150 STARTING AND OPERATING
Gear Selector Lever Position
The current gear selector lever position (1) is indicated
in the gear range indicator display. The automatic gear
shifting process can be adapted to specific operating
conditions using the gear selector lever.vPark Position
The park position is to be used when parking the
vehicle. Engage only with the vehicle stopped.
The park position is not intended to serve as a
brake when the vehicle is parked. Rather, the
driver should always use the parking brake in
addition to placing the gear selector lever in
park position to secure the vehicle.
NOTE: With a malfunction in the vehicle’s electrical
system the gear selector lever could remain locked in
position "P". To unlock the gear selector lever
manually, refer to "Transmission Gear Selector Lever,
Manually Unlocking".
t Reverse Gear
Shift to reverse gear only with the vehicle
stopped.
s Neutral
No power is transmitted from the engine to the
drive axle. When the brakes are released, the
vehicle can be moved freely (pushed or towed).
Do not engage "N" while driving as you may
otherwise lose control of the vehicle.

STARTING AND OPERATING 151
5
NOTE: Coasting the vehicle, or driving with gear
selector lever in "N" can result in transmission damage
that is not covered by the Sprinter Warranty.
wThe transmission automatically upshifts through
5th gear. Position "D" provides optimum driving
characteristics under all normal operating
conditions.
Gear Selection for Special Circumstances
The transmission gear ranges for special circumstances can
be selected by pushing the gear selector lever to the right or
the left with the gear selector lever in position "D".
The gear range currently selected is indicated in the
instrument cluster display.
Briefly press gear selector lever in the ç direction:
The transmission downshifts, one gear range at a time,
in the order "4", "3", "2", "1".
Press and hold gear selector lever in the ç direction:
The transmission will shift to a gear range which
favorably accelerates or decelerates the vehicle. This
way downshiftings can be caused.Briefly press gear selector lever in the æ direction:
The transmission will shift from the current gear range
to the next higher gear range. If the transmission is
already in gear range "D", an additional upshift of one
gear is not possible.
Press and hold gear selector lever in the æ direction:
The transmission will shift from the current gear range
directly to gear range "D".
NOTE: With transmission in gear range "D", "4" or "3",
upshifting from 1st to 2nd to 3rd gear is delayed
depending on vehicle speed and engine temperature.
This allows the catalytic converter to heat up more
quickly to operating temperatures.
During the brief warm-up period this delayed upshift
and increased engine noise might be perceived as a
malfunction. However, neither the engine nor
WARNING!
On slippery road surfaces, never downshift in order
to slow the vehicle down. This could result in drive
wheel slip and reduced vehicle control. Your vehi-
cle’s ABS will not prevent this type of loss of control.

156 STARTING AND OPERATING
For all sensors, the minimum distance between sensor
and obstacle is 12 in (30 cm).
In the event of a malfunction, a continuous warning
signal sounds for approximately three seconds when
the vehicle is reversing
NOTE: Distance display
 "in" in USA only
 "cm" in Canada onlyLOADING THE VEHICLE
WARNING!
Do not overload the tires by exceeding the specified
vehicle capacity weight (as indicated by the label on
the base of the driver’s seat). Overloading the tires
can overheat them, possibly causing a blowout,
which could cause an accident and personal injury.
In addition, braking and stopping distances can be
significantly longer if the vehicle is overloaded.
WARNING!
Always close the sliding and rear doors when
driving.
Otherwise exhaust fumes could enter the vehicle
interior and poison you.

306 MAINTENANCE SCHEDULESM
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
8
MAINTENANCE - WITH ASSYST MAINTENANCE
COMPUTER
ASSYST provides you with information on the best
possible timing for maintenance work.
When the next maintenance service is due, this will be
indicated in the multi-function display with the
symbol
9 Oil service and fuel filter replacement
9 Maintenance service - displayed in km/miles
or days.
9
If the display shows the number of days, the symbol
È will also appear in the multi-function display.
You should have the maintenance performed within
the stated period/distance.
The service indicator will be reset by your Sprinter
Dealer after an oil service and/or maintenance service
has been performed.REGULAR CHECK-UPS
To maintain the safe operation of your vehicle, it is
recommended that you perform the following tasks on
a regular basis (i.e., weekly or whenever the vehicle is
refueled). Check:
 Engine oil level
 Brake system, clutch mechanism – fluid level
 Battery – acid level
 Windshield washer system and headlamp cleaning
system – fluid level
 Mechanical assemblies (e. g. ,engine, transmission,
etc.) – check for leaks
 Condition of tires and tire pressures
 All exterior lights

