8W-50 FRONT LIGHTING
Component Page
Body Control Module............. 8W-50-2, 4, 5
Diagnostic Junction Port........... 8W-50-5, 6, 8
Front Control Module . . 8W-50-3, 4, 6, 7, 8, 9, 10, 11
Front Fog Lamp Relay............... 8W-50-11
Fuse 1............................ 8W-50-11
Fuse 2........................... 8W-50-4, 6
Fuse 3.......................... 8W-50-4, 8
G102......................... 8W-50-4, 8, 11
G200........................... 8W-50-2, 10
G300.............................. 8W-50-3
Headlamp Switch................. 8W-50-2, 10
Integrated Power
Module......... 8W-50-3, 4, 5, 6, 7, 8, 9, 10, 11
Left Fog Lamp..................... 8W-50-11
Left Front Park/Turn Signal Lamp....... 8W-50-4Component Page
Left Headlamp...................... 8W-50-3
Left Headlamp Leveling Motor....... 8W-50-6, 10
Left High Beam Lamp.............. 8W-50-6, 7
Left Low Beam Lamp................. 8W-50-7
Left Park Lamp................... 8W-50-6, 7
Multi- Function Switch................ 8W-50-5
Park Lamp Relay................ 8W-50-4, 6, 8
Right Fog Lamp.................... 8W-50-11
Right Front Park/Turn Signal Lamp...... 8W-50-4
Right Headlamp..................... 8W-50-3
Right Headlamp Leveling Motor...... 8W-50-8, 10
Right High Beam Lamp............. 8W-50-8, 9
Right Low Beam Lamp................ 8W-50-9
Right Park Lamp.................. 8W-50-8, 9
RS8W-50 FRONT LIGHTING8W-50-1
