DODGE STRATUS COUPE 2004 2.G Manual PDF

2. Grasp the metal tongue and slide it up the webbing so
that it becomes easy to pull across your body.
After a couple of tries this will become an automatic
one-handed motion.3. Pull the seat belt out slowly while holding the metal
tongue. This system will not lock up if you stop or
hesitate, so relax and continue to ªbuckle-upº.
Push the metal tongue into the buckle until a ªclickº is
heard. Pull up on the belt to confirm the metal tongue is
locked securely in the buckle.
NOTE:If the seat belt is pulled to its full extension, it can
enter the ALR mode and lock in position. If this occurs,
allow the belt to fully retract and then repeat step 3.
G28A0220G28A0230
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 71
3

4. Pull up on the shoulder portion of the belt to ensure
that there is no slack in the lap belt. The belt will retain
the small amount of slack necessary for comfort when
you return to your normal seating position. If the belt is
still too tight, pull out 6 to 8 inches of webbing, release
the belt, and let it return to your chest.
NOTE: If a person wearing the seat belt moves their
upper body or the belt completely unwinds, the retractor
may switch to its Automatic Locking Retractor (ALR)
child restraint installation mode and lock (see page 82),
thus preventing further movement. If this happens, the
person should switch the retractor back to its Emergency
Locking Retractor (ELR) mode by unlatching the buckle
and letting the belt fully retract. The person should then
put the seat belt back on repeating steps 1 through 4.
WARNING!
²Be sure the lap belt portion fits snugly and as low
as possible across the hips, not around the waist.
Failure to do so may increase the chance or sever-
ity of injury in the event of a collision.
²Wear the seat belt without twisting it.
G28A0240
72 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

5. The shoulder belt portion will allow regular move-
ment under normal conditions. The belt will lock in the
event of an abrupt change in vehicle motion.
6. To release the belt, push the button on the buckle. The
belt retracts automatically, so hold the tongue when the
belt is released and while it retracts. Should the belt not
fully return to its stowed position, pull the shoulder belt
down slightly and release quickly.
Adjustable seat belt shoulder anchor (front seats)
The seat belt shoulder anchor height can be adjusted for
greater comfort.
To move the anchor down, depress the lock knob (A). To
move the anchor up, simply slide the anchor up to the
desired position (there is no need to depress the lock
knob).
G28A0260
G08C0070
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 73
3

WARNING!
To reduce risk of serious injury in a collision, adjust
the anchor at a position so that the belt passes over
your shoulder, but does not touch your neck.
Always adjust the anchor when vehicle is not in
motion.
Make sure the anchor is securely latched after ad-
justment.
Enhanced Driver Seat Belt Use Reminder System
(BeltAlertŸ)
If the driver 's seat belt has not been buckled within 60
seconds of starting the vehicle and if the vehicle speed is
greater than 5 mph (8 km/h), the Enhanced Warning
System (BeltAlertŸ) will alert the driver to buckle their
seat belt. The driver should also instruct all other occu-
pants to buckle their seat belts. Once the warning is
triggered, the Enhanced Warning System (BeltAlertŸ)
will continue to chime and flash the Seat Belt Warning
Light for 96 seconds or until the driver 's seat belt is
buckled.The Enhanced Warning System (BeltAlertŸ) will be
reactivated if the driver 's seat belt is unbuckled for more
than 10 seconds and the vehicle speed is greater than 5
mph (8 km/h).
The Enhanced Warning System (BeltAlertŸ) can be en-
abled or disabled by your authorized dealer or by
following these steps:
NOTE:
The following steps must occur within the first 60
seconds of the ignition switch being turned to the ON
or START position. The manufacturer does not recom-
mend deactivating the Enhanced Warning System
(BeltAlertŸ).
·Turn the ignition switch to the OFF position, and
buckle the driver 's seat belt.
·Turn the ignition key to the ACCESSORY/RUN
position (engine does not need to be running), and
wait for the Seat Belt Warning Light to turn off.
·Within 60 seconds of starting the vehicle, unbuckle
and then re-buckle the driver 's seat belt at least three
times within 10 seconds, ending with the seat belt
buckled.
74 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

·Turn the ignition key to the OFF position. A single
chime will sound to signify that you have successfully
completed the programming.
The Enhanced Warning System (BeltAlertŸ) can be reac-
tivated by repeating this procedure.
NOTE: Although the Enhanced Warning System
(BeltAlertŸ) has been deactivated, the Seat Belt Warning
Light will continue to illuminate while the driver 's seat
belt remains unfastened.
Seat belt extender
If the seat belt is too short, even when fully extended, a
seat belt extender is available from your dealer. The
extender may be used for either front seating positions.
G28A0160
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 75
3

