Page 321 of 438

FIAT 500C 2015 2.G Owners Manual CAUTION!
The winch mechanism is designed for use with the
jack wrench tool only. Use of an air wrench or other
power tools is not recommended and they can dam-
age the winch.
3. Pull the spare tire ou

Page 322 of 438

FIAT 500C 2015 2.G Owners Manual 4. Tilt the retainer at the end of the cable and pull itthrough the center of the wheel.
Preparations For Jacking
1. Park the vehicle on a firm level surface, avoiding ice orslippery areas.
WARNING!
D

Page 323 of 438

FIAT 500C 2015 2.G Owners Manual NOTE:Passengers should not remain in the vehicle
while the vehicle is being jacked.
Jacking Instructions
WARNING!
Carefully follow these tire changing warnings to
help prevent personal injury or damag

Page 324 of 438

FIAT 500C 2015 2.G Owners Manual NOTE:Refer to the “Compact Spare Tire” section of the
“Tires-General Information” under “Starting And Oper-
ating” for information about the spare tire, it’s use, and
operation.
CAUTION!

Page 325 of 438

FIAT 500C 2015 2.G Owners Manual 3. Loosen, but do not remove, the wheel bolts by turningthem to the left one turn while the wheel is still on the
ground.
NOTE: There are front and rear jacking locations on each
side of the body (as

Page 326 of 438

FIAT 500C 2015 2.G Owners Manual Do not raise the vehicle until you are sure the jack is
securely engaged.
4. Turn the jack screw to the left until the jack can beplaced under the jacking location. Once the jack is
positioned, turn t

Page 327 of 438

FIAT 500C 2015 2.G Owners Manual 5. Using the swivel wrench, raise the vehicle by turningthe jack screw to the right. Raise the vehicle only until
the tire just clears the surface and enough clearance is
obtained to install the spare

Page 328 of 438

FIAT 500C 2015 2.G Owners Manual 9. Finish tightening the wheel bolts. Push down on thewrench while at the end of the handle for increased
leverage. Tighten the wheel bolts in a star pattern until
each bolt has been tightened twice.

Page 329 of 438

FIAT 500C 2015 2.G Owners Manual Road Tire Installation
Vehicles Equipped With Wheel Covers
1. Mount the road tire on the axle.
2. Align the valve notch in the wheel cover with thevalve stem on the wheel. Install the cover by hand. D

Page 330 of 438

FIAT 500C 2015 2.G Owners Manual 3. Install the four wheel bolts with the cone shaped endof the nut toward the wheel. Lightly tighten the wheel
bolts.
WARNING!
To avoid the risk of forcing the vehicle off the jack,
do not tighten the
