key FIAT 500L 2019 Owner handbook (in English)

WINDSCREEN
WIPER/REAR
WINDOW WIPER
WINDSCREEN WIPER /
WASHER
6) 7)
This operates only with the ignition key
turned to MAR.
Ring A fig. 31 has five different
positions:
windscreen wiper off
constant flick with 10 second
periods
“faster” flick (speed related)
LOcontinuous slow operation
HIcontinuous fast operation
MIST functionMove the stalk upwards (unstable
position) to activate the MIST
function: operation is limited to the
time for which the stalk is held in this
position. When released, the stalk
will return to its default position and the
windscreen wiper will be stopped.
This function is useful to remove small
deposits of dust from the windscreen,
or morning dew.
“Smart washing” function
Pull the stalk towards the steering
wheel (unstable position) to operate the
windscreen washer. When the stalk is
held pulled for longer than half a
second, the windscreen wiper is moved
with active control.
The wipers flick three times when the
stalk is released, after which, if the
control is in position
, the washing
cycle is concluded by one last flick after
a pause of approximately 6 seconds.
With the ring inLOorHIposition,
the smart washing function is not
carried out.
Raising the blades ("Service
position" function)
This function makes it possible to
replace the blades or protect them in
conditions of ice and/or snow.Function activation
turn the ring A to position(wiper
stopped);
turn the ignition key to the STOP
position;
after having turned the ignition key
to the STOP position, within two
minutes move the lever to the MIST
within two minutes for at least half a
second to activate the wiper for part
of a flick. This operation can be
repeated up to three times, in order to
move the blade to the most suitable
position for replacement;
turn the ignition key to the MAR
position to move the blades back
down.
The function will be deactivated when
the engine is started again, in case of a
wiping request or with the car moving
(speed above 5 km/h).
IMPORTANT Place the blades back in
contact with the windscreen before
activating the windscreen wiper again
and/or turning the ignition key to
MAR-ON.
IMPORTANT Before activating the
function, make sure, when starting the
engine, that the windscreen is free of
snow or ice.
31F0Y0608C
28
KNOWING YOUR CAR

RAIN SENSOR
(for versions/markets, where provided)
22)8) 9)
This is located behind the rear-view
mirror in contact with the windscreen.
The sensor is activated with ignition key
turned to the MAR position, while it is
deactivated with the key turned to
STOP position.
The sensor can measure the amount of
rain and, consequently, manage the
automatic wiping mode of the
windscreen in accordance with the
amount of water on the screen (see the
“Automatic Wiping” paragraph).
AUTOMATIC WIPING
Activation
Go to the “Settings” menu of the
Uconnect™system (for more
information see the supplement
available online) and turn the ring A to
position
or.
Inhibition
If the ignition key is turned to STOP,
leaving the ring A in position
or,
when the engine is next started (ignition
device at MAR), no wiping cycle
occurs for system protection reasons.Deactivation
Go to the “Settings” menu of the
Uconnect™system (for more
information see the supplement
available online) and turn the ring A to a
position other than intermittent (
or
).
REAR WINDOW WIPER /
WASHER
10)
This operates only with the ignition key
turned to MAR.
The ring B fig. 32 can be set to the
following positions:
rear window wiper stopped
intermittent operation
continuous operation, without
pausing between two strokes.The rear window wiper can be
activated in the following ways:
intermittent(with a two-second
pause between two flicks), when ring B
is in position
and the windscreen
wiper is not in operation;
synchronous(half frequency as
the windscreen wiper), when ring B is in
position
and the wiper is working or
when ring B is in position
, reverse
gear is engaged and the windscreen
wiper is working;
continuouswhen ring nut B is in
position
or when reverse gear is
engaged.
Push the stalk towards the dashboard
(rocking position) to activate the rear
window washer jet. Keep pushing the
lever to automatically activate both
the rear window washer jet and the rear
window wiper with a single movement.
Releasing the stalk will activate three
strokes, as described for the
windscreen wiper. If the position is
(rear window wiper stopped), after a
6 second pause, the washing cycle
is completed by a single stroke. The
smart wash cycle will not be performed
if the ring B is in position
.
If washer lasting longer than 30
seconds is needed, the washing cycle
will be inhibited as described in the
“Smart washing” paragraph.
32F0Y0655C
29

