Page 12 of 246
11
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
KEY WITH REMOTE CONTROL
The key is fitted with a metal insert
A-fig. 9, operating:
❒the ignition switch
❒doors and tailgate locks
❒the fuel lid locking/unlocking
❒the safe lock device (only disengage-
ment - where provided)
fig. 9F0Q0327m
Button Ëfor remote unlocking of doors
and tailgate.
Button
Áfor remote locking of doors and
tailgate.
Button
Rfor remote opening of the tail-
gate. Button Bfor power-assisted open-
ing of the metal insert A.
To refit the metal insert into the key grip,
keep button Bpressed and turn the met-
al insert in the direction shown by the ar-
row until hearing the click as it locks into
place. Then release button B. Led C
(where provided) comes on when send-
ing the control to the alarm system re-
ceiver. To know the operating logics of
the key with remote control and every
possible and modifiable setting, see para-
graph “Alarm” in this section.If locking button
Áis inadver-
tently pressed from the pas-
senger compartment, when
getting out of the car only the doors
being used will unlock; the tailgate will
stay locked. To realign the system,
press again the locking/unlocking but-
tons
Á/Ë.
Button B-fig. 9 should only
be pressed when the key is
away from the body, in particular
from the eyes and from objects that
can be spoilt (e.g. clothes). Make sure
the key can never be touched by oth-
ers, especially children, who may in-
advertently press the button.
WARNING
001-022 BRAVO GB 10-05-2007 8:57 Pagina 11
Page 76 of 246
75
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
DOORS
CENTRAL DOOR LOCKING
SYSTEM
From outside
With the doors closed, fit and turn the key
in one of the front door locks.
From inside
From inside the car (with doors closed)
press the door lock/unlock button fig. 79
set on the dashboard.
Doors can however be closed manually
if the electric system is failing.
IMPORTANT The rear doors cannot be
opened from inside when the child lock
is engaged.CHILD LOCK fig. 80
To prevent opening the rear doors from
the inside.
This device can be engaged only with
doors open:
❒position 1- engaged (door locked);
❒position 2- disengaged (door can be
opened from the passenger’s compart-
ment).
The device stays on even if the doors are
unlocked by the centralised system.
fig. 79F0Q0641mfig. 80F0Q0677m
Always use this device when
transporting children.
After engaging the lock on
both rear doors, check by
trying to open a rear door with the in-
ternal handle.
WARNING
057-082 BRAVO GB 10-05-2007 9:09 Pagina 75
Page 77 of 246
76
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IMPORTANT Door locking/unlocking sys-
tem shall be re-initialised after discon-
necting the battery or if the relevant pro-
tection fuse is blown:
❒close all the doors;
❒press the key button Áor door
lock/unlock button ≈on the
instrument panel;
❒press the key button Ëor door
lock/unlock button ≈on the
instrument panel.
Do not activate the child
lock device and the rear
doors emergency lock device at the
same time. If both devices are on, to
open the door: operate the internal
handle to deactivate the rear doors
emergency lock device and then open
the door using the external handle.
WARNING
REAR DOORS EMERGENCY
LOCK DEVICE fig. 81
Rear doors are fitted with a device
enabling to close them also when cur-
rent is lacking.
In this event proceed as follows:
❒fit the metal insert of the ignition key
into slot A;
❒turn the key clockwise and then
remove it from slot A.
fig. 81F0Q0679m
To realign the lock knobs (only if battery
charge is restored) proceed as follows:
❒press the key button Ë;
❒press door lock/unlock button ≈
on the instrument panel;
❒opening with the key in front door
revolving plug;
❒pulling internal door handle.
IMPORTANT If the child lock and the rear
door emergency lock are active, operat-
ing the internal door handle will not open
the door but only realign the lock knobs;
to open the door: pull the external han-
dle. Door central locking/unlocking but-
ton ≈will not be disabled when acti-
vating the emergency lock.
057-082 BRAVO GB 10-05-2007 9:09 Pagina 76
Page 134 of 246
133
DASHBOARD
AND CONTROLS
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
SAFETY
DEVICES
CORRECT USE
OF THE CAR
PARKING
Proceed as follows:
❒ Stop the engine and engage the hand-
brake;
❒Engage a gear (first if the car is faced up-
hill or reverse if it is faced downhill) and
leave the wheels steered.
Block the wheels with a wedge or a stone
if the car is parked on a steep slope. Do
not leave the ignition key at MARto pre-
vent draining the battery. Always remove
the key when you leave the car.HANDBRAKE
The handbrake lever is located between
the two front seats.
Pull the handbrake lever upwards until the
car cannot be moved.
Four or five clicks are generally enough
when the car is on level ground while nine
or ten may be required if the car is on a
steep slope or laden.
IMPORTANT If this is not the case, con-
tact Fiat Dealership to have the handbrake
adjusted.
