windshield wipers DODGE STRATUS 2006 2.G Owners Manual

▫Daytime Running Lights (Canada Only)......62
▫Lights-On Reminder....................62
▫Fog Lights—If Equipped................62
▫Turn Signals..........................62
▫Headlight Beam Select Switch.............63
▫Flash To Pass.........................63
▫Headlight Time Delay...................63

Windshield Wipers And Washers...........63
▫Mist................................64
▫Speed Sensitive Intermittent Wiper System....64

Tilt Steering Column.....................64

Traction Control—If Equipped.............65

Electronic Speed Control—If Equipped......66
▫To Activate...........................66
▫To Set At A Desired Speed................66
▫To Deactivate.........................67▫To Resume Speed......................67
▫To Vary The Speed Setting................67
▫To Accelerate For Passing................67
▫Using Speed Control On Hills.............67

Garage Door Opener—If Equipped.........69
▫Programming The Universal Transceiver......69
▫“Rolling Code”Programming.............71
▫Canadian Programming/Gate Programming . . .72
▫Operation............................73
▫Reprogramming A Single Button...........73
▫Security.............................73

Power Sunroof—If Equipped.............74
▫Opening Sunroof - Manual...............75
▫Opening Sunroof - Express...............75
▫Closing Sunroof - Manual................75
▫Venting Sunroof - Express................75
48 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Automatic Headlights—If Equipped
This system automatically turns your headlights on at a
preset level of outdoor lighting. Turn the end of the
control lever to the third detent to turn the system on.
When the system is on, the headlight delay feature is also
on. This means that your headlights will stay on for about
90 seconds after you turn the ignition switch off. To turn
the Automatic system off, turn the control lever clock-
wise, to the off position.
NOTE:The engine must be running before the head-
lights will come on in the automatic mode.
NOTE:The Automatic Headlight System will turn on
the headlights if it detects that the windshield wipers
have been in operation for more than 10 seconds.
Daytime Running Lights (Canada Only)
The headlights come on at a low intensity level whenever
the ignition switch is turned on. The lights remain on
until the ignition switch is turned OFF or the parking
brake is engaged. The headlight switch must be used for
normal night time driving.
Lights-on Reminder
If the headlights or parking lights are on after the ignition
is turned off, a chime will sound when the driver’s door
is opened.
Fog Lights—If Equipped
The fog light switch is in the multi-function lever.
To activate the fog lights, turn on the low beam
headlights and pull out the end of the control
lever. A light in the instrument cluster shows when the
fog lights are on.
NOTE:The switch will turn on the fog lights only if the
low beam headlights are on. Turning on the high beam
headlights turns off the fog lights.
Turn Signals
Move the turn signal lever up or down and the arrows in
the instrument cluster flash to show proper operation of
the front and rear turn signal lights. You can signal a lane
change by moving the lever partially up or down.
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Headlight Beam Select Switch
Pull the turn signal lever towards you to switch the
headlights to HIGH beam. Pull the turn signal lever a
second time to switch the headlights to LOW beam.
Flash to Pass
You can signal another vehicle with your headlights by
lightly pulling the turn signal lever toward the steering
wheel. This will cause the headlights to turn on at high
beam and remain on until the lever is released.
Headlight Time Delay
This feature provides the safety of headlight illumination
for about 90 seconds when leaving your vehicle in an
unlighted area.
To activate the delay, turn off the ignition while the
headlights are still on. Then turn off the headlights. The
delay interval begins when the ignition is turned off.
If the headlights are turned off before the ignition, they
will turn off in the normal manner.
WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by a switch in the
right side control lever. Turn the end of the control lever
to select the desired wiper speed.
NOTE:Always remove any build-up of snow that
prevents the windshield wiper blades from returning to
the OFF position. If the windshield wiper switch is
turned OFF and the blades cannot return to the OFF
position, damage to the wiper motor may occur.
Windshield Wiper/Washer Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 63
3

To use the washer, pull the lever toward you and hold
while spray is desired. If the lever is pulled while in the
delay range, the wiper will operate for several cycles
after the lever is released, and then resume the intermit-
tent interval previously selected.
If the lever is pulled while in the OFF position, the wipers
will operate for several cycles, then turn OFF.
WARNING!
Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with defroster before and during wind-
shield washer use.
Mist
Use this feature when weather conditions make occa-
sional usage of the wipers necessary. Pull down and
release the control lever for a single wiping cycle.
Speed Sensitive Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable. Turn the lever to the delay
position, then select the delay interval. The delay can be
regulated from a maximum of approximately 18 seconds
between cycles, to a cycle every 1/2 second.
NOTE:The wiper delay times depend on vehicle speed.
If the vehicle is moving less than 16 km/h (10 mph),
delay times will be doubled.
TILT STEERING COLUMN
To tilt the column, push down on the lever below the turn
signal control and move the wheel up or down, as
desired. Push the lever back up to lock the column firmly
in place.
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

If you use a lubricant that cannot be dispensed directly
into the lock cylinder, apply a small amount of the
lubricant to the key. Insert the key into the lock cylinder,
then proceed as described above, to distribute the lubri-
cant within the lock cylinder. Pay attention to trunk
hinges, especially during cold weather, to ensure ease of
trunk operation.
Other Body Mechanisms
The following body mechanisms should be inspected
and, if necessary, all pivot and sliding contact areas of
these components should be lubricated with the lubricant
specified as follows:
Engine Oil
•
Door hinges
•Hood hinges
•Trunk hinges
Smooth White Body Lubricant - Such as Mopar
Spray White Lube or equivalent:
•
Hood hinge springs and links
•Lock cylinders
•Parking brake mechanism
•Trunk latches
•Ash tray
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild non abrasive cleaner. This will remove accumula-
tions of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to
remove frost or ice from the windshield. Keep the blade
rubber out of contact with petroleum products such as
engine oil, gasoline, etc.
MAINTAINING YOUR VEHICLE 221
7

Vanity Mirrors.......................... 54
Vehicle Identification Number (VIN).......... 6
Vehicle Loading.....................157,178
Vehicle Modifications/Alterations............ 6
Vehicle Storage......................... 240
Vehicle Theft Alarm (Security Alarm)......... 19
Vinyl Trim............................ 235
Viscosity, Engine Oil..................... 246
Voltmeter.............................. 84
Warning, Door Ajar...................... 13
Warning Flasher, Hazard................. 190
Warnings and Cautions.................... 6
Warranty Information.................... 272
Washer, Adding Fluid................... 222Washers, Windshield..................63,222
Washing Vehicle........................ 233
Waxing and Polishing................... 233
Wheel Alignment and Balance............. 167
Wind Buffeting.......................22,75
Window Airbag (Side Curtain)............30,35
Window Fogging....................... 126
Windows.............................. 21
Power.............................. 21
Windshield Washers...................63,222
Windshield Wipers.................62,63,221
Wiper Blade Replacement................. 222
Wipers, Intermittent...................... 64
Wood Trim Cleaning.................... 236
INDEX 291
10
