3. Once finished with registration you will be directed toyour 500e owner ’s site.
4. From the 500e owner ’s site you will be able to down- load the 500e Uconnect Access mobile application and
learn how to use your connected features.
5. Use your owner ’s site username and password for logging into the 500e Uconnect Access mobile appli-
cation.
NOTE: Your smartphone must have a valid data connec-
tion to use the 500e Uconnect Access mobile application.
Need help with registration?
Please call the Uconnect Call Center Toll Free number
below:
(855) 792-4241ELECTRIC SYSTEM OPERATION
Level 1 Charging
(120V — Requires NEMA 5–15 Outlet)
Level 1 charging is done by using a conventional 120 Volt
AC grounded receptacle along with the NEMA 5–15
Electric Vehicle Supply Equipment (EVSE) that comes
standard with your vehicle. Refer to “Vehicle Charging
Cord” for further information.
Level 2 Charging
(240V — Requires A 40 Amp Circuit Breaker Or
Greater)
Level 2 charging is accomplished by using 240V perma-
nently mounted EVSEs and is the preferred method for
charging your vehicle.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19

A Level 2 charging station can be installed at your
residence. The Level 2 unit and installation service is
available for purchase at your authorized dealer.
Charge Times
The following factors determine the time it takes to
charge the high voltage battery:•
The high voltage battery’s current state of charge
• What level EVSE is being used (Level 1 – 120V or Level
2 – 240V)
• Ambient temperature
NOTE:
• The charging times are estimates based on a com-
pletely discharged high voltage battery.
• Charging times will vary based on the age, condition,
state of charge and temperature of the high voltage
battery.
Type of Charge Estimated Charge Time
Level 1 (120V/15A) Approximately 23 hours
Level 2 (240V/30A) Approximately 4 hours
Level 2 Charging Station
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Vehicle Charge Cord
Your vehicle comes equipped with a standard AC 120V
NEMA 5-15 Electric Vehicle Supply Equipment (EVSE)
also referred to as a charge cord.
The EVSE plugs into any standard AC grounded outlet
and is used to charge the high voltage battery. To access
the charge cord, lift the rear cargo cover and remove the
charging cord from the storage bin.NOTE:The EVSE charge cord is used for Level 1
charging only.
EVSE Location
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21

SAE J1772 Charge Receptacle
Your vehicle uses an industry standard SAE J1772 charge
receptacle (vehicle’s inlet) for both AC Level 1 (120V) and
AC Level 2 (240V) charging.NOTE:The charge receptacle door locks and unlocks
with the vehicle doors.
SAE J1772 Charge Receptacle
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

EVSE Operation And Status Information
IndicatorDescription
1 — AC Indicator LED Green indicates READY
RED Indicates a fault
Indicator Description
2 — Fault Indicator LED Green indicates READY
RED indicates a fault
3 — Charge Level Indicator LED’s All ON indicates system ready
and not charging
LED’s turning on and off in sequence indicates vehicle charging
When the EVSE is first plugged in it will go through an
initialization and self test. For the first three seconds after
plugging in your EVSE all the LED’s will remain off.
After approximately three seconds the EVSE performs an
internal self test and Ground Continuity Test. This pro-
cess takes approximately 6 seconds.
During the internal self test the unit turns on one Charge
Level Indicator LED every 1.5 seconds until all the
Charge Level Indicator LED’s are illuminated.
EVSE Status Indicators
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23

AC
LED Fault
Indica-
tor LED Charge Level Indicator
LED’s Time
••• ooo1.5
sec
•••• o o 3.0
sec
••••• o 4.5
sec
• • •••• 6.0
sec
If the self test is successful the AC LED, the Fault
Indicator LED and the four Charge Level LED’s will turn
solid green.
The EVSE LED’s will be used to indicate the vehicle’s
connection status if no faults are found during the self
test.AC LED Fault In-
dicator LED Charge Level Indicator
LED’s
••••••
After the EVSE is connected to the vehicle’s charge inlet
the EVSE will continue to illuminate all LED’s green.
Once the vehicle begins charging the EVSE Charge level
LED’s will illuminate in order from left to right, then shut
off. This pattern will repeat as long as the EVSE remains
connected to AC power and the vehicle is actively
charging. Completion of charge will result in illuminat-
ing all LED’s green. If the vehicle stops charging, the LED
pattern will stop.
The LED’s are illuminated and turn off at the rate of one
change per second and the battery is charging.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

AC
LED Fault
Indica-
tor LED Charge Level Indicator
LED’s Time
••• ooo1.0
sec
•••• o o 2.0
sec
••••• o 3.0
sec
• • •••• 4.0
sec
Refer to the Level 1 User Manual for any additional
information on its use or operation.
Charging The High Voltage Battery
1. Put the vehicle in PARK.
2. Turn the ignition to the OFF position. 3. Remove the Level 1 EVSE from its storage bin by
lifting the rear cargo cover.
4. Uncoil the entire length of the EVSE (charge cord).
EVSE Location
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25

5. Plug the EVSE into a standard 120V AC outlet that isproperly grounded. It is recommended that the EVSE
is connected to an AC outlet on a circuit which is not
electrically loaded by other devices. Extension cords
may not be used.
NOTE: All of the EVSE LED’s illuminate green.
6. Open the charge receptacle door.
NOTE: The charge receptacle door is locked whenever
the vehicle is locked. Unlock the doors to unlock the
charge receptacle door for charging.
7. Plug the EVSE into the charge receptacle. Push the EVSE in firmly until it is completely engaged (if not
completely engaged the vehicle may not charge). NOTE:
•The vehicle will initiate the charging cycle automati-
cally when all the conditions are satisfied.
• The vehicle charge indicator will show the pattern
for charging.
EVSE Charge Coupler
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

8. When charging is complete, or the vehicle needs to beunplugged, remove the EVSE by pushing the button
on the charge connector and pull firmly to remove it
from the charge receptacle. 9. Close the charge receptacle door.
Charge Indicator
Charge Receptacle Door
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27

NOTE:
•In the event of an error in the charging process, the AC
power to the vehicle will stop and a red indicator will
illuminate on the EVSE.
• Keep the door for the charge receptacle closed when
not in use.
Vehicle Charge Indicators
Instrument Cluster High Voltage Battery Gauge
There is a battery gauge indicator located on the instru-
ment cluster. The battery gauge will display, with pro-
gressive color indication, the current state of charge for
the high voltage battery; with the percentage value
located at the bottom of the gauge. Charge Low And Limited Power Messages
The state of charge is monitored during normal opera-
tion. If the state of charge reaches certain thresholds the
following messages will also be displayed on the cluster:
High Voltage Battery Gauge
