stop start FIAT DOBLO PANORAMA 2018 Owner handbook (in English)

1.4 16V Euro 5 / Euro 6 NO Start&Stop Combined
Cargo Short Wheelbase169
Cargo, short wheelbase, increased payload / Cargo, long wheelbase /
Combi 5-seater, short wheelbase / Combi 5-seater, long wheelbase172
Doblò 5/7-seater / Cargo, short wheelbase, high roof 173
Cargo, short wheelbase, high roof, increased payload / Doblò 5/7-
seater, high roof177
Flatbed, short wheelbase / long wheelbase, low roof 185
1.4 Euro 4 Combined
Cargo short wheelbase169
Cargo short wheelbase, increased payload / Cargo long wheelbase 174
Combi 5-seater - Doblò 5/7-seater 172
Cargo, short wheelbase, high roof 173
Doblò 5-seater, high roof177
1.4 T-JET Euro 5 / Euro 6 Combined
Cargo short wheelbase / Cargo long wheelbase 169
Cargo, short wheelbase, high roof 175
Cargo, long wheelbase, high roof 179
Combi 5 seats169
Combi 5-seater, long wheelbase 173
Doblò 5/7-seater169
214
TECHNICAL DATA

1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 126
Cargo long wheelbase / Combi 5-seater 129
Flatbed, short wheelbase / long wheelbase, low roof 142
1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Eco Pack Combined
Cargo, short wheelbase / Cargo, increased payload, short wheelbase 115
Cargo increased payload, long wheelbase / Combi, short wheelbase /
long wheelbase118
Flatbed, short wheelbase / long wheelbase, low roof 131
1.3 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop with DPF Combined
Cargo Short wheelbase / Cargo Short wheelbase, Increased payload
/ Cargo Long wheelbase133
Combi 5-seater, short wheelbase / Combi 5-seater, long wheelbase 136
Flatbed, short wheelbase / long wheelbase, low roof 149
1.3 Multijet 80 HP/95 HP Euro 6 Start&Stop Eco Pack Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 120
Cargo, long wheelbase / Cargo, long wheelbase (700 kg) 123
Combi, short wheelbase / Combi, short wheelbase, increased
payload / Combi, long wheelbase123
Truck, long wheelbase127
Flatbed, short wheelbase / long wheelbase, low roof 127
215

1.3 Multijet 80 HP/95 HP Euro 6 NO Start&Stop Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 133
Cargo, long wheelbase / Cargo, long wheelbase (700 kg) 136
Combi, short wheelbase / Combi, short wheelbase, increased
payload / Combi, long wheelbase136
Truck, long wheelbase140
Flatbed, short wheelbase / long wheelbase, low roof 140
1.3 Multijet Euro 4 Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 136
Cargo long wheelbase139
Combi 5 seats139
Flatbed, short wheelbase / long wheelbase, low roof 141
1.3 Multijet Euro 4 Start&Stop with DPF Combined
Doblò 5/7-seater129
1.3 MultiJet 75 HP Euro 5+ DPF Start&Stop Combined
Flatbed, short wheelbase / long wheelbase 137
Cargo short wheelbase / Cargo short wheelbase, increased payload 126
Cargo long wheelbase, increased payload / Combi 5-seater 129
1.3 MultiJet 75 HP Euro 5+ DPF NO Start&Stop Combined
Flatbed, short wheelbase / long wheelbase 144
Cargo Short wheelbase / Cargo Short wheelbase, Increased payload
/ Cargo Long wheelbase133
216
TECHNICAL DATA