WARNING!
²The extender should only be used if the existing
belt is not long enough.
Persons who can use the standard seat belt should
not use an extender. Unnecessary use could result
in serious personal injury in the event of a colli-
sion.
²When not required, the extender must be removed
and stowed because the use of the extender when
not required may deactivate the seat belt locking
mechanism.
CHILD RESTRAINTS
When transporting infants or small children in your
vehicle, an appropriate child restraint system should
always be used. This is required by law in most states.
Child restraints specifically designed for infants and
small children are offered by several manufacturers. Only
choose a child restraint system with a label certifying it
complies with Federal Motor Vehicle Safety Standard
213.The child restraint system should be appropriate for your
child's weight and height and properly fit the vehicle's
seat.
All children should be restrained in a restraint device that
offers the maximum protection for their size and age.
·Children less than 1 year and less than 20 pounds must
ride in a rear-facing child safety seat only in the rear
seat.
·Children older than 1 year who weigh less than 40
pounds or are less than 40 inches tall should be in a
forward-facing restraint in the rear seat.
·Children who weigh more than 40 pounds or are more
than 40 inches tall - regardless of age - should use a
booster seat in the rear seat until the lap/shoulder belt
fits properly.
76 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

WARNING!
²All children 12 years old and under should be
seated in the rear seat, and properly restrained.
Accident statistics indicate that children of all
sizes and ages are safer when properly restrained
in the rear seat rather than in the front seat.
²Any child who is too large to use a child restraint
should ride in the rear seat and wear the lap and
shoulder belt properly. The shoulder belt should
be over the shoulder and across the chest, not
across the neck, and the lap belt should be low on
the child's hips, not across the stomach. If neces-
sary, a booster seat should be used for proper seat
belt fit; follow the booster seat manufacturer's
instructions. Only use a booster seat that certifies
it complies with Federal Motor Vehicle Safety
Standards.
WARNING!
Never hold an infant or child in your arms or on your
lap when riding in a vehicle, even if you are wearing
your seat belt. Also never place any part of your seat
belt around an infant or child. To do so risks severe
or fatal injury to the child in a collision or sudden
stop.
G28A0890
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 77
3

WARNING!
This vehicle is also equipped with a front passenger
air bag. Rear facing child restraints place an infant
too close to the air bag, the force of an inflating front
passenger air bag could strike a rear-facing child
restraint, causing serious or fatal injury to the child:
REAR-FACING CHILD RESTRAINTS MUST
ONLY BE USED IN THE REAR SEAT.
WARNING!
FRONT-FACING CHILD RESTRAINTS should al-
ways be used in the rear seat whenever possible; if
one must be used in the front passenger seat, adjust
the seat as far back as possible and ensure that the
child stays in the child seat properly restrained.
Failure to do so could kill or cause serious injury to
the child.
G28G3170
Air bag cover
G28G1060
78 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

WARNING!
²It is important to use an approved rear facing
infant restraint until the infant is one year old to
allow the infant's neck and spine to develop
enough to support the weight of their head in the
event of a collision.
²When installing a child restraint system, follow
the instructions provided by the manufacturer
and follow the directions in this manual. Failure
to do so can result in severe or fatal injury to your
child in a collision or sudden stop.
²After installation, push and pull the child re-
straint system back and forth, and side to side, to
see that it is firmly secured. If the child restraint
system is not installed securely, it may cause
injury to the child or other occupants in the event
of a collision or sudden stop.
²When not in use, keep your child restraint system
secured with the seat belt or remove it from the
vehicle in order to prevent it from being thrown
inside the vehicle during an accident.
NOTE: Before purchasing a child restraint system, try
installing it in the rear seat to ensure a good fit. Due to the
location of the seat belt buckles and the shape of the seat
cushion it may be difficult to securely install some child
restraint systems.
If the child restraint system can be pulled forward or to
either side easily on the seat cushion after the seat belt
has been tightened, choose another child restraint sys-
tem.
²Depending on the seating position in the vehicle and
the child restraint system that you have, the child
restraint can be attached using one of the following 2
methods:
²To the lower anchorage in the rear seat ONLY if the
child restraint complies with Federal Motor Vehicle
Satety Standard 213 (See page 80).
²To the UNIBELT (See page 82).
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 79
3

Installing a new child restraint system to the lower
anchorage
Your vehicle's rear seat is fitted with lower anchorages
for attaching a new child restraint system that complies
with Federal Motor Vehicle Safety Standard 213.
NOTE
²
The marks on the seatback show the location of the
lower anchorage points.
New child restraint system that complies with
Federal Motor Vehicle Safety Standard 213
A: Rear-facing child restraint
B: Forward-facing child restraint
C: Child restraint system connectors
(These are only examples.)
G08C0070G18C0750
80 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS
