headlamp DODGE SPRINTER 2005 1.G User Guide

MAINTAINING YOUR VEHICLE 249
7
Side and Parking Lamps
1. Pull out the bulb holder with the bulb.
2. Replace the bulb.
3. Insert the bulb holder.
4. Secure the housing cap. High Beam Headlamp
1. Unplug the cable connector from the bulb.
2. Press the retaining spring towards the headlamps
and outwards (direction of arrow).
3. Remove the bulb.
4. Insert the new bulb so that the retaining lugs are fed into the recesses in the reflector section of the bulb holder.5. Clip in the retaining springs.
6. Press on the cable connector.
7. Secure the housing cap.

266 MAINTENANCE SCHEDULES
M A I
N T
E
N A
N
C E
S
C
H
E
D
U L
E
S8
MAINTENANCE - WITH ASSYST MAINTENANCE
COMPUTERASSYST provides you with information on the best
possible timing for maintenance work.
When the next maintenance service is due, this will be
indicated in the multi-function display with the
symbol
9 Oil service and fuel filter replacement
9 Maintenance service - displayed in km/miles
or days.
9
If the display shows the number of days, the symbol
È will also appear in the multi-function display.
You should have the maintenance performed within
the stated period/distance.
The service indicator will be reset by your Sprinter
Dealer after an oil service and/or maintenance service
has been performed.
REGULAR CHECK-UPSTo maintain the safe operation of your vehicle, it is
recommended that you perform the following tasks on
a regular basis (i.e., weekly or whenever the vehicle is
refueled). Check:
 Engine oil level
 Brake system, clutch mechanism – fluid level
 Battery – acid level
 Windshield washer system and headlamp cleaning
system – fluid level
 Mechanical assemblies (e. g. ,engine, transmission, etc.) – check for leaks
 Condition of tires and tire pressures
 All exterior lights

268 MAINTENANCE SCHEDULES
M A I
N T
E
N A
N
C E
S
C
H
E
D
U L
E
S8
SCOPE OF WORK FOR MAINTENANCE SERVICE
Oil ServiceOil change
Engine:
Oil change and filter replacement
Check fluid levels of the following system, refill as
necessary.
If fluid is lost, trace and eliminate cause – as a separate
order.
Power-assisted steering
Lubrication work:
Trailer tow hitch (original equipment)
Maintenance
ASSYST maintenance computer reset Function check
Signalling system,
warning and indicator lamps
Headlamps, exterior lighting
Windscreen wipers,
windscreen washer system
Check for leaks and damage.
Check for abrasion points and ensure that
lines are correctly routed!
All assemblies:
Engine, transmission, transfer case, front axle, rear
axle, steering, power steering pump
All lines and hoses, sensor cables
Rubber boots on front axle drive shafts,
rubber boots on front axle suspension ball joints, shock
absorbers

INDEX 279
10
Engine Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Headlamps, Taillamps, Turn Signal Lenses . . . . 234
Vehicle Washing . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Care of vehicle
Paintwork, painted body components . . . . . . . . 233
Power washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Tar stains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Catalytic Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Central Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Central Locking Switch. . . . . . . . . . . . . . . . . . . . . . . . . 17 Locking and Unlocking . . . . . . . . . . . . . . . . . . . . . . 19
Locking Status Display . . . . . . . . . . . . . . . . . . . . . . 18
To Program the Automatic Lock Feature . . . . . . . 19
Chains, Snow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Changing a Bulb
Additional Brake Lamp . . . . . . . . . . . . . . . . . . . . . 252
Exit Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Front Lamp Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Interior Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Interior Lighting with Interior Sensor Protection 255 License Plate Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 252
Reading Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Side-Marker Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 253
Side-Mounted Turn Signal . . . . . . . . . . . . . . . . . . 253
Taillamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Changing the Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Checking Coolant Level . . . . . . . . . . . . . . . . . . . . . . . 224
Checking Weights of Vehicle and Trailer. . . . . . . . . 188
Cigar Lighter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Cleaning Cup Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Hard Plastic Trim Items . . . . . . . . . . . . . . . . . . . . . 237
Instrument Cluster . . . . . . . . . . . . . . . . . . . . . . . . . 236
Light Alloy Wheels . . . . . . . . . . . . . . . . . . . . . . . . . 236
Plastic and Rubber Parts . . . . . . . . . . . . . . . . . . . . 238
Seat Belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Steering Wheel and Gear Selector Lever . . . . . . . 236
Upholstery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Wiper Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
Climate Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

282 INDEXHeadlamp Range Control. . . . . . . . . . . . . . . . . . . . . . . 68
Headlamps, taillamps, turn signal lenses . . . . . . . . 234
Heated Rear Window . . . . . . . . . . . . . . . . . . . . . . . . . 121
Heater, Seat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116, 118
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Hydroplaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175IIgnitionLock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Starter Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Indicator Lamp Symbols . . . . . . . . . . . . . . . . . . . . . . 108
Inhalation of Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . 54
Installing a Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Instrument and Display Lighting . . . . . . . . . . . . . . . . 97
Instrument Cluster Battery Charge Indicator Lamp . . . . . . . . . . . . . . 104
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Coolant Level Indicator Lamp . . . . . . . . . . . . . . . 106
Coolant Temperature Gauge. . . . . . . . . . . . . . . . . 101
Engine Control Unit Indicator Lamp . . . . . . . . . . 107 Engine Oil Level Indicator Lamp . . . . . . . . . . . . . 105
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Trip Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Water in Fuel Indicator Lamp . . . . . . . . . . . . . . . . 104
Instrument Cluster and Indicator Lamps. . . . . . . . . . 91
Instruments and Controls . . . . . . . . . . . . . . . . . . . . . . . 89
Interior Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 Cargo Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Driver and Rear-Seat Passenger/Cargo Area. . . . 69
Interior Sensor Protection . . . . . . . . . . . . . . . . . . . . 69
Reading Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Intervals, Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 265
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Intrument Cluster Fuel Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
JJack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Jump Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209LLamps Acceleration Skid Control . . . . . . . . . . . . . . . . . . . 164