1.3 MultiJet 75 HP Euro 5+ DPF NO Start&Stop Combined
Combi 5-seater / Cargo long wheelbase / Increased payload 136
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase136
Cargo short wheelbase, increased payload Cargo long wheelbase 137
Combi 5-seater, short wheelbase 138
Combi 5-seater, long wheelbase 141
Doblò 5/7-seater138
Cargo,short wheelbase, high roof / Cargo, short wheelbase,
increased payload, high roof146
Doblò 5-seater, high roof150
Doblò 5-seater, long wheelbase 138
Flatbed, short wheelbase / long wheelbase, low roof 170
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Eco Pack Combined
Cargo short wheelbase124
Cargo, increased payload, short wheelbase / long wheelbase 125
Combi short wheelbase126
Combi long wheelbase129
Combi Panorama, short wheelbase / long wheelbase - Doblò, short
wheelbase / long wheelbase126
Cargo / Cargo increased payload, short wheelbase, high roof 134
Doblò, short wheelbase, high roof 136
Flatbed, short wheelbase / long wheelbase, low roof 155
217

1.6 MultiJet 105 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Cargo short wheelbase143
Cargo Short wheelbase, Increased payload 144
Cargo, long wheelbase / Combi 5-seater, short wheelbase 145
Combi 5-seater, long wheelbase 148
Doblò 5/7-seater145
Cargo, long wheelbase, high roof 158
Cargo, short wheelbase, high roof 154
Cargo, short wheelbase, high roof / increased payload / Doblò
5-seater, high roof158
Doblò 5-seater, long wheelbase 145
Flatbed, short wheelbase / long wheelbase, low roof 178
1.6 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Doblò 5/7-seater145
Doblò 5-seater, high roof158
1.6 Multijet Euro 5+ TREKKING Combined
Doblò 5-seater Short Wheelbase Low Roof - No Start&Stop 154
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 146
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 134
Doblò 5-seater Short Wheelbase Low Roof - No Start&Stop 154
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 146
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 134
Combi 5-seater Short Wheelbase Low Roof - No Start&Stop 154
218
TECHNICAL DATA

1.6 Multijet Euro 5+ TREKKING Combined
Combi 5-seater Short Wheelbase Low Roof - Start&Stop 146
Combi 5-seater Short Wheelbase Low Roof - Eco Pack 134
Combi 5-seater Short Wheelbase Low Roof (No Start&Stop -
Reinforced suspension)154
Combi 5-seater Short Wheelbase Low Roof - Start&Stop (Reinforced
suspension)146
Combi 5-seater Short Wheelbase Low Roof - Eco Pack (Reinforced
suspension)134
1.6 Multijet 90 HP with COMFORT-MATIC transmission Combined
Cargo short wheelbase130
Cargo Short Wheelbase High roof / Cargo
Short Wheelbase Increased Payload High
RoofF.C.
(*) 1470140
F.C.
(*) 1590145
Cargo Short Wheelbase, Increased Payload / Long Wheelbase 133
Combi Short Wheelbase133
Combi Long Wheelbase135
(*) F.C.: flywheel class
1.6 Multijet 90 HP NO Start&Stop with COMFORT-MATIC transmission Combined
Cargo short wheelbase138
Cargo Short Wheelbase High roof / Cargo
Short Wheelbase Increased Payload High
RoofF.C.
(*) 1470150
F.C.
(*) 1590156
Cargo Short Wheelbase, Increased Payload / Long Wheelbase 141
Combi Short Wheelbase / Long Wheelbase141
(*) F.C.: flywheel class
219

Versions with DUALOGIC™transmission Combined
1.6 Multijet
133 / 147(*)
1.6 Multijet NO Start&Stop
141 / 157(*)
(*) High roof versions
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 NO Start&Stop Combined
Doblò 5/7 seater, short wheelbase, low roof 137
Doblò 5 seater, long wheelbase, low roof, reinforced suspension 144
Doblò 5 seater, short wheelbase, low roof, reinforced suspension 152
Doblò 5 seater (120 HP), long wheelbase / high roof / reinforced
suspension152
Cargo, short wheelbase, low roof 134
Cargo, short wheelbase, high roof, increased payload 135
Cargo, short wheelbase, high roof / Cargo, short wheelbase, high
roof, increased payload135
Cargo, long wheelbase, low roof / Cargo, long wheelbase, low roof
(700 kg)135
Cargo, long wheelbase, high roof 149
Combi, short wheelbase, low roof / Combi, short wheelbase, low roof,
increased payload136
Combi, long wheelbase, low roof 139
Combi, long wheelbase, high roof 149
Truck, long wheelbase, low roof 149
Flatbed, short wheelbase / long wheelbase, low roof 149
Flatbed, short wheelbase / long wheelbase, low roof — Increased
payload153
220
TECHNICAL DATA