INDEX 319
10
Care of Vehicle
Engine Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Headlamps, Taillamps, Turn Signal Lenses . . . . 273
Vehicle Washing . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Care of vehicle
Paintwork, painted body components . . . . . . . . 272
Power washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
Tar stains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Catalytic Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Central Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Central Locking Switch. . . . . . . . . . . . . . . . . . . . . . . . . 17
Locking and Unlocking . . . . . . . . . . . . . . . . . . . . . . 19
Locking Status Display . . . . . . . . . . . . . . . . . . . . . . 18
To Program the Automatic Lock Feature . . . . . . . 19
Changing a Bulb
Additional Brake Lamp . . . . . . . . . . . . . . . . . . . . . 291
Exit Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
Front Lamp Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Interior Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Interior Lighting with Interior Sensor
Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294License Plate Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 291
Reading Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294
Side-Marker Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 292
Side-Mounted Turn Signal . . . . . . . . . . . . . . . . . . 292
Taillamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
Changing the Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Checking Coolant Level . . . . . . . . . . . . . . . . . . . . . . . 263
Checking Weights of Vehicle and Trailer. . . . . . . . . 224
Cigar Lighter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Cleaning
Cup Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Hard Plastic Trim Items . . . . . . . . . . . . . . . . . . . . . 276
Instrument Cluster . . . . . . . . . . . . . . . . . . . . . . . . . 275
Light Alloy Wheels . . . . . . . . . . . . . . . . . . . . . . . . . 275
Plastic and Rubber Parts . . . . . . . . . . . . . . . . . . . . 276
Seat Belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Steering Wheel and Gear Selector Lever . . . . . . . 275
Upholstery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Wiper Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Cleaning Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

320 INDEX
Climate Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Comfortseat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Comfortseat (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . 61
Compartments in Front Doors. . . . . . . . . . . . . . . . . . . 87
Constant RPMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Consumer Assistance
Be Reasonable with Request . . . . . . . . . . . . . . . . . 312
If You Need Assistance . . . . . . . . . . . . . . . . . . . . . 312
Prepare a List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
Prepare for the Appointment . . . . . . . . . . . . . . . . 312
Coolant Level Indicator Lamp . . . . . . . . . . . . . . . . . . 108
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . 103
Coolant, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Cooling System, Engine . . . . . . . . . . . . . . . . . . . . . . . 261
Corrosion Protection . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Cup Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
DDe-Fogging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Dehumidification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
De-Icing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Diesel Fuels for Use at Very Low Temperatures . . 211Direction of Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Displaying Engine Oil Level . . . . . . . . . . . . . . . . . . . 115
Doors
Front Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Rear Cargo Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Sliding Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Draining Fuel Filter with Water Separator . . . . . . . 214
Driver’s Airbag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Driving Safety Systems . . . . . . . . . . . . . . . . . . . . . . . . 163
EElectric Sun Roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Electrical Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Fuse and Relay Optional Equipment . . . . . . . . . . 281
Fuse, Relay, and Diode Assignments - Optional
Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 282
Relay Assignment, Standard Equipment . . . . . . 281
Standard Fuse and Relay Equipment. . . . . . . . . . 277
Electrical Outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Electronic Brake Force Distribution . . . . . . . . . . . . . 167
Electronic Brake Force Distribution Lamp . . . . . . . . 160
Electronic Stability Program . . . . . . . . . . . . . . . . . . . 169
Emission Label, Vehicle/Engine . . . . . . . . . . . . . . . . . . 8

