A WORD ABOUT YOUR KEYS
The dealer that sold you your new Viper has the key code
numbers for your vehicle locks. These numbers can be
used to order duplicate keys from your dealer or a
locksmith. Ask your dealer for these numbers and keep
them in a safe place.
Ignition Key
Press clutch and insert the ignition key fully, then turn
the switch to one of the four illustrated positions. It may
be difficult to turn the key from the OFF/LOCK position
when starting your vehicle. Move the steering wheel left
and right while turning the key until it turns easily. To
start the vehicle fully apply the parking brake, press the
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
2
Page 38 of 236
²If the shoulder belt contacts the face or neck, move the
child closer to the side of the vehicle.
Booster seats that may help overcome this problem are
also available for use with lap/shoulder belts. Before
buying a booster seat, make sure that it has a label
certifying that it meets applicable Motor Vehicle Safety
Standards. Make sure that it is satisfactory for use in this
vehicle.
Supplemental Restraint System (SRS) - Airbag
This vehicle has airbags for the driver and passenger as a
supplement to the seat belt restraint systems. The driver's
airbag is mounted in the steering wheel. The passenger
side airbag is mounted in the instrument panel, under a
cover marked SRS/AIRBAG. These airbags inflate in
higher speed impacts. They work with the instrument
panel knee bolsters and the seat belts to provide im-
proved protection for the driver and right front passen-
ger.
WARNING!
²Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won't deploy at all.
Wear your seat belts even though you have air-
bags.
²Being too close to the steering wheel or instru-
ment panel during airbag deployment could cause
serious injury. Airbags need room to inflate. Sit
back, comfortably extending your arms to reach
the steering wheel or instrument panel.
The seat belts are designed to protect you in many types
of collisions. The airbags deploy only in frontal collisions
and will not deploy in collisions at slow speed. But even
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 40 of 236
2.All occupants should wear their lap and shoulder
belts properly.
3.The driver and passenger seats should be moved
back as far as practical to allow the airbags room to
inflate. Additionally, the pedals are power adjustable,
so the driver seat can be moved back and the pedals
moved closer as needed so the driver can be as far from
the airbag as possible. (See section on Power Adjust-
able Pedals for operation.)
4.You should read the instructions provided with your
child safety or booster seat to make sure that you are
using it properly.
The airbag system consists of the following:
²Airbag control module and internal crash sensor
²AIRBAG Readiness Light
²Driver and Passenger Airbag/inflator Units
²Passenger Side Airbag On/Off Switch
²Passenger Airbag Off Indicator Light
²Unique Steering Wheel and Column
²Unique Instrument Panel
²Interconnecting Wiring
²Knee Impact Bolster
How The Airbag System Works
²
A crash sensor in the occupant compartment deter-
mines if a frontal impact is severe enough to require
the airbag. The sensor will not detect side, roll over, or
rear impacts. The crash sensor is connected to the
diagnostic unit and to the airbag/inflator unit.
²The Diagnostic Unit monitors the readiness of the
electronic parts of the system whenever the ignition
switch is in the START or RUN position. These include
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 41 of 236
all of the items listed above except the knee bolster, the
instrument panel, and the steering wheel and column.
The Diagnostic Unit also turns on the AIRBAG light in
the instrument panel for 6 to 8 seconds when the
ignition is first turned on, then turns the light off. If it
detects a malfunction in any part of the system, it turns
on the light either momentarily or continuously.
²The Airbag/Inflator Units are in the center of the
steering wheel and in the instrument panel. The words
SRS/AIRBAG are embossed on the airbag covers.
WARNING!
Ignoring the AIRBAG light in your instrument panel
could mean you won't have the airbags to protect
you in a collision. If the light does not come on, stays
on after you start the vehicle, or if it comes on as you
drive, have the airbag system checked right away.
WARNING!
Do not put anything on or around the airbag covers
or attempt to manually open them. You may damage
the airbags and you could be injured because the
airbags are not there to protect you. These protective
covers for the airbag cushions are designed to open
only when the airbags are inflating.
²When the crash sensors detect an impact requiring the
airbags, they signal the inflator units. A large quantity
of non toxic nitrogen gas is generated to inflate the
airbags. The airbag covers separate and fold out of the
way as the airbags inflate to their full size. The airbags
fully inflate in about 50 milliseconds. This is only
about half of the time it takes you to blink your eyes.
The airbags then quickly deflate while helping to
restrain the driver and right front passenger. The
airbag gas is vented through the airbag material
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2
Page 43 of 236
²Your vehicle may be safely driveable after the airbags
deploy. If so, you can tuck the deployed airbags inside
the opening in the steering wheel hub and instrument
panel trim covers to make driving somewhat easier.
