DODGE VIPER 2004 ZB / 2.G Owners Manual

Power Distribution Center
Cavity Fuse Circuits
1 Cartridge Fuse 40
AmpBatt-Relay Contact, High
Blower Motor Module-
ABS Pump Feed
2 Cartridge Fuse 40
AmpABS Pump Feed
3 Cartridge Fuse 30
Amp GreenBattery
4 Cartridge Fuse 20
Amp YellowFused Feed to RS Ampli-
fier or Power Amplifier
5 Cartridge Fuse 30
Amp GreenIgnition Switch (Run &
Accessory)-(Downstream)
6 Cartridge Fuse 40
AmpBatt
7 Cartridge Fuse 30
Amp GreenBatt-Relay Contact, ABS
Pump Motor
8 Cartridge Fuse 30
Amp GreenBatt-Motor, WiperCavity Fuse Circuits
9 Cartridge Fuse 40
AmpBatt-Fuseblock
10 Cartridge Fuse 30
Amp GreenBatt-Switch, Ignition
(Run/Start/Accy)
11 Mini Fuse 20
Amp YellowBatt-Relay Contact, Auto
Shutdown
12 Mini Fuse 20
Amp YellowSecondary Power Outlet
Feed
13 Mini Fuse 15
Amp BlueBatt-Flasher, Hazard
14 Mini Fuse 15
Amp BlueRear 02 Sensor to Heater
Relay
15 Mini Fuse 20
Amp YellowElectric Heated RR. WDO
(EBL)
16, 17 Mini Fuse 20
Amp YellowFused Feed-Cigar Lighter
MAINTAINING YOUR VEHICLE 181
7

Cavity Fuse Circuits
18 Mini Fuse 15
Amp BlueBatt-Locks, Power Door
19 Mini Fuse 15
Amp BlueBatt
20 Mini Fuse 15
Amp BlueFeed-Courtesy, Dome, Vi-
sor, Illuminated Entry,
Reading
21 Mini Fuse 15
Amp BlueFuse Feed to Stop Lamp
Switch
22 Mini Fuse 15
Amp BlueBattery to AC Clutch Re-
lay
23, 24 Mini Fuse 10
Amp RedAirbag, Ignition Run
25-29 ISO RELAY Batt-Relay Contact, High
Blower Motor
30-34 MICRO RELAY Batt-Relay-Starter Contact
to SolenoidCavity Fuse Circuits
35-39 MICRO RELAY Feed-Auto Shutdown Re-
lay Coil
40-44 MICRO RELAY Feed-Horn (From Relay)
45-49 MICRO RELAY Batt-Relay-Headlamps
50-54 MICRO RELAY Relay-A/C Clutch Output
from Relay Contact (B+)
55-59 MICRO RELAY Left/Right Downstream
Oxygen Sensor Output
Feed FR
60, 61 Mini Fuse 15
Amp BlueIgnition Start/Run Relay
Coil
62, 63 Mini Fuse 15
Amp BlueIgnition Start/Run Gauges
64, 65 Mini Fuse 10
Amp RedIgnition Start/Run Airbag
66, 67 Mini Fuse 20
Amp YellowFeed-Ign Run/Acc Wiper
Switch
182 MAINTAINING YOUR VEHICLE

Cavity Fuse Circuits
68, 69 Mini Fuse 20
Amp YellowLeft HID Headlamp
70, 71 Mini Fuse 20
Amp YellowRight HID Headlamp
72-76 MICRO RELAY Batt-Run/Acc Relay
82-86 MICRO RELAY Heated Rear Window
(EBL) Relay
87-91 MICRO RELAY Batt-Motor, Fuel Pump
RelayVEHICLE STORAGE
We recommend that you follow these guidelines before
storing your vehicle for extended periods.
²Fill the fuel tank. This will prevent water condensation
inside the gas tank.
If you plan on storing your vehicle more than 2
months, add an anti-oxidant fuel stabilizer to the fuel
tank.
²Change the oil to remove any corrosive combustion
related acids in the crankcase.
²Wash and wax the vehicle to protect the finish.
²Cover the vehicle whenever possible to prevent acci-
dental damage to the finish.
²Store the vehicle in a dry, well ventilated location.
MAINTAINING YOUR VEHICLE 183
7

