automatic transmission fluid FIAT 500E 2018 Owners Manual

E-Park is activated when the driver pushes the PARK
button. An electric motor activates the parking pawl and
locks the single-speed transmission when the vehicle is
placed into PARK. This will prevent any unwanted move-
ment of the vehicle.
NOTE:The engagement of the E-Park can be heard when
there is no noise in the interior of the vehicle, this is a
normal condition.
Climate Control (HVAC System)
Your 500e is equipped with an Automatic Temperature
Control (ATC) HVAC system. This HVAC system utilizes a
humidity sensor, cabin sensor, and ambient temperature
sensor to choose operation mode and control cabin com-
fort. These components allow the controller to operate the
HVAC system in a very efficient manner to maximize
driving range.
Your 500e also uses an electric air heater to provide heat to
the cabin.
Electric Air Conditioning Compressor
Your 500e uses an electric air conditioning compressor. The
air conditioning compressor is powered by the high volt-
age battery system and is used to cool the vehicle occu-
pants and the high voltage battery while the vehicle is
being driven or when it is being charged.
The high voltage battery may require cooling to keep the
vehicle running. The air conditioning compressor activates
without any input from the occupant.
NOTE: The AC system helps cool the high voltage battery.
If the air conditioning system should require service, see an
authorized dealer as soon as possible.
Electric Power Steering
Your vehicle is equipped with an Electric Power Steering
(EPS) system. The power steering system requires no
maintenance and operates without the use of power steer-
ing fluid.
3
GETTING TO KNOW YOUR VEHICLE 19

Shallow Standing Water
Although your vehicle is capable of driving through shal-
low standing water, consider the following Caution and
Warning before doing so.
CAUTION!
•Always check the depth of the standing water before
driving through it. Never drive through standing
water that is deeper than the bottom of the tire rims
mounted on the vehicle.
• Determine the condition of the road or the path that
is under water and if there are any obstacles in the
way before driving through the standing water.
• Do not exceed 5 mph (8 km/h) when driving through
standing water. This will minimize wave effects.
• Driving through standing water may cause damage
to your vehicle’s drivetrain components. Always in-
spect your vehicle’s fluids (i.e., transmission, coolant,
etc.) for signs of contamination (i.e., fluid that is
milky or foamy in appearance) after driving through
standing water. Do not continue to operate the ve-
hicle if any fluid appears contaminated, as this may
(Continued)
CAUTION! (Continued)
result in further damage. Such damage is not covered
by the New Vehicle Limited Warranty.
• Driving through standing water limits your vehicle’s
traction capabilities. Do not exceed 5 mph (8 km/h)
when driving through standing water.
• Driving through standing water limits your vehicle’s
braking capabilities, which increases stopping dis-
tances. Therefore, after driving through standing
water, drive slowly and lightly press on the brake
pedal several times to dry the brakes.
• Failure to follow these warnings may result in inju-
ries that are serious or fatal to you, your passengers,
and others around you.
EXTENDING YOUR DRIVING RANGE PER CHARGE
The drive system and cabin temperature management
features use the most energy from the high voltage battery.
Reducing energy draw from these features are the easiest
and most effective way to extend driving range.
The 500e uses high voltage components to heat and cool
the cabin, so when using automatic climate control, con-
sider setting temperatures a few degrees higher or lower
during hot and cold days. If your 500e has been soaking in
6
STARTING AND OPERATING 175

Adding Washer Fluid........................217
AirBag ................................ .122
Advance Front Air Bag ....................122
Air Bag Operation ........................124
Air Bag Warning Light .....................121
Driver Knee Air Bag ..................... .125
Enhanced Accident Response .............130, 212
Event Data Recorder (EDR) .................212
FrontAirBag .......................... .122
If Deployment Occurs .....................129
Knee Impact Bolsters ..................... .124
Maintaining Your Air Bag System .............131
Maintenance ............................131
Side Air Bags .......................... .125
Transporting Pets ........................148
Air Bag Light .......................90, 121, 149
Air Conditioner Maintenance ..................224
Air Conditioning Filter .......................71
Air Conditioning, Operating Tips ................70
Air Conditioning Refrigerant ..................224
Air Conditioning System .....................224
Air Pressure Tires................................. .237
Alarm Security Alarm ...........................41 Alarm System
Security Alarm ...........................41
Alterations/Modifications, Vehicle ................5
Anti-Lock Brake System (ABS) .................100
Anti-Lock Warning Light .................93, 96, 97
Arming System Security Alarm ...........................41
Audio Systems (Radio) .......................262
Automatic Dimming Mirror ....................54
Automatic Transmission ..................... .157
Gear Ranges ............................159
Battery ...............................92, 218
Charging ...............................16
Charging System Light .....................92
Belts, Seat ............................... .149
Body Mechanism Lubrication ..................225
B-Pillar Location .......................... .232
Brake

Assist System ........................ .101
Brake Fluid ...............................259
Brake, Parking ............................ .156
Brake System ............................ .227
Anti-Lock (ABS) ........................ .100
Fluid Check ............................227
Master Cylinder ........................ .227
290 INDEX

Sun Roof.................................73
Supplemental Restraint System - Air Bag ..........122
Telescoping Steering Column ...................53
Temperature Control, Automatic (ATC) ............69
Tilt Steering Column .........................53
Time Delay Headlight ...............................56
Tire And Loading Information Placard ............232
Tire Markings ............................ .229
Tires......................... .151, 236, 243, 249
Aging (Life Of Tires) ..................... .240
Air Pressure ............................236
Chains ............................... .247
Changing ............................. .228
Compact Spare ..........................244
General Information ...................236, 243
High Speed ............................ .238
Inflation Pressure ........................237
Jacking ............................... .228
Life Of Tires ............................240
Load Capacity .......................232, 233
Pressure Monitoring System (TPMS) ............94
Quality Grading ........................ .249
Radial ............................... .238
Replacement ............................241 Rotation
...............................248
Safety ............................ .229, 236
Snow Tires ............................ .243
Spare Tires ..........................243, 245
Spinning ...............................239
Tread Wear Indicators .....................239
Wheel Nut Torque ........................257
Tire Safety Information .......................229
Tire Service Kit ...........190, 191, 193, 194, 196, 197,
198, 199, 200, 201, 204, 205
To Open Hood .............................76
Towing ................................. .172
Disabled Vehicle .........................211
Recreational ............................173
T owing

Behind A Motorhome ..................173
Traction ............................. .173, 174
Traction Control .......................... .101
Trailer Towing ............................ .172
Transmission Automatic ............................ .157
Fluid .................................259
Transporting Pets ..........................148
Tread Wear Indicators .......................239
Turn Signals ..........................56, 58, 97
12
INDEX 297
