8W-51 REAR LIGHTING
Component Page
Back-Up Lamp Switch................ 8W-51-5
Battery............................ 8W-51-5
Body Control Module............ 8W-51-2, 3, 4, 5
Brake Lamp Switch................ 8W-51-2, 4
Center High Mounted Stop Lamp........ 8W-51-6
Front Control Module............. 8W-51-2, 4, 5
Fuse 2........................... 8W-51-2, 4
Fuse 3......................... 8W-51-2, 4, 5
Fuse 26.......................... 8W-51-2, 4
G101.............................. 8W-51-5
G103.............................. 8W-51-5Component Page
G302........................ 8W-51-2, 3, 4, 5
G400.............................. 8W-51-6
Integrated Power Module.......... 8W-51-2, 4, 5
Left Rear Lamp Assembly........ 8W-51-2, 3, 4, 5
Left Stop/Turn Signal Relay............ 8W-51-3
License Lamp....................... 8W-51-6
Park Lamp Relay................ 8W-51-2, 4, 5
Right Combination Relay.............. 8W-51-3
Right Rear Lamp Assembly......... 8W-51-2, 4, 5
Trailer Tow Connector................. 8W-51-3
RS8W-51 REAR LIGHTING8W-51-1
