PARKING SENSORS
These are located in the rear bumper
fig. 135 and their function is to inform
the driver, through an intermittent
beeping noise, about the presence of
obstacles behind the vehicle.
ACTIVATION/
DEACTIVATION
The sensors are automatically activated
when reverse gear is engaged. As the
obstacle behind the vehicle gets closer
to the bumper, the frequency of the
acoustic signal increases.
Detection distances
If several obstacles are detected by the
sensors, only the nearest one is
considered.
112)
OPERATION WITH A
TRAILER
Parking sensor operation is
automatically deactivated when the
electric cable plug of the trailer is
inserted into the vehicle tow hook
socket. The sensors are automatically
reactivated when the trailer's cable plug
is removed.
IMPORTANT
If you wish to leave the tow hook fitted
without towing a trailer, it is advisable to
contact a Fiat Dealership for the
relevant system update operations
because the tow hook could be
detected as an obstacle by the central
sensors.
IMPORTANT
INFORMATION
113)
When parking, take the utmost care
over obstacles that may be above or
under the sensor.
Sometimes, objects located very
near the rear of the vehicle are not
detected and could therefore damage
the vehicle or be damaged themselves.
The following conditions may influence
the performance of the parking
assistance system:
Reduced sensor sensitivity and a
reduction in the parking assistance
system performance could be due to
the presence on the surface of the
sensor of: ice, snow, mud, thick paint.
The sensor may detect a non-
existent obstacle (echo noise) due to
mechanical noises, for example when
washing the vehicle, in case of rain,
strong wind, hail.
The signals sent out by the sensors
can be altered by dirt, snow or ice
deposited on the sensors or by
ultrasound systems (e.g. truck
pneumatic brakes or pneumatic drills)
near the vehicle.
The performance of the parking
assistance system may also be affected
by the position of the sensors. For
example by a change in the ride setting
(caused by the wear of the shock
absorbers, suspension), changing the
tyres, overloading the vehicle and
carrying out specific tuning operations
that require the vehicle to be lowered.
Detection of obstacles in the upper
part of the vehicle (particularly in the
case of vans or chassis cabs) may not
be guaranteed because the system
detects obstacles that could strike the
lower part of the vehicle.
The parking sensors work properly
with the swing doors closed.
135F0V0077
116
STARTING AND DRIVING

if a tyre is punctured, stop
immediately and replace it to avoid
damage to the tyre, the rim, suspension
and steering system;
tyres age even if they are not used
much. Cracks in the tread and on
the sidewalls are a sign of ageing. In
any event, have the tyres checked
by specialised technicians if they have
been fitted for longer than 6 years.
Remember to check the spare wheel
very carefully;
in the case of replacement, always
fit new tyres, avoiding those of
unknown origin;
if a tyre is changed, also change the
inflation valve;
to allow even wear between the
front and rear tyres, it is advisable to
change them over every 10–15
thousand kilometres, keeping them on
the same side of the vehicle so as
not to reverse the direction of rotation.
142) 143) 144) 145) 146)
WARNING
142)Remember that the road holding
qualities of your vehicle also depend on the
correct inflation pressure of the tyres.
143)If tyre pressure is too low, the tyre
may overheat and be severely damaged as
a result.
144)Do not switch tyres from the
right­hand side of the vehicle to the
left­hand side, and vice versa.
145)Never submit alloy rims to repainting
treatments requiring the use of
temperatures exceeding 150°C. The
mechanical properties of the wheels could
be impaired.
146)Keep the vehicle's speed down when
snow chains are fitted; never exceed 50
km/h. Avoid potholes, do not drive over
steps or pavements, and do not drive long
distances over roads without snow, to
avoid damaging both your vehicle and the
road surface.
169

