DODGE VIPER 2006 ZB / 2.G Owners Manual

REPLACEMENT BULBS
Interior Light Bulbs
Message Center Indicators.................. 103
Cluster................................ 103
Gauge Pack............................ 103
Heater Control........................... 37
Interior Light..........................212–2
Courtesy Footwell Lights................... 194
Exterior Light Bulbs — Convertible Models
Headlight-Low/High Beam.... Servicedatdealer only
Aux. Headlight-High Beam......... (HB3A) 9005XS
Front Park/Turn......................3157AK
Fog Light....................... (H10U)9145
Front Sidemarker.......................2886X
Center Stop Light.......... 16LED(notserviceable)
Rear Tail/Stop..........................3157
Rear Tail Light.......................... 194
Rear Marker Light........................ 194
Back up Light..........................3157
Rear Turn Light.......................3457AK
License................................ 168
NOTE:You will note that upon turning the (HID) High
Intensity Discharge Headlamp Bulbs on, there is a blue
hue to the lamps. This diminishes and becomes more
white after approximately 10 seconds as the system
charges.
MAINTAINING YOUR VEHICLE 211
7

Exterior Light Bulbs — Coupe Models
Headlight-Low/High Beam.... Servicedatdealer only
Aux. Headlight-High Beam.........(HB3A) 9005XS
Front Park/Turn......................3157AK
Fog Light.......................(H10 U) 9145
Front Sidemarker.......................2886X
Center Stop Light.......... 16LED(not serviceable)
Rear Tail/Stop/Turn.....................3157
Rear Marker Light........................ 194
Back up Light..........................3157
License................................ 168
Rear Compartment Light................... 168
NOTE:You will note that upon turning the (HID) High
Intensity Discharge Headlamp Bulbs on, there is a blue
hue to the lamps. This diminishes and becomes more
white after approximately 10 seconds as the system
charges.
EXTERIOR LIGHT BULB SERVICE
Headlight, Parking, Front Park, Turn Signal, Front
Sidemarker and Front Fog Light Removal
1. Remove the splash shield.
212 MAINTAINING YOUR VEHICLE

2. Twist off sockets counter-clockwise and pull out bulbs
from the socket, install the new bulbs, and reinstall the
bulb and socket assembly. Replace the splash shield.
NOTE:On vehicles equipped with High Intensity Dis-
charge Headlights (HID), when the headlights are turned
on there is a blue hue to the lights. This diminishes and
becomes more white after approximately 10 seconds, as
the system charges.
MAINTAINING YOUR VEHICLE 213
7

High Intensity Discharge Headlights (HID)
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
NOTE:If High Intensity Discharge (HID) lights are not
working, recycle the headlight switch 4 times to see if it
will restrike.
Tail, Tail/Stop, and Marker Lamp Bulb
Replacement
1. Open the trunk. Remove two access panel fasteners.
Remove the access panel.
214 MAINTAINING YOUR VEHICLE

2. Twist sockets counter-clockwise to pull out bulbs.
Replace tail, tail/stop, or marker lamp bulb.
3. Reinstall the appropriate bulb and socket assembly.
Replace the access panel. Close the trunk.Backup and Rear Turn Signal Lamp Bulb
Replacement
1. Open the trunk. Remove two access panel fasteners.
Remove the access panel.
MAINTAINING YOUR VEHICLE 215
7

2. Remove three plastic nuts from the upper lamp assem-
bly.
216 MAINTAINING YOUR VEHICLE

3. Twist sockets of the three bulbs shown counter-
clockwise. Disconnect bulb and socket assemblies from
the upper lamp assembly. Pull the upper lamp assembly
clear in order to access backup and rear turn signal lamp
bulbs.4. Replace the backup or rear turn signal lamp bulb.
Reinstall the appropriate bulb and socket assembly. Re-
install the three bulb and socket assemblies in the upper
lamp assembly. Reinstall the upper lamp assembly. Re-
place the access panel. Close the trunk.
MAINTAINING YOUR VEHICLE 217
7

License Plate Light
Twist off sockets counter-clockwise and pull out bulbs.
Replace as required.
218 MAINTAINING YOUR VEHICLE

Headlight Aiming
The headlights on your new Viper were aimed at the
factory. The factory setting was made at a no load setting.
A great increase in weight will change the aiming and it
may be necessary to readjust the headlights if you
typically carry an excessive amount of weight in the rear
compartment or otherwise suspect misalignment.
Aiming Check
Each headlight assembly can be adjusted up and down
only. No left to right adjustment is necessary. To check,
proceed as follows:
1. Fill the fuel tank and park the vehicle on level ground.
A driveway is not normally level. If in doubt and you
have no way to check levelness, do not attempt to adjust
the headlights.2. Mark the position of the headlights on a wall prior to
loading the vehicle. Load the rear compartment with the
items you normally carry. Have someone sit in the
driver’s seat who is about the same weight as the person
who drives the vehicle.
3. Push down on the front and rear of the vehicle several
times to make sure that the suspension has settled.
4. Then readjust the headlights to the original position.
NOTE:If any further adjustments are necessary, contact
your dealership.
MAINTAINING YOUR VEHICLE 219
7

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (approximate)
8.3 Liter Engine (Premium 91
Octane)18.2 gallons 68.9 liters
Engine Oil-With Filter
8.3 Liter Engines (SAE 0W-40) 10 qts. 9.5 Liters
Cooling System *
8.3 Liter Engines* (Mopar
Antifreeze/Coolant 5 Year/
102,000 Mile Formula) or
equivalent.16 qts. 15 Liters
* Includes heater and coolant recovery bottle filled to
MAX level.
