Modifications or repairs
to the fuel system that
are not carried out prop-
erly or do not take the system
technical specifications into ac-
count can cause malfunctions
leading to the risk of fire. FUEL SUPPLY/IGNITION
Petrol versions
Electronic Multipoint sequential
phased injection integrated with igni-
tion, returnless system.FUEL FEED/IGNITION
Multijet versions
“Common Rail” electronic control
direct injection, turbo and intercool-
er.
SPARK PLUGS
The cleanness and soundness of the
spark plugs are very important for
keeping the engine efficient and pol-
luting emissions down.
The appearance of the spark plug, if
examined by an expert eyes, is a good
way of pinpointing a problem even if it
has nothing to do with the ignition sys-
tem. Therefore, if the engine has prob-
lems, it is important to have the spark
plugs checked at a Fiat Dealership.
The spark plugs must be
changed at the times
specified in the service
schedule. Only use the type of
plugs indicated. If the heat ratio
is less than required or the life
specified is not guaranteed, prob-
lems can arise.
181TECHNICAL SPECIFICATIONS

200TECHNICAL SPECIFICATIONS
CAPACITIES
1.4
litres kg
60 –
5 - 7 –
7–
2.4 2.1
2.6 2.25
1.98 1.8
1.3 1.2
0.5 –
0.55 –
7–
Fuel tank:including a reserve of:
Engine cooling
system:
Engine sump:
Engine sump and filter:
Manual gearbox:
Power steering
Front and rear brakes
hydraulic circuit:
Hydraulic brake circuit
with ABS:
Windscreen and rear window
washer fluid reservoir:
(▲) For particularly hard climate conditions, we recommend use of a 60% PARAFLU UP and 40% demineralized water mixture.
(❒) For particularly cold temperatures use SELENIA MULTIPOWER.
Prescribed fuel
Recommended products
Unleaded petrol not lower than
95 R.O.N
50 - 50 mixture of distilled water
and PARAFLU UP
(▲)
SELENIA 20K(❒)
TUTELA CAR ZC 75 SYNTH
TUTELA GI/E
TUTELA TOP 4
TUTELA TOP 4
Mixture of water and TUTELA
PROFESSIONAL SC 35

201TECHNICAL SPECIFICATIONS201
1.9 Multijet
litres kg
60 –
5 - 7 –
6.5 –
4.0 (❍) 3.5 (❍)
4.3 (❍) 3.7 (❍)
1.98 1.8
1.3 1.2
0.5 –
0.55 –
7– 1.3 Multijet
litres kg
60 –
5 - 7 –
6.5 –
3.0 (■) 2.6 (■)
3.2 (■) 2.8 (■)
1.98 1.8
1.3 1.2
0.5 –
0.55 –
7–
(▲) For particularly hard climate conditions, we recommend use of a 60% PARAFLU UP and 40% demineralized water mixture.
(❍) For particularly cold temperatures use SELENIA WR.
Fuel tank:including a reserve of:
Engine cooling
system:
Engine sump:
Engine sump and filter:
Manual gearbox:
Power steering
Front and rear brakes
hydraulic circuit:
Hydraulic brake circuit
with ABS:
Windscreen and rear window
washer fluid reservoir: Prescribed fuel
Recommended products
Diesel fuel for motor vehicles
(EN590 Specification)
50 - 50 mixture of distilled water
and PARAFLU UP
(▲)
SELENIA TURBO DIESEL(❍)
SELENIA WR(■)
TUTELA CAR ZC 75 SYNTH
TUTELA GI/E
TUTELA TOP 4
TUTELA TOP 4
Mixture of water and TUTELA
PROFESSIONAL SC 35

202TECHNICAL SPECIFICATIONS
FLUIDS AND LUBRICANTS
PRODUCTS WHICH MAY BE USED AND THEIR CHARACTERISTICS
Specifications of the lubricants and fluids to use
for best operation
Synthetic-based engine oils grade SAE 10W-40
that pass ACEA A3 and API SL specifications.
Synthetic-based engine oils grade SAE 5W-30
that pass ACEA A1-A5 - API SL and
FIAT 9.55535-M1specifications.
Synthetic-based engine oils grade SAE 10W-40
that pass ACEA B3 and API CD specifications.
Synthetic-based engine oils grade SAE 5W-40
that pass ACEA B4, API CF and
FIAT 9.55535-M2specifications.
Synthetic-based engine oils grade SAE 5W-40 that pass
ACEA B4, API CF and FIAT 9.55535-M2specifications
F0A0175b
(*) For very low temperatures, we recommend SELENIA MULTIPOWER.
(**) For very low temperatures, we recommend SELENIA WR.
Applications Use
Lubricants for
petrol engines (*)
Lubricants for
diesel engines (**)
Lubricants for
diesel engines
(1.3 Multijet versions)
Fluids and lubricants
recommended
SELENIA 20K
SELENIA
MULTIPOWER
SELENIA
TURBO DIESEL
SELENIA
WR

207TECHNICAL SPECIFICATIONS
PROVISIONS FOR THE PROCESSING OF A VEHICLE
AT THE END OF ITS LIFE-CYCLE
For years now Fiat has been developing its global commitment towards the safeguarding and protection of the
Environment through the continuous improvement of its production processes and the making of increasingly more “eco
friendly” products. With a view to guaranteeing the best possible service to clients in full observance of environmental
standards and in response to the obligations imposed by European Directive 2000/53/EC on end-of-life vehicles, Fiat offers
its clients the possibility to hand in their vehicle* at the end of its life span without additional costs.
The European Directive, in fact, provides for the take-back of the vehicle without the last holder or owner of the same
incurring expenses due to the fact that the market value of the vehicle is zero or negative. In particular, in almost all of
the countries of the European Union, up until 1st January 2007, take-back of the vehicle free of charge only applies to vehi-
cles registered from 1 July 2002 on, while, from 2007 on, take-back will be carried out free of charge, independently of
the year of registration, provided that the vehicle still contains all its essential component parts (especially engine and
body) and is free from additional waste materials.
Our contracted network of authorised treatment facilities has been carefully selected in order to provide a quality ser-
vice to our customers by de-polluting and recycling “End of Life Vehicles” to approved environmental standards. To find
out the location of your nearest authorised treatment facility, offering free of charge take-back, simply contact one of our
dealers or refer to the Fiat web site or call the toll free number 00800 3428 0000.
*Passenger transportation vehicles to seat a max. of nine persons, having a total admissible weight of 3.5 t
