40 THINGS TO KNOW BEFORE STARTING YOUR VEH ICLEBelt Height AdjustmentBelt height adjustment button 4
Do not adjust the belt height while the vehicle is
moving.
To lower:
Press the button and move the belt sash guide down.
To raise:
Move the belt sash guide up.
The shoulder strap must pass between the neck and the
shoulder.
A IRBA G A ND BELT TENSIONERSThe vehicle is equipped with an airbag for the driver
and the front seat passenger as well as belt tensioners
for the driver and the front passenger. The system is
known as a Supplemental Restraint System (SRS). It
has been designed to work together with the seat belt
and to supplement.SRS Malfunction Indicator LampWhen the key is in position 2 in the ignition lock, the
malfunction indicator lamp1 will light up in the
instrument cluster for about 4 seconds as a function
check.
WARNING!
Do not put anything on or around the front airbag
covers or attempt to manually open them. You
may damage the airbags and you could be injured
because the airbags are not there to protect you.
These protective covers for the airbag cushions are
designed to open only when the airbags are inflat-
ing.
Freightliner-all.book Pag e 40 Monday , December 1, 2003 2:54 PM

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
3
CONTENTS
Mirror Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 53Interior Mirror (Optional) . . . . . . . . . . . . . . . . . . 53Electrically Adjustable Exterior Mirror
(Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Seat Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54Driver’s and Front Passenger’s Seat . . . . . . . . . 54Lumbar Support . . . . . . . . . . . . . . . . . . . . . . . . . . 55Armrest (Optional) . . . . . . . . . . . . . . . . . . . . . . . . 56Head Restraint . . . . . . . . . . . . . . . . . . . . . . . . . . . 56Folding Seat at Partition (Optional) . . . . . . . . . 57

Seat Heater (Optional) . . . . . . . . . . . . . . . . . . . . . . 57

Rear Seat Bench Removal and Installation . . . . . 58Retrofitting Seat Mounting Cups . . . . . . . . . . . . 59

Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Headlamp Range Control . . . . . . . . . . . . . . . . . . . . 62

Fog Lamp Switch (Optional) . . . . . . . . . . . . . . . . . 62

Interior Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63Interior Lamps in the Driver and Rear-Seat
Passenger Area/Cargo Area . . . . . . . . . . . . . . . . 63Interior Lamps with Interior Sensor Protection
(Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63Interior Lighting with Reading Lamp, Front
Passenger Space Only . . . . . . . . . . . . . . . . . . . . . 64Interior Cargo Area Lighting (Optional) . . . . . 65

Multifunction Switch . . . . . . . . . . . . . . . . . . . . . . . . 66

Window Operation . . . . . . . . . . . . . . . . . . . . . . . . . 68Mechanical Window Operation . . . . . . . . . . . . . 68Electric Window Operation (Optional) . . . . . . . 68

Windshield Wiper Switch . . . . . . . . . . . . . . . . . . . . 69Windshield wipers with rain sensor
(Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Freightliner-all.book Pag e 51 Monday , December 1, 2003 2:54 PM

54 UNDERSTANDING THE FEATURES OF YOUR VEHICLESEAT ADJUSTMENT
Driver’s and Front Passenger’s Seat
WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat
could cause you to lose control. The seat belt
might not be properly adjusted and you could be
injured. Adjust the seat only while the vehicle is
parked.
WARNING!
Do not ride with the seat back reclined so that the
shoulder belt is no longer resting against your
chest. In a collision, you could slide under the seat
belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
WARNING!
The rear area of the vehicle should not be used as
a play area by children when the vehicle is in mo-
tion. They could be seriously injured in an acci-
dent. Children should be seated and using the
proper restraint system.
WARNING!
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these area are more likely to be seriously
injured or killed.
Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.
Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Freightliner-all.book Pag e 54 Monday , December 1, 2003 2:54 PM

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55
3
Comfortseat (Optional)
Seat adjustment, fore/aft (1)