In cars fitted with front armrest, lift the
latter so that it does not hinder the hand-
brake engaging procedure.When the handbrake lever is pulled up
and the ignition key is at MAR, the in-
strument panel warning light
xwill turn
on.
To release the handbrake:
❒slightly lift the handbrake and press re-
lease button A-fig. 1;
❒keep button Apressed and lower the
lever. Warning light xwill turn off.
Press the brake pedal when carrying out
this operation to prevent the car from
moving accidentally.
fig. 1F0Q0628m
Never leave children unat-
tended in the car. Always re-
move the ignition key when leaving
the car and take it out with you.
WARNING
129-140 BRAVO GB 10-05-2007 9:16 Pagina 133
Page 238 of 246
237
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Car maintenance ............................ 191
– scheduled servicing ........................ 192
– service schedule ............................ 193
– heavy duty ....................................... 195
– routine maintenance .................... 195
Carrying children safely ..................... 112
Ceiling lights ......................................... 63
Central door locking system ............ 75
Checking fluid levels ............................ 196
Child locks ............................................ 75
Cigar lighter .......................................... 69
CO
2 emissions ..................................... 231
Code Card ............................................ 10
Containing running costs ................... 135
Controls ................................................ 65
Correct use of the car................. 129
Courtesy mirror light
(bulb replacement) ........................... 177
Cruise Control ................................... 61
Current outlet ..................................... 69
Dashboard ........................................... 5
Dashboard and controls .............. 4
Daylight sensor .................................... 56Diesel particulate filter (DPF) .......... 104
Dimensions ........................................... 224
Dipped beam headlights .................... 55
Direction indicators
– activation ......................................... 55
– bulbs replacement ................ 171-172
Doors
– child lock .......................................... 75
– rear doors emergency
lock device ...................................... 76
DPF (diesel particulate filter) ........... 104
Dualdrive
(electric power steering) ................ 94
Engine codes/Bodywork versions .. 216
Engine compartment (washing) ....... 210
Engine starting .............................. 130-156
EOBD system ....................................... 91
ESP system ............................................ 88
Exterior lights (replacement) ........... 170
External lights ....................................... 55
Fiat CODE system ............................. 8
Fix&Go automatic ............................... 163
Fluids and lubricants ........................... 228
ABS ........................................................ 86
Air bag
– front ................................................. 120
– side ................................................... 123
Air cleaner/Pollen filter ...................... 201
Alarm ...................................................... 16
Ashtray ................................................... 69
ASR system ........................................... 89
At the filling station ............................ 102
Automatic two-zone climate
control system .................................. 49
Battery ................................................... 79
– jump starting .................................. 156
– recharge .......................................... 188
– replacement .................................... 202
Bodywork .............................................. 208
– bodywork versions ....................... 216
Bonnet ..................................................... 83
Boot ........................................................ 79
Brake Assist ........................................... 87
Brakes ..................................................... 219
Capacities ............................................. 227
Car inactivity.......................................... 140
I I
N N
D D
E E
X X
237-244 BRAVO GB 10-05-2007 9:23 Pagina 237
Page 240 of 246
239
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Steering wheel ...................................... 40
Sun roof ................................................. 72
Sun visors .............................................. 71
Suspensions ........................................... 219
Symbols .................................................. 8
T.P.M.S. system .................................... 96
Technical specifications .............. 213
Third brake light
(bulb replacement) ........................... 174
Towing the car ..................................... 189
Towing trailers ..................................... 137
Transmission ........................................ 218
Trip Computer ................................... 35
Tyres
– replacement .................................... 157
– snow tyres ...................................... 139
– standard tyres ................................ 222
– tyre marking ................................... 220
– pressure ............................................ 223
Using the gearbox ............................. 134
Isofix child restraint system .............. 117
Warning lights and messages... 141
Weights ................................................. 226Wheel geometry ................................. 220
Wheels and tyres ....................... 204-220
When needing to change a bulb ...... 167
Window washing ................................. 57
Windows (cleaning) ............................ 210 Remote control: ministerial
homologations ................................... 232
Right hand drive versions............ 234
Rim marking .......................................... 221
Roof rack/ski rack ............................... 84
Rubber hoses ....................................... 205
Safe lock device .................................. 14
S.B.R system ......................................... 108
Safety devices................................... 105
Seat belts ............................................... 106
Seats ........................................................ 37
– cleaning ............................................ 210
– manual adjustment ........................ 37
– electrical adjustment .................... 38
– seat warming .................................. 38
Side lights
– activation ......................................... 55
– bulbs replacement ................ 171-172
Smart washing function ...................... 58
Snow chains .......................................... 139
Sound System ....................................... 92
Spark plugs ............................................ 217
Sport function ...................................... 95
Spray nozzles ........................................ 207
Steering .................................................. 219
Steering column lock .......................... 19
237-244 BRAVO GB 10-05-2007 9:23 Pagina 239
