Dear Customer,
We would like to congratulate and thank you for choosing a Fiat Doblò.
We have written this handbook to help you get to know all the features of your vehicle and use it in the best possible way.
Here you will find information, advice and important warnings regarding use of your vehicle and how to achieve the best performance from the
technical features of your Fiat Doblò.
You are advised to read it right through before taking to the road for the first time, to become familiar with the controls and above all with those
concerning brakes, steering and gearbox; at the same time, you can understand the vehicle behaviour on different road surfaces.
This document also provides a description of special features and tips, as well as essential information for the safe driving, care and
maintenance of your Fiat Doblò over time.
After reading it, you are advised to keep the handbook inside the vehicle, for an easy reference and for making sure it remains on board the
vehicle should it be sold.
In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate and
the detail of the terms and conditions for maintaining its validity.
We are sure that these will help you to get in touch with and appreciate your new vehicle and the service provided by the people at Fiat.
Enjoy reading. Happy motoring!
Page 7 of 323
USE OF THE OWNER HANDBOOK
OPERATING INSTRUCTIONS
Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be
intended as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as
appropriate in the text.
The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the
image do not correspond to the actual arrangement of your vehicle. In addition, the Handbook has been conceived
considering vehicles with steering wheel on the left side; it is therefore possible that on vehicles with steering wheel
on the right side, the position or construction of some controls is not exactly mirror-like with respect to the figure.
To identify the chapter with the information needed you can consult the index at the end of this Owner Handbook.
Chapters can be rapidly identified with dedicated graphic tabs, at the side of each odd page. A few pages further
there is a key for getting to know the chapter order and the relevant symbols in the tabs. There is in any case a
textual indication of the current chapter at the side of each even page.
WARNINGS AND PRECAUTIONS
While reading this Owner Handbook you will find a series ofWARNINGSto prevent procedures that could damage
your vehicle.
There are alsoPRECAUTIONSthat must be carefully followed to prevent incorrect use of the components of the
vehicle, which could cause accidents or injuries.
Therefore allWARNINGSandPRECAUTIONSmust always be carefully followed.
WARNINGSandPRECAUTIONSare recalled in the text with the following symbols:
personal safety;
vehicle integrity;
environmental protection.
NOTE These symbols, when necessary, are indicated besides the title or at the end of the line and are followed by a
number. That number recalls the corresponding warning at the end of the relevant section.
Page 15 of 323
.
AIR VENTS
❒Diffusers ............................................. 43
LEFT STALK
❒External lights ..................................... 34
INSTRUMENT PANEL
❒Control panel and on-board
instruments ......................................... 74
❒Warning lights ..................................... 92
RIGHT STALK
❒Window cleaning ................................ 40
CAR RADIO
❒System ............................................... 70
PASSENGER SIDE FRONT
AIRBAG
❒Front airbag ........................................128
GLOVE COMPARTMENT
❒Interior fittings ..................................... 64
DASHBOARD CONTROLS
❒Operation ........................................... 58
HEATER/CLIMATE CONTROL
SYSTEM
❒Heating and ventilation ........................ 44
❒Manual climate control system ............ 47
❒Automatic climate control .................... 50
GEAR LEVER
❒Operation ...........................................139
STEERING WHEEL
❒Adjustment ......................................... 32
❒Driver's side front airbag .....................128
3F0V0538
11
Page 16 of 323
.
BONNET OPENING LEVER
❒Opening/closing .................................. 59
STEERING WHEEL
ADJUSTMENT UNLOCKING LEVER
❒Operation ........................................... 32
DOORS
❒Lock/Unlock ....................................... 19
SEATS
❒Adjustments ....................................... 24❒Driver’s seat adjustments .................... 24
❒Passenger seat adjustments ............... 25
❒Rear seat access ................................ 26
❒Seat that folds to table ........................ 26
❒Third row seats ................................... 26
4F0V0541
12
GRAPHICAL INDEX
Page 17 of 323
KNOW YOUR VEHICLE
In-depth knowledge of your new
vehicle starts here.
The booklet that you are reading
simply and directly explains how it is
made and how it works.