²If the vehicle will be subjected to freezing tempera-
tures, remove the battery and store it in a dry, well
ventilated area or place a trickle charger (1.5 Amp)
with automatic shutdown / overcharge protection
connected to the battery. Do not leave the trickle
charger hooked up to the battery without being
plugged into the 110 AC voltage outlet, because this
will result in further drain on the vehicle's battery. If
the vehicle is not going to be driven in the next 3
weeks, follow the battery recharge procedure in the
Service Manual, then disconnect the battery at the
negative terminal or use the save feature described in
Maintaining your Vehicle section under the Mainte-
nance Procedures sub-section, within Maintenance-
Free Battery.CAUTION!
Use care when disconnecting the remote positive
cable. It is connected to the battery and can short out
to any metal on the vehicle. Always tape or wrap the
exposed cable end to prevent electrical shorts.
²Disconnecting the battery causes the engine control
system to lose memory of some ªlearnedº functions,
unless using the Battery Save feature described in
Maintaining your Vehicle section under the Mainte-
nance Procedures sub-section, within Maintenance-
Free Battery. The engine may run rough when first
started after a battery disconnect until the control
module ªrelearnsº these functions.
184 MAINTAINING YOUR VEHICLE

Check the battery every 4 to 6 weeks to ensure that the
voltage is above 12.40. Voltage will drop more rapidly
in hot temperatures. If battery voltage drops below
12.40, follow the battery recharge procedure in the
Service Manual.
²Check that the radiator coolant level of protection is to
at least -20ÉF (-29ÉC).
²Block the wheels. Do not apply the Parking Brake.
²Make sure that all tires are inflated to the optimum
pressure, (29 PSI).
²Cut blocks of plywood about the same size of the tires.
Cover each block with indoor/outdoor carpeting and
place them between the tires and concrete. This will
prevent tire flat spotting.
²For long term storage, remove the tires and put the
vehicle up on blocks. Stack the tires on plywood and
cover with a tarp to prevent flat spotting.
²Move the wiper blades away from the windshield.
NOTE:To help prevent the battery from discharging
during shorter periods of inactivity, perform the follow-
ing:
1. Make sure that the trunk, hood, doors, windows and
convertible top are completely closed.
2. Make sure that remote transmitter is operating and
that the battery is good.
3. Make sure that the hood, trunk and door switches are
in adjustment. Perform the quick system check which
follows.
Use the remote transmitter to set the alarm. If the alarm
SET light comes on and flashes, the system is operating
properly. If not, there is a problem with a switch or the
system. See your dealer for service.
MAINTAINING YOUR VEHICLE 185
7

REPLACEMENT BULBS
Interior Light Bulbs
Message Center Indicators.................. 103
Cluster................................ 103
Gauge Pack............................ 103
Heater Control........................... 37
Interior Light..........................212±2
Courtesy Footwell Lights................... 194
Exterior Light Bulbs
Headlight-Low/High Beam.... Serviced at dealer only
Aux. Headlight-High Beam.........(HB3A) 9005XS
Front Park/Turn......................3157AK
Fog Light.......................(H10 U) 9145
Front Sidemarker.......................2886X
Center Stop Light.......... 16LED(not serviceable)
Rear Tail/Stop..........................3157
Rear Tail Light.......................... 194
Rear Marker Light........................ 194
Back up Light..........................3157
Rear Turn Light.......................3457AK
License................................ 168
NOTE:You will note that upon turning the (HID) High
Intensity Discharge Headlamp Bulbs on, there is a blue
hue to the lamps. This diminishes and becomes more
white after approximately 10 seconds as the system
charges.
186 MAINTAINING YOUR VEHICLE

EXTERIOR LIGHT BULB SERVICE
Headlight, Parking, Front Park, Turn Signal, Front
Sidemarker and Front Fog Light Removal
1. Remove the splash shield.2. Twist off sockets counter-clockwise and pull out bulbs
from the socket, install the new bulbs, and reinstall the
bulb and socket assembly. Replace the splash shield.
MAINTAINING YOUR VEHICLE 187
7

NOTE:On vehicles equipped with High Intensity Dis-
charge Headlights (HID), when the headlights are turned
on there is a blue hue to the lights. This diminishes and
becomes more white after approximately 10 seconds, as
the system charges.
High Intensity Discharge Headlights (HID)
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
NOTE:If High Intensity Discharge (HID) lights are not
working, recycle the headlight switch 4 times to see if it
will restrike.
188 MAINTAINING YOUR VEHICLE

Tail, Tail/Stop, and Marker Lamp Bulb
Replacement
1. Open the trunk. Remove two access panel fasteners.
Remove the access panel.
2. Twist sockets counter-clockwise to pull out bulbs.
Replace tail, tail/stop, or marker lamp bulb.3. Reinstall the appropriate bulb and socket assembly.
Replace the access panel. Close the trunk.
MAINTAINING YOUR VEHICLE 189
7

Backup and Rear Turn Signal Lamp Bulb
Replacement
1. Open the trunk. Remove two access panel fasteners.
Remove the access panel.2. Remove three plastic nuts from the upper lamp assem-
bly.
190 MAINTAINING YOUR VEHICLE