1.6 Multijet 95 HP/105 HP/120 HP Euro 6 Start&Stop Eco Pack Combined
Doblò 5/7 seater, short wheelbase, low roof 124
Doblò 5 seater, long wheelbase, low roof, reinforced suspension 130
Doblò 5 seater, short wheelbase, low roof, reinforced suspension 140
Doblò 5 seater (120 HP), long wheelbase / high roof / reinforced
suspension140
Cargo, short wheelbase, low roof 120
Cargo, short wheelbase, high roof, increased payload 121
Cargo, short wheelbase, high roof / Cargo, short wheelbase, high
roof, increased payload121
Cargo, long wheelbase, low roof / Cargo, long wheelbase, low roof
(700 kg)121
Cargo, long wheelbase, high roof 133
Combi, short wheelbase, low roof / Combi, short wheelbase, low roof,
increased payload122
Combi, long wheelbase, low roof 125
Combi, long wheelbase, high roof 133
Truck, long wheelbase, low roof 133
Flatbed, short wheelbase / long wheelbase, low roof 133
1.6 Multijet Euro 6 TREKKING Combined
Doblò 5-seater Short Wheelbase Low Roof - No Start&Stop 144
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 132
Doblò 7-seater Short Wheelbase Low Roof - No Start&Stop 144
Doblò 7-seater Short Wheelbase Low Roof - Eco Pack 132
221

1.6 Multijet Euro 4 Combined
Cargo short wheelbase143
Cargo, increased payload, short wheelbase, long wheelbase 144
Cargo, short wheelbase, high roof / Cargo, short wheelbase, high
roof, increased payload152
1.6 Multijet Euro 4 Start&Stop with DPF Combined
Doblò 5/7-seater138
Doblò 5-seater, high roof150
2.0 Multijet Euro 5 / Euro 5+ Combined
Cargo short wheelbase / long wheelbase 148
Combi 5-seater / Doblò 5/7-seater 150
Cargo,short wheelbase, high roof / Cargo, short wheelbase,
increased payload, high roof152
Doblò 5-seater, high roof157
Doblò 5-seater, long wheelbase 150
2.0 MultiJet 135 HP Euro 5 / Euro 5+ Combined
Cargo short wheelbase154
Cargo, short wheelbase, Increased payload / Cargo, long wheelbase /
Combi 5-seater, short wheelbase156
Combi 5-seater, long wheelbase / Doblò 5/7-seater / Cargo, long
wheelbase, high roof163
Cargo, short wheelbase, high roof 158
Cargo, short wheelbase, high roof, increased payload / Cargo, short
wheelbase, high roof167
222
TECHNICAL DATA

2.0 MultiJet 135 HP Euro 5 / Euro 5+ Combined
Cargo, short wheelbase, high roof / increased payload / Doblò
5-seater, high roof163
Combi 5-seater, long wheelbase, high roof 167
Doblò 5-seater, long wheelbase 156
Flatbed, short wheelbase / long wheelbase, low roof 185
2.0 Multijet Euro 5+ TREKKING Combined
Combi 5-seater Short Wheelbase Low Roof (No Start&Stop) 158
Combi 5-seater Short Wheelbase Low Roof (No Start&Stop -
Reinforced suspension)158
1.4 T-JET Natural Power Combined
Doblò 5-seater Short Wheelbase / Long Wheelbase
173(*) / 134 (**)
Cargo, short wheelbase, high roof
175(*) / 136 (**)
(*) Running on petrol
(**) Running on methane
