ENGINE
GENERAL INFORMATION 1.2 8V 69 HP 1.2 8V 69 HP LPG
0.9 TwinAir 85 HP(*)
Engine code 169A4000 169A4000 312A2000
Cycle Otto Otto Otto
Number and position of cylinders 4 in line 4 in line 2 in line
Piston bore and stroke (mm) 70.8 × 78.86 70.8 × 78.86 80.5 × 86.0
Total displacement (cm³) 1242 1242 875
Compression ratio 11.1 : 1 11.1 : 1 10 ± 0.2 : 1
LPG Petrol
Maximum power (EC) (kW) 51 51 51 62.5
Maximum power (EEC) (HP) 69 69 69 85
corresponding engine speed (rpm) 5500 5500 5500 5500
Maximum torque (EEC) (Nm) 102 102 102 145
Maximum torque (EEC) (kgm) 10.4 10.4 10.4 14.8
corresponding engine speed (rpm) 3000 3000 3000 1900
Spark plugsNGK ZKR7A-10 /
Champion RA8MCX4NGK ZKR7A-8 NGK LKR9EI-8
FuelUnleaded petrol 95
R.O.N. (EN228
specifications)LPG for motor
vehiclesUnleaded petrol 95
R.O.N. (EN228
specifications)Unleaded petrol 95
R.O.N. (EN228
specifications)
(*) For versions/markets, where provided