That’s why we advise you to read it
seated comfortably on board, so
that you can see what is described
here for yourself.THE KEYS....................................... 14
IGNITION DEVICE ........................... 17
SYMBOLS ...................................... 18
THE FIAT CODE SYSTEM ............... 18
DOORS ........................................... 19
SEATS ............................................ 24
PARTITIONS ................................... 29
HEAD RESTRAINTS ........................ 31
STEERING WHEEL ......................... 32
REAR VIEW MIRRORS .................... 32
EXTERIOR LIGHTS ......................... 34
INTERIOR LIGHTS .......................... 36
WINDSCREEN/REAR WINDOW
WIPER ............................................ 40
HEATING AND VENTILATION
SYSTEM ......................................... 42
DIFFUSERS..................................... 43
HEATING AND VENTILATION.......... 44
MANUAL CLIMATE CONTROL
SYSTEM ......................................... 47
AUTOMATIC CLIMATE CONTROL
SYSTEM ......................................... 50
ELECTRIC WINDOWS .................... 56
CONTROLS .................................... 58
BONNET ......................................... 59
BOOT ............................................. 60
INTERIOR FITTINGS ....................... 64
ROOF RACK/SKI RACK .................. 68HEADLIGHTS.................................. 69
RADIO............................................. 70
PROTECTING THE
ENVIRONMENT .............................. 71
13
Page 21 of 323
IGNITION DEVICE
The key can be turned to 3 different
positions fig. 10:
❒STOP: engine off, key extractable,
steering locked. Some electrical
devices (e.g. sound system, central
door locking system, etc.) can
operate;
❒MAR: driving position. All electrical
devices are enabled;
❒AVV: engine starting (unstable
position).
The ignition switch is fitted with an
electronic safety system that
requires the ignition key to be turned
back to STOP if the engine will not
start, before the starting operation
can be repeated.
4) 5) 6) 7)
STEERING LOCK
Activation
When the key is at STOP, remove
the key and turn the steering wheel
until it locks.
Deactivation
Move the steering wheel slightly as
you turn the ignition key to MAR.
WARNING
4) If the ignition device has been
tampered with (e.g. an attempted
theft), have it checked over by a
Fiat Dealership before driving
again.
5) Always remove the key when you
leave your vehicle to prevent
someone from accidentally
operating the controls. Remember
to engage the handbrake.
Engage first gear if the vehicle is
parked uphill or reverse gear if the
vehicle is parked downhill. Never
leave children unattended in the
vehicle.6) Never extract the key while the
vehicle is moving. The steering
wheel will automatically lock
as soon as it is turned. This also
applies to cases in which the
vehicle is towed.
7) It is absolutely forbidden to carry
out any after-market operation
involving steering system or
steering column modifications
(e.g.: installation of anti-theft
device) that could badly affect
performance and safety, cause
the lapse of warranty and also
result in non-compliance of the
vehicle with type approval
requirements.
10F0V0006
17
Page 28 of 323
SEATS
DRIVER’S SEAT
(for Cargo versions, where provided)
15)
Longitudinal
adjustment
Raise the lever A fig. 24 and push
the seat forwards or backwards:
in driving position your arms should
be slightly bent and your hands
should rest on the rim of the
steering wheel.
16)
Reclining backrest
adjustment
Lift lever B fig. 24 and, slightly
detaching the back from the
backrest, accompany the
movement of the backrest until it is
in the desired position.
DRIVER’S SEAT
(for Doblò/Doblò Combi/Cargo
versions, where provided)
15)
Lengthwise
adjustment
Lift the lever A fig. 25 and push the
seat forwards or backwards: in
the driving position your arms
should rest on the rim of the
steering wheel.
16)
Backrest angle
adjustment
Turn knob B fig. 25Driver seat height
adjustment
(for versions/markets, where
provided)
Operate lever C fig. 25 to lift or
lower the rear part of the cushion to
achieve the most comfortable
driving position.
IMPORTANT Adjustment must be
carried out only when seated in the
relevant seat.
24F0V0210
25F0V0013
24
KNOW YOUR VEHICLE
Page 36 of 323
STEERING WHEEL
The height and axial position of the
steering wheel can be adjusted
on all versions.