WARNING
22)Make sure the device is switched off
whenever the windscreen must be
cleaned.
WARNING
6)Do not use the windscreen wiper to
remove layers of snow or ice from the
windscreen. In such conditions, the
windscreen wiper may be subjected to
excessive stress and the motor cut-out
switch, which prevents operation for a few
seconds, may intervene. If operation is
not restored (even after turning the key and
restarting the engine), contact a Fiat
Dealership.
7)Do not operate the windscreen wiper
with the blades lifted from the windscreen.
8)Do not activate the rain sensor when
washing the car in an automatic car wash.
9)Make sure the device is switched off if
there is ice on the windscreen.
10)Do not use the rear window wiper to
remove layers of snow or ice. In such
conditions, the screen wiper may be
subjected to excessive stress and the
motor cut-out switch, which prevents
operation for a few seconds, may
intervene. If operation is not restored,
contact a Fiat Dealership.
FIXED GLASS ROOF
(for versions/markets, where provided)
SUN BLIND
The sun blind operates only with the
ignition key turned to MAR. From the
fully closed position press button A fig.
33 for more than half a second: the
blind will move to the fully open
position.
From the fully open position press
button A for more than half a second:
the blind will move to the fully closed
position.
Button A can be pressed in jog mode
to open or close the blind manually.EMERGENCY OPERATION
If the control button does not work, to
move the sun blind manually, remove
the protective cap A fig. 34 on the
internal trim, take the Allen key B
provided (located in the tool box or,
depending on the version, in the
Fix&Go Automatic container in the
luggage compartment), insert it in
housing A and turn it clockwise to open
the blind or anticlockwise to close it.
SUN BLIND
INITIALISATION
Following an automatic movement
malfunction while opening/closing or
after an emergency manoeuvre (see
description in the previous paragraph),
the automatic operation of the sun
curtain must be initialised again.
33F0Y0121C34F0Y0285C
30
KNOWING YOUR CAR

Proceed as follows:
turn the ignition key from the STOP
position to the MAR position;
hold down button Afig. 33: after
approximately 10 seconds the curtain
moves jerkily to closing position. When
the movement stops (blind closed),
release button A (if the blind is already
closed, you will hear the mechanical
lock only);
press button A again within 3
seconds after the blind reached the fully
closed position;
hold down button A: the blind will
perform an automatic opening and
closing cycle. Should this not occur,
repeat the operation from the
beginning;
hold down button A until the blind is
completely closed: the initialisation
procedure has ended.
ELECTRIC SUNROOF
(for versions/markets, where provided)
23)11)
The sun roof and the blind can be
operated only with the ignition
key turned to MAR.
CONTROL BUTTONS
Opening/closing the front glass
panel
Opening
Press button A fig. 35 to open the sun
roof in the “spoiler” position. After
opening in “spoiler” position, press
button A once again for more than half
a second to bring the roof automatically
to fully open position. To deactivate
the automatic movement press the
button again. Use button A in jog mode
to open the sun roof manually.Closing
From the fully open position press
button A for more than half a second:
the front glass panel will move into
the “spoiler” position. Use button A in
jog mode to close the sun roof
manually.
Sun blind movement
Pressing the B fig. 35 button will move
the blind towards the rear part of the
vehicle, until it is fully open. With blind
fully open press button B: the blind
will move towards the front part of the
vehicle, until it is fully closed. During the
blind automatic opening and closing
stages, press the button again to
interrupt the blind movement.
Button B can be pressed in jog mode
to open or close the blind manually.
EMERGENCY OPERATION
If the control buttons fail to operate, the
sunshade and the sunroof can be
moved manually proceeding as
described below:
Sun blind movement: remove
protective cap A fig. 36 on the internal
trim;
Sunroof movement: remove
protective cap B on the internal trim;
35F0Y0120C
31

