151VEHICLE MAINTENANCE
20 40 60 80 100 120 140 160 180
●●●●
●●●
●●●●●●●●●
●●
●
●●●●
●●●●
●●
●●●●●●●●●
(●)(●)(●)(●)(●)(●)(●)(●)(●)
●●●
●●●●●●●●●thousands of kilometres
Replace air cleaner cartridge (petrol versions)
Replace air cleaner cartridge (Multijet versions)
Top up fluids (engine coolant, brakes, windscreen washer, battery, etc.)
Check timing belt conditions (excluding 1.3 Multijet versions)
Replace timing belt (excluding 1.3 Multijet versions) (*)
Replace spark plugs (petrol versions)
Check engine control systems (via diagnostic socket)
Check mechanical transmission oil level
Change engine oil and oil filter (versions without DPF) (O)
Change engine oil and oil filter (Multijet versions with DPF)
(or every 2 years) (**)
Change brake fluid (or every 2 years)
Change pollen filter (or every 2 years)
(*) Or every 4 years for very demanding use (cold climate, idling in city traffic, dusty areas).
Or every 5 years, regardless from the distance travelled.
(
O) Every 30.000 km or 2 years for Multijet versions
(**)Engine oil and oil filter shall be changed according to their actual exhaust conditions, indicated by warning light/message (where provided) on the
instrument panel (see section “Warning lights and messages”).
149-173 Doblo GB 9-05-2008 12:10 Pagina 151

215INDEX
Rearview mirrors
- electric ....................................... 56
- exterior ..................................... 55
- interior ...................................... 55
Rev counter .................................. 24
Reversing light ............................... 134
Rims ........................................ 183-185
Roof bars
- fasteners presetting ................ 86
Rubber tubing................................ 168
SBR system ................................. 10
Seat adjustment ............................ 48
Seat belts
- general warnings...................... 13
- height adjustment.................... 11
- maintenance ............................ 14
- use .............................................. 9
Seats
- accessing the rear seat........... 52
- adjustments .............................. 48
- cleaning ...................................... 173
- electrically heated ................... 49
- passenger folding seat ............ 50
Side doors ...................................... 75
Side/taillights
- control ...................................... 63- front bulb replacement .......... 133
- rear bulb replacement ........... 134
Snow chains ................................... 116
Snow tyres .................................... 117
Sound system ............................... 97
- setup system ............................ 97
- sound system installation ...... 98
Spark plugs
- maintenance ............................. 181
- type............................................. 179
Starting the engine ....................... 105
- bump starting ........................... 121
- diesel versions ......................... 107
- emergency startup ......... 107-119
- ignition switch .......................... 20
- jump starting ............................ 120
- petrol versions......................... 106
- stopping the engine ................ 108
- warming up the engine .......... 107
Steering column lock ................... 20
Steering column stalks
- left-hand stalk ......................... 63
- right-hand stalk ........................ 64
Steering wheel adjustment ......... 55
Steering........................................... 183
Stopping the engine ..................... 107
Storing the vehicle ....................... 118Structure ........................................ 183
Sun visors ....................................... 71
Suspensions .................................. 182
Symbols........................................... 6
Tailgate.......................................... 79
Technical characteristics ............ 174
Third brake lights ........................ 136
Tilting shelf ................................... 71
Tools ............................................... 121
Top speed ...................................... 186
Towing a trailer
- assembly diagram .................... 114
- tow hitch installation .............. 114
- warnings ................................... 113
Towing the vehicle ....................... 146
Transmission ................................ 182
Transporting children in safety . 15
Trip computer .............................. 36
Tyre pressure................................ 185
Tyres
- if a tyre is punctured .............. 121
- inflation pressure .................... 184
- reading ....................................... 184
- standard..................................... 185
Using the gearbox ..................... 109
212-220 Doblo GB 16-12-2008 14:26 Pagina 215
