compression ratio FIAT 500L 2018 Owner handbook (in English)

ENGINE
Versions 0.9 TwinAir Turbo Natural Power 0.9 TwinAir Turbo 105HP
Type code 312A2000 199B6000
Cycle Otto Otto
Number and position of cylinders 2 in line 2 in line
Piston bore and stroke (mm) 80.5 × 86.0 80.5 × 86.0
Total displacement (cm³) 875 875
Compression ratio 10 ± 0.2 10 ± 0.2
METHANE PETROL
Maximum power (EEC) (kW) 59 62.5 77
72
(*)
Maximum power (EEC) (HP) 80 85 105
98(*)
corresponding engine speed (rpm) 5500 5500 5500
5750(*)
Maximum torque (EEC) (Nm) 145 145 145
120(*)
Maximum torque (EEC) (kgm) 14.8 14.8 14.8
12.2(*)
corresponding engine speed (rpm) 2500 2000 2000
1750(*)
Spark plugs NGK ILKR9G8 or NGK ILKR9H8 NGK ILKR9G8
FuelMethane for motor
vehiclesUnleaded petrol 95
R.O.N. (EN228
specifications)Unleaded petrol 95 R.O.N. (EN228
specifications)
Emission level Euro 6 Euro 6
(*) Engine data with ECO button pressed
176
TECHNICAL DATA

Versions 1.4 16V 95 HP 1.4 16V 120HP 1.4 16V 120 HP LPG
Type code 843A1000 940B7000 940B7000
Cycle Otto Otto Otto
Number and position of cylinders 4 in line 4 in line 4 in line
Piston bore and stroke (mm) 72.0 × 84.0 72.0 × 84.0 72.0 × 84.0
Total displacement (cm³) 1368 1368 1368
Compression ratio 11 ± 0.2 9.8 ± 0.2 9.8 ± 0.2
LPG PETROL
Maximum power (EEC) (kW) 70 88 88 88
Maximum power (EEC) (HP) 95 120 120 120
corresponding engine speed (rpm) 6000 5000 5000 5000
Maximum torque (EEC) (Nm) 127 215 215 215
Maximum torque (EEC) (kgm) 12.9 22 22 22
corresponding engine speed (rpm) 4500 2500 2500 2500
Spark plugs NGK DCPR7E-N-10 NGK IKR9J8 NGK IKR9J8
FuelUnleaded petrol 95
R.O.N. (EN228
specifications)Unleaded petrol 95
R.O.N. (EN228
specifications)LPG for motor
vehicles (EN589
Specification)Unleaded petrol 95
R.O.N. (EN228
specifications)
Emission level Euro 6 Euro 6 Euro 6
177

Versions 1.3 16V 85HP Multijet 1.3 16V 95HP Multijet
Type code 199B4000 330A1000
Cycle Diesel Diesel
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 69.6 × 82.0 69.6 × 82.0
Total displacement (cm³) 1248 1248
Compression ratio 16.8 ± 0.4 16.8 ± 0.4
Maximum power (EEC) (kW) 62 70
Maximum power (EEC) (HP) 85 95
corresponding engine speed (rpm) 3500 3750
Maximum torque (EEC) (Nm) 200 215
Maximum torque (EEC) (kgm) 20.4 21.9
corresponding engine speed (rpm) 1500 1500
FuelDiesel for motor vehicles (EN590
Specification)Diesel for motor vehicles (EN590
Specification)
Emission level Euro 5 Euro 6
178
TECHNICAL DATA

Versions 1.6 16V 120 HP MultiJet
Type code940C1000
CycleDiesel
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 79.5 × 80.5
Total displacement (cm³) 1598
Compression ratio 16.5 ± 0.4
Maximum power (EEC) (kW) 88
Maximum power (EEC) (HP) 120
corresponding engine speed (rpm) 3750
Maximum torque (EEC) (Nm) 320
Maximum torque (EEC) (kgm) 32.6
corresponding engine speed (rpm) 1750
Fuel Diesel for motor vehicles (EN590 Specification)
Emission levelEuro 6
179
