179TECHNICAL SPECIFICATIONS
EUROPEAN HOMOLOGATION
Engine Engine code
1.9 Multijet 120 HP 186 A 9000
VersionsBodywork version code
Cargo 223ZXH1AAX
Cargo high roof223ZXH1ABX
Cargo Maxi (long wheelbase)223ZXH1AAXL
5 seater combi N1223ZXH1AAZ
Panorama 223AXH1A06
Panorama high roof223AXH1A06B
7 seater family223AXH1A06C
ENGINE
GENERAL FEATURES1.4 8v
Type code 350A1000
Cycle Otto
Number and layout of cylinders 4 in line
Piston bore and stroke mm 72,0 x 84
Total displacement cm31368
Compression ratio 11,1 : 1
Max power (CEE):
kW 57
HP 77
corresponding ratio rpm 6000
Max torque (CEE):
Nm 115
kgm 11,7
corresponding ratio giri/min 3000
Spark plugs NGK ZKR7A - 10
Fuel Unleaded
petrol
95 RON

180TECHNICAL SPECIFICATIONS
1.3 Multijet
75 HP
199 A2 000
Diesel
4 in line
69.6x 82
1248
17.6 : 1
55
75
4000
190
19.4
1750
Diesel fuel 1.9 Multijet
100 HP*
223 B2 000
Diesel
4 in line
82.0 x 90,4
1910
18.0 : 1
74
100
4000
200
20.4
1750
Diesel fuel 1.9 Multijet
105 HP
223 B1 000
Diesel
4 in line
82.0 x 90,4
1910
18.0 : 1
77
105
4000
200
20,4
1750
Diesel fuel 1.9 Multijet
120 HP
186 A9 000
Diesel
4 in line
82.0 x 90.4
1910
18.0 : 1
88
120
4000
200
20,4
1750
Diesel fuel GENERAL FEATURES
Type code
Cycle
Number and layout of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Max power (EEC):
kW
HP
corresponding ratio rpm
Max torque (EEC):
Nm
kgm
corresponding ratio rpm
Fuel
(*) For specific markets where applicable1.3 Multijet
85 HP
223 A9 000
Diesel
4 in line
69.6x 82
1248
17.6 : 1
62
85
4000
200
20.4
1750
Diesel fuel