take Allen key C fig. 36 from the tool
box or, depending on the version,
from the Fix&Go Automatic container,
insert it in housing A (for blind
movement) or B (for sun roof
movement) and turn it clockwise to
open the roof (or the blind) or
anticlockwise to close the roof (or the
blind).
SUN ROOF
INITIALISATION
Following an automatic movement
malfunction while opening/closing or
after an emergency manoeuvre (see
description in the previous paragraph),
the automatic operation of the sunroof
must be initialised again.
Proceed as follows
turn the ignition key from the STOP
position to the MAR position;
hold down button A fig. 35: after
approximately 10 seconds the roof
moves jerkily to closing position. When
the movement stops (closed roof),
release button A (if the roof is already
closed, you will hear the mechanical
lock only);
press button A again within 5
seconds after the blind reached the fully
closed position;
hold down button A: the roof will
perform an automatic opening and
closing cycle. Should this not occur,
repeat the operation from the
beginning;
hold down button A until the roof is
completely closed: the initialisation
procedure has ended.
WARNING
23)When leaving the vehicle, always
remove the key from the ignition to avoid
the risk of injury to those still inside the
vehicle due to accidental operation of the
sun roof. Improper use of the roof can
be dangerous. Before and during
operation, always check that no one is
exposed to the risk of being injured by the
moving sun roof or by objects getting
caught or hit by it.
WARNING
11)Do not open the sunroof if a transverse
roof rack is fitted. Do not open the sunroof
if there is snow or ice on it: you may
damage it.
36F0Y0234C
32
KNOWING YOUR CAR

DOORS
DOOR CENTRAL
LOCKING/UNLOCKING
Locking from the outside
With doors closed, press the
button
on the remote control or turn the metal
insert (located inside the key) in the
driver side door lock. Door locking is
carried out with all doors shut,
irrespective of the luggage
compartment open/closed status.
Door unlocking from the outside
Press the
button on the remote
control or turn the metal insert (located
inside the key) in the driver side door
lock.
Door locking/unlocking from the
inside
Press the
button on the
dashboard.fig. 37
LED on button on: doors locked /
LED on button off: doors unlocked.
IMPORTANT With central locking
active, pulling the internal opening lever
of the passenger side door unlocks
the door (the LED stays on). Pulling the
internal opening lever of the driver
side door activates central unlocking.CHILD SAFETY DEVICE
24)
This system prevents the rear doors
from being opened from the inside. The
device B fig. 38 can be activated only
with the doors open.
Position 1: device on (door locked) /
Position 2: device off (door can be
opened from the inside).
The device remains engaged even if the
doors are electrically unlocked.
IMPORTANT The rear doors cannot be
opened from the inside when the child
safety device is engaged.PASSENGER SIDE FRONT
DOOR AND REAR DOOR
EMERGENCY LOCKING
DEVICE
12)
Used to lock the doors when there is
no electrical power supply. Insert the
metal insert of the ignition key in
position A fig. 39 (passenger side front
door) or A fig. 38 (rear doors) and
then turn the key clockwise and then
remove it from position A.
37F0Y0652C
38F0Y0111C
33

To restore the starting condition of the
door locks (only if battery charge
restored) press the
button on the
remote control or the
button on the
dashboard or introduce the metal insert
of the ignition key in the driver's side
front door pawl and pull the door inner
handle.
INITIALISING THE DOOR
OPENING / CLOSING
MECHANISM
If the battery is disconnected or the
protection fuse blows, the door
opening/closing mechanism must be
initialised as follows:
close all the doors;
press thebutton on the remote
control or the button on the dashboard;
press thebutton on the remote
control or the button on the dashboard.
WARNING
24)Always use this device when carrying
children. After engaging the child lock
on both rear doors, check for effective
engagement by trying to open a door with
the internal handle.
WARNING
12)If the child lock was engaged and the
previously described locking procedure
carried out, operating the internal opening
handle will not open the door: in this case,
to open the door, the outside handle
must be used. The door central locking/
unlocking button
is not disabled by the
engagement of the emergency lock.
ELECTRIC WINDOWS
25)
OPERATION
These operate when the ignition key is
turned to MAR-ON and for about 3
minutes after the ignition key is turned
to STOP or removed unless one of
the front doors is opened.
DRIVE SIDE FRONT
DOOR CONTROLS
Versions with 4 electric windows
The buttons are located on the door
panel trim fig. 40.
All windows can be controlled from the
driver side door panel.
A: front left window opening/
closing. "Automatic continuous"
operation during window opening/
closing and anti-pinch system
activated.
39F0Y0110C
40F0Y0240C
34
KNOWING YOUR CAR

