Remove the extension shaft bearing (2) from
the extension shaft (1).
9. UsingaSlideHammerC-3752(2),removethe4X4
stub shaft (1).
10. Remove the 4X4 stub shaft (1) from the transmis-
sion output shaft. Inspect the cir-clip on the shaft
for damage and replace the clip if necessary.

NOTE: The speed sensor bolts have a sealing
patch applied from the factory. Separate these
bolts for reuse.
11. Remove the input speed sensor bolt.
NOTE: The speed sensor bolts have a sealing
patch applied from the factory. Separate these
bolts for reuse.
12. Remove the output speed sensor bolt.
13. Remove the input and output (2) speed sensors.
Identify the speed sensors for re-installation since
they are not interchangeable.

NOTE: One of the oil pan bolts has a sealing patch
applied from the factory. Separate this bolt for
reuse.
14. Remove the transmission oil pan bolts (2).
15. Removethetransmissionoilpan(1).
16. Remove the transmission oil filter screws (2).

17. Remove transmission oil filter (1).
18. Remove the oil filter o-ring (2) from the valve
body.
19. Remove valve body-to-case bolts (1).

CAUTION: Do not handle the valve body by the
manual shaft. Damage could result.
20. Remove valve body (1) from transmission.
21. Remove underdrive and overdrive accumulators
(1, 2).
22. Remove the low/reverse accumulator snap ring
(1).

23. Remove the low/reverse accumulator plug (2).
24. Remove low/reverse accumulator piston (1) using
suitable pliers.
25. Remove piston (1) and springs (2).

26. Remove and discard the oil pump-to-case bolts
(1). The oil pump bolts are not to be reused.
27. Remove oil pump using Slide Hammers C-3752
(2).
28. Remove oil pump while pushing in on input shaft
(1).

29. Remove oil pump gasket (2).
CAUTION: By-pass valve must be replaced if a
transmission failure has occured.
30. Remove the cooler by-pass valve (1).
31. Remove the #1 caged needle bearing (1).

32. Remove the input clutch assembly (1).
33. Removethe#4thrustplate(2).
34. Remove the front sun gear assembly (1) and #4
thrust washer (if still in place).

35. Remove the front carrier/rear annulus (2) and #6
needle bearing (1).
36. Remove the rear sun gear (2) and #7 needle
bearing (1).
NOTE: The number seven needle bearing (1) has
three antireversal tabs and is common with the
number five and number two position. The orien-
tation should allow the bearing to seat flat against
the rear sun gear. A small amount of petrolatum
can be used to hold the bearing to the rear sun
gear.
