Tighten bolts starting at the center
and working outward to 11 Nꞏm (95 in. lbs.).
4. Connect CCV hoses to left and right cylinder head
covers.
5. Connect fuel line to fuel rail. Pull backward on the
quick connect fitting to ensure complete insertion.
6. Connect the brake booster vacuum hose.