B: right front window opening/
closing. "Automatic continuous"
operation during window opening/
closing and anti-pinch system
activated.
C: enabling/disabling of rear door
electric window controls.
D: rear left window opening/closing
(for versions/markets, where provided).
"Automatic continuous" operation
during window opening/closing and
anti-pinch system activated.
E: rear right window opening/
closing (for versions/markets, where
provided). "Automatic continuous"
operation during window
opening/closing and anti-pinch system
activated.
Window opening
Push the buttons to open the desired
window. When one of the two buttons
is pressed briefly, the window moves
in "stages"; if the button is held down,
"continuous automatic" operation is
activated. If the button is pressed
again, the window will stop in
the desired position.Window closing
Lift the buttons to close the desired
window. The window closing stage
occurs following the same logic
described for the opening stage.
Anti-crush safety device
(for versions/markets, where provided)
The anti-pinch function is active both
during manual and automatic operation
of the electric windows. When the
anti-crush system is activated
the window travel is immediately
interrupted and then reversed. The
window cannot be operated in any way
during this time.
ELECTRIC WINDOWS
INITIALIZATION
If power supply is interrupted when the
window is moving, the electric window
automatic operation must be
reinitialised. The initialisation procedure
must be carried out with the doors
closed (and for each door) as follows:
fully close the window to be
initialised, with manual operation;
after the window has reached the
upper end of travel, hold the up button
pressed for at least one second.
WARNING
25)Improper use of the electric windows
can be dangerous. Before and during
operation, always check that passengers
are not exposed to the risk of being injured
either directly by the moving windows or
through objects getting caught or struck by
them. When leaving the vehicle, always
remove the ignition key to avoid the risk of
injury for people still on board due to
accidental operation of the electric
windows.
35

LUGGAGE
COMPARTMENT
28) 29) 31)13)
The luggage compartment unlocking is
electrically operated and is deactivated
when the car is in motion.
OPENING
27)
When unlocked, the luggage
compartment can be opened from
outside the car using the electric
opening handle A fig. 44 located under
the handle until the unlocking click is
heard or by pressing the
button
on the remote control.Emergency opening from the inside
Proceed as follows:
remove the rear head restraints and
fully fold the seats;
take the screwdriver provided from
the tool box or the Fix&Go Automatic
container, depending on the version;
use the screwdriver to remove
the yellow tab A fig. 45;
then insert the screwdriver in
housing B fig. 46 in order to activate
the luggage compartment release tab.
CLOSING
Take hold of the handle on the inside of
the tailgate and lower it, pressing next
to the lock until it clicks.IMPORTANT Before closing the
luggage compartment make sure that
you have the keys, since the luggage
compartment is automatically locked.
LUGGAGE
COMPARTMENT
INITIALISATION
IMPORTANT If the battery is
disconnected or the protection fuse
blows, the luggage compartment
opening/closing mechanism must be
reinitialised as follows:
close all the doors and the luggage
compartment;
press thebutton on the remote
control;
press thebutton on the remote
control;44F0Y0610C
45F0Y0172C
46F0Y0173C
37

30)In the event of an accident or sharp
braking, any object placed on the curtain
may be projected backwards in the
passenger compartment, and risk to hurt
the occupants.
31)Abrupt braking or occasional impacts
may cause sudden movements of the load
with consequent situations of hazard for
the driver and passengers: before setting
off, secure the load tightly using the hooks
provided. For securing use cables, ropes
or belts strong enough to hold the items to
be secured.
WARNING
13)Before tilting the seat backrest fully,
remove any objects laid on it.
14)The dimensions of the platform permit
a maximum capacity of distributed weight
of 70 kg (in position 1) or 40 kg (in position
2): do not load objects with a higher
weight.
15)To avoid damaging the blind, do not
place heavy objects on it.
DUALDRIVE
ELECTRIC POWER
STEERING
(for versions/markets, where provided)
This only operates with the ignition
key turned to MAR and engine running.
Electric power steering allows the
force required at the steering wheel to
be adapted to the driving conditions.
IMPORTANT When turning the ignition
key quickly, full power steering
functionality can be achieved after a
few seconds.
IMPORTANT During parking
manoeuvres requiring a lot of steering,
the steering may become harder; this is
normal and is due to the intervention
of the system to protect the electric
steering motor from overheating. No
repair intervention is needed in this
case. When the car is used again, the
power steering will work normally again.IMPORTANT The Dualdrive electric
power steering provides an electronic
damping effect when approaching
the end of travel. In some manoeuvring
conditions, the steering wheel may
perform an additional small rotation until
reaching its mechanical stop. This
behaviour is normal and is intended to
prevent excessive impacts with the
mechanical components located inside
the device.
POWER STEERING
ACTIVATION/
DEACTIVATION
32) 33)
To engage/disengage the electric
power steering press button fig. 51.
The LED above the button switches on
to indicate that the system is active.
51F0Y0646C
39