WARNING!
Deployed airbags can't protect you in another colli-
sion. Have the airbags replaced by an authorized
dealer as soon as possible.
Passenger Side AirBag On/Off Switch
The passenger airbag is to be turned off only if the
passenger:
²is an infant (less than 1 year old) who must ride in the
front seat because there is no rear seat, because the rear
seat is too small for a rear-facing infant restraint orbecause the infant has a medical condition which
makes it necessary for the driver to be able to see the
infant,
²is a child, age 1 to 12 who must ride in the front seat
because there is no rear seat, because there is no rear
seat position available, or because the child has a
medical condition which makes it necessary for the
driver to be able to see the child,
²has a medical condition which makes passenger airbag
inflation (deployment) a greater risk for the passenger
than the risk of hitting the dashboard (instrument
panel) or windshield in a crash.
If the airbag is turned off when there is any other
occupant at that position, the supplemental restraint
provided by the airbag will not be available.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
2
Page 50 of 236
NDaytime Running Lights.................63
NLights-On Reminder....................63
NHeadlight Time Delay...................63
NBattery Saver Feature Ð Exterior Lights......63
NFog Lights...........................64
NTurn Signals..........................64
NHighbeam/Lowbeam Select Switch..........65
NPassing Light.........................65mTilt Steering Column.....................65
mAdjustable Pedals.......................66
NAdjustable Left Foot Rest.................67
mWindshield Wipers And Washers.............68
NWindshield Washers....................69
NMist Function.........................69
NIntermittent Wiper System................69
50 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 61 of 236
Interior Lights
The interior lights come on when a door is opened and
the dome switch is not in the defeat position.
Battery Saver Feature Ð Interior Lights
The interior courtesy lights come on when a door is open
or left ajar. To prevent battery drain, if you leave a door
open or ajar, these lights will turn off after 15 minutes.
After you close the door, the interior courtesy lights will
again function in the normal manner.
Multi-Function Control Lever
The Multi-Function Control Lever controls the operation
of the headlights, parking lights, turn signals, headlight
beam selection, instrument panel light dimming, interior
lights, the passing lights, and fog lights. The lever is
located on the left side of the steering column.
Dimmer Control
With the parking lights or headlights
on, rotating the dimmer control for the
interior lights on the Multi-Function
Control Lever upward will increase
the brightness of the instrument panel
lights.
Dome Light Position
Rotate the dimmer control completely
upward to the second detent to turn
on the interior lights. The interior
lights will remain on when the dim-
mer control is in this position.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3
Page 65 of 236
If either light remains on and does not flash, or there is a
very fast flash rate, check for a defective outside light
bulb. If an indicator fails to light when the lever is
moved, it would suggest that the fuse or indicator bulb is
defective.
Highbeam/Lowbeam Select Switch
Pull the Multi-Function Control Lever towards you to
switch the headlights to HIGH beam. Pull the control
lever a second time to switch the headlights to LOW
beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multi-function lever toward the steer-
ing wheel. This will cause the headlights to turn on at
high beam and remain on until the lever is released.
Tilt Steering Column
To tilt the column, simply pull down the small lever
below the turn signal control and move the wheel up or
down, as desired. Return the lever to the up position to
lock the wheel firmly in place.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65
3
Page 66 of 236
WARNING!
Tilting the steering column while the vehicle is
moving is dangerous. Without a stable steering col-
umn, you could lose control of the vehicle and have
an accident. Adjust the column only while the ve-
hicle is stopped. Be sure it is locked before driving.
ADJUSTABLE PEDALS
Your Viper is equipped with an adjustable pedal system
that allows about 4 inches (100 mm) of fore and aft pedal
adjustment. The pedals are adjusted using a switch
recessed into the knee bolster beneath the steering col-
umn.To adjust the pedals:
²Adjust the seat to a comfortable driving position.
²Adjust the pedals to a position that allows full pedal
travel.
²It may be necessary to make further small adjustments
to find the best possible seat/pedal position.
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 95 of 236
STARTING AND OPERATING
CONTENTS
mStarting Procedures......................97
NIf Engine Fails To Start..................98
NAfter Starting........................100
mTransmission Shifting....................100
NRecommended Shift Speeds..............101
NSkip Shift Light.......................101
mParking Brake.........................102
mBrake System..........................104
NBrake Pad Break-In....................107mPower Steering........................107
mTire Safety Information...................108
NTire Markings........................108
NTire Identification Number (TIN)..........111
NTire Loading And Tire Pressure...........112
mTiresÐGeneral Information................116
NTire Pressure.........................116
NTire Inflation Pressures.................117
NRadial-Ply Tires......................120
5