INDEX 321
10
Emission Related Component . . . . . . . . . . . . . . . . . . 256
Emissions Control System . . . . . . . . . . . . . . . . . . . . . 228
Engine Break-in Recommendations . . . . . . . . . . . . . . 52
Engine Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Engine Control Unit Indicator Lamp . . . . . . . . . . . . 109
Engine Coolant. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Engine Cooling System . . . . . . . . . . . . . . . . . . . . . . . . 261
Engine Oil Consumption . . . . . . . . . . . . . . . . . . . . . . . 53
Engine Oil Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Indicator in Instrument Cluster . . . . . . . . . . . . . . 117
Engine Oil Level - Display in Instrument Cluster . 114
Engine Oil Level Indicator Lamp . . . . . . . . . . . . . . . 107
Engine Oils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Engine oils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Engine Speed, Maximum . . . . . . . . . . . . . . . . . . . . . . 145
Engine, Stopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Exhaust Gas, Inhalation of . . . . . . . . . . . . . . . . . . 54, 228
FFax Machines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Fire Extinguisher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Fog Lamp Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68Folding Seat at Partition . . . . . . . . . . . . . . . . . . . . . . . . 63
Fording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Front Seat Passenger Airbag . . . . . . . . . . . . . . . . . . . . 48
Fuel Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Fuel Filter with Water Separator . . . . . . . . . . . . . . . . 210
Fuel Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Fuel Tank Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Fuels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Bleeding the Diesel Fuel System . . . . . . . . . . . . . . 216
Diesel Fuels for Use at Very Low Temperatures 211
Draining Fuel Filter with Water Separator . . . . . 214
Fuel Filter with Water Separator . . . . . . . . . . . . . 210
Fuel Tank Capacity . . . . . . . . . . . . . . . . . . . . . . . . . 213
Refueling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Fuse and Relay Optional Equipment . . . . . . . . . . . . 281
Fuse, Relay, and Diode Assignments - Optional
Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Fuses, Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
GGear Selector Lever Position . . . . . . . . . . . . . . . . . . . 150
Glove Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Lockable Glove Compartment . . . . . . . . . . . . . . . . 87

322 INDEX
HHazard Warning Flasher Switch . . . . . . . . . . . . . . . . 232
Head Restraint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Headlamp Cleaning System . . . . . . . . . . . . . . . . . . . . 77
Headlamp Range Control. . . . . . . . . . . . . . . . . . . . . . . 68
Headlamps, taillamps, turn signal lenses . . . . . . . . 273
Heated Rear Window . . . . . . . . . . . . . . . . . . . . . . . . . 123
Heater, Seat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118, 120
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Hydroplaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
IIgnition
Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Starter Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Important Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . 179
Indicator Lamp Symbols . . . . . . . . . . . . . . . . . . . . . . 110
Inhalation of Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . 54
Installing a Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Instrument and Display Lighting . . . . . . . . . . . . . . . . 99
Instrument ClusterBattery Charge Indicator Lamp . . . . . . . . . . . . . . 106
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Coolant Level Indicator Lamp . . . . . . . . . . . . . . . 108
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . 103
Engine Control Unit Indicator Lamp . . . . . . . . . . 109
Engine Oil Level Indicator Lamp . . . . . . . . . . . . . 107
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Trip Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Water in Fuel Indicator Lamp . . . . . . . . . . . . . . . . 106
Instrument Cluster and Indicator Lamps. . . . . . . . . . 93
Instruments and Controls . . . . . . . . . . . . . . . . . . . . . . . 91
Interior Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Cargo Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Driver and Rear-Seat Passenger/Cargo Area. . . . 69
Interior Sensor Protection . . . . . . . . . . . . . . . . . . . . 69
Reading Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Intervals, Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 305
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Intrument Cluster
Fuel Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
JJack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

324 INDEX
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304
Oil Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
Once a Year . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Regular Check-Ups. . . . . . . . . . . . . . . . . . . . . . . . . 306
Scope of Work for Maintenance service . . . . . . . 308
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304
With ASSYST Maintenance Computer . . . . . . . . 306
Without ASSYST Maintenance Computer . . . . . 305
Maximum Engine Speed . . . . . . . . . . . . . . . . . . . . . . 145
MaximumTire Inflation Pressure . . . . . . . . . . . . . . . 199
Mechanical Sun Roof. . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Mechanical Sun Roof Operation . . . . . . . . . . . . . . . . . 81
Mirror Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Mirrors
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Mobile Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Mopar® Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
Multi-Function Indicator . . . . . . . . . . . . . . . . . . . . . . . 96
Multifunction Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 72OOccupant Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Opening/Closing doors . . . . . . . . . . . . . . . . . . . . . . . . 27
Operation, Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Ornamental Moldings . . . . . . . . . . . . . . . . . . . . . . . . . 273
Outlet, Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Outside Temperature Display . . . . . . . . . . . . . . . . . . 100
Overheating (Air Heater) . . . . . . . . . . . . . . . . . . . . . . 140
PPassenger Airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Passenger Airbag, Front Seat . . . . . . . . . . . . . . . . . . . . 48
Passenger Compartment Protection . . . . . . . . . . . . . . 25
Alarm Pushbutton . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Pedals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Permissible Roof Load . . . . . . . . . . . . . . . . . . . . . . . . 216
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Power Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Programmed Top Speed . . . . . . . . . . . . . . . . . . . . . . . 213
RRadial-Ply Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