To carry out the adjustment,
proceed as follows:
❒release lever A fig. 48 by pushing it
forwards (position 1);
❒adjust the steering wheel;
❒lock lever A fig. 48 by pulling it
towards the steering wheel (position
2).
24) 25)
WARNING
24) All adjustments must only be
carried out with the vehicle
stationary and the engine off.
25) Under no circumstances should
aftermarket operations involving
steering system or steering
column modifications (e.g.:
installation of anti-theft device) be
carried out that could badly
affect performance and safety.
This also causes the warranty to
become null and void and results
in vehicle non-compliance with
type-approval requirements.
REAR VIEW
MIRRORS
INTERIOR MIRROR
(for versions/markets, where
provided)
The mirror is fitted with a safety
device that causes its release in the
event of a violent impact with the
passenger.
Lever A fig. 49 can be used to move
the mirror to two different positions:
normal or antiglare.
Some versions may feature an
internal child surveillance mirror B
fig. 50.
48F0V001449F0V0125
32
KNOW YOUR VEHICLE
Page 39 of 323
MAIN BEAM
HEADLIGHTS
With ring nut in position
, push
the stalk forward toward the
dashboard (stable position). The
warning light switches on in the
instrument panel. Pulling the stalk
towards the steering wheel, the
main beams are turned off and the
dipped headlights on.
FLASHING
You can flash the beams pulling the
stalk toward the steering wheel
(unstable position). The
warning
light switches on in the instrument
panel.
DIRECTION
INDICATORS
Bring the stalk into (stable) position
fig. 55:
❒up (position 1): to activate the right
direction indicator;
❒down (position 2): activates the left
direction indicator.
Warning lightorwill blink on
the instrument panel.Direction indicators switch off
automatically when the vehicle is
back in a straight line.
Lane change function
If you wish to signal a lane change,
place the left stalk in the unstable
position for less than half a second.
The direction indicator on the side
selected will flash five times and
then switch off automatically.
"FOLLOW ME HOME"
DEVICE
This device allows the illumination of
the space in front of the vehicle for
a preset time.Activation
With the ignition key in the STOP
position or extracted, pull the stalk
towards the steering wheel and
move it within 2 minutes of the
engine switching off.
Each time the stalk is moved, the
lights stay on for an extra 30
seconds up to a maximum of 210
seconds; then the lights are
switched off automatically.
The warning light
on the
instrument panel will light up and the
corresponding message will appear
in the display (see “Warning lights
and messages” section) for as long
as the function is activated.
The warning light comes on when
the stalk is operated and stays
on until the function is automatically
deactivated.
Each movement of the stalk only
increases the amount of time the
lights stay on.55F0V0516
35
Page 40 of 323
Deactivation
Keep the stalk pulled towards the
steering wheel for more than 2
seconds.
WARNING
27) The daytime running lights are
an alternative to dipped
headlights for driving during the
daytime. They are compliant in
countries where is it obligatory to
have lights on during the day
and permitted in those where it is
not obligatory. Daytime running
lights cannot replace dipped
headlights when driving at night
or through tunnels. The use of
daytime running lights is
governed by the highway code of
the country in which you are
driving. Comply with the
prescriptions.
INTERIOR LIGHTS
FRONT ROOF LIGHT
WITH MOVABLE LENS
The light fades up or reaches full
brightness immediately if pushed at
the sides.
On the Doblò Cargo versions, it is
only connected to the front doors.
On the Doblò/Doblò Combi people
carrier versions, it is connected to
the front doors and the sliding
side doors.FRONT ROOF LIGHT
WITH SPOT LIGHTS
(for versions/markets, where
provided)
On the Doblò Cargo versions, it is
only connected to the front doors.
On the Doblò/Doblò Combi people
carrier versions, it is connected to
the front doors and the sliding
side doors.
Switch A fig. 56 is used to switch
on/off roof lights.
With switch A in the middle position,
lights C and D go on/off when the
doors are opened/closed.
With switch A pressed to the left,
the lights C and D are always off.
With switch A pressed to the right,
the lights C and D are always on.
Lights switch on/off progressively.
Switch B controls the spot light
function; when the roof light is off, it
switches on individually:
light C if pressed on the left side;
light D if pressed on the right side.
56F0V0055
36
KNOW YOUR VEHICLE