VERSIONS CONSUMPTION
1.6 Multijet Euro 5+ TREKKING Urban Extra-urban Combined
Doblò 5-seater Short Wheelbase Low Roof - No
Start&Stop7.1 5.1 5.8
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 6.3 5.1 5.5
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 5.8 4.7 5.1
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop7.1 5.1 5.8
Combi 5-seater Short Wheelbase Low Roof - Start&Stop 6.3 5.1 5.5
Combi 5-seater Short Wheelbase Low Roof - Eco Pack 5.8 4.7 5.1
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop - Reinforced suspension7.1 5.1 5.8
Combi 5-seater Short Wheelbase Low Roof - Start&Stop
- Reinforced suspension6.3 5.1 5.5
Combi 5-seater Short Wheelbase Low Roof - Eco Pack -
Reinforced suspension5.8 4.7 5.1
.
VERSIONS CONSUMPTION
1.6 Multijet 90 HP with COMFORT-MATIC transmission Urban Extra-urban Combined
Cargo short wheelbase 5.5 4.6 4.9
Cargo short wheelbase High roof / Cargo
short wheelbase increased payload high
roofF.C.
(*)14705.6 5.2 5.3
F.C.
(*)15905.7 5.4 5.5
Cargo short wheelbase, increased payload / long wheelbase 5.6 4.7 5.0
Combi Short Wheelbase 5.6 4.8 5.0
Combi Long Wheelbase 5.7 4.8 5.1
(*) F.C.: flywheel class
The fuel consumption figures in the table refer to the AUTO-ECO logic..
206
TECHNICAL DATA

VERSIONS CONSUMPTION
1.6 Multijet 90 HP NO Start&Stop with COMFORT-
MATIC transmissionUrban Extra-urban Combined
Cargo short wheelbase 6.3 4.7 5.3
Cargo short wheelbase high roof / cargo
short wheelbase increased payload high
roofF.C.
(*)14706.5 5.2 5.7
F.C.
(*)15906.6 5.5 5.9
Cargo short wheelbase, increased payload / long wheelbase 6.4 4.8 5.4
Combi Short Wheelbase / Long Wheelbase 6.4 4.8 5.4
(*) F.C.: flywheel class
The fuel consumption figures in the table refer to the AUTO-ECO logic..
VERSIONS CONSUMPTION
Versions with DUALOGIC
™transmission Urban Extra-urban Combined
1.6 MultiJet 90 HP
5.6 / 5.9(*)4.7 / 5.3(*)5.0 / 5.5(*)
1.6 Multijet 90 HP NO Start&Stop
6.4 / 6.7(*)4.8 / 5.5(*)5.4 / 5.9(*)
(*) High roof versions
The fuel consumption figures in the table refer to the AUTO-ECO logic..
VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 NO
Start&StopUrban Extra-urban Combined
Doblò 5/7 seater, short wheelbase / low roof 6.5 4.4 5.2
Doblò 5 seater, long wheelbase / low roof / reinforced
suspension6.8 4.7 5.5
Doblò 5 seater, short wheelbase / low roof / reinforced
Suspension6.9 5.1 5.8
Doblò 5 seater (120 HP), long wheelbase / high roof /
reinforced suspension6.9 5.1 5.8
207

VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 NO
Start&StopUrban Extra-urban Combined
Cargo, short wheelbase, low roof 6.3 4.4 5.1
Cargo, short wheelbase, high roof, increased payload 6.5 4.4 5.2
Cargo, short wheelbase, high roof / Cargo, short
wheelbase, high roof, increased payload6.5 4.4 5.2
Cargo, long wheelbase, low roof / Cargo, long
wheelbase, low roof (700 kg)6.5 4.4 5.2
Cargo, long wheelbase, high roof 6.7 5.1 5.7
Combi, short wheelbase, low roof / Combi, short
wheelbase, low roof, increased payload6.4 4.5 5.2
Combi, long wheelbase, low roof 6.5 4.6 5.3
Combi, long wheelbase, high roof 6.7 5.1 5.7
Truck, long wheelbase, low roof 6.7 5.1 5.7
Flatbed, short wheelbase / long wheelbase, low roof 6.7 5.1 5.7
Flatbed, short wheelbase / long wheelbase, low roof —
Increased payload6.8 5.2 5.8
.
VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 Start&Stop
Eco PackUrban Extra-urban Combined
Doblò 5/7 seater, short wheelbase, low roof 5.4 4.3 4.7
Doblò 5 seater, long wheelbase, low roof, reinforced
suspension5.6 4.5 4.9
Doblò 5 seater, short wheelbase, low roof, reinforced
suspension6.0 4.9 5.3
Doblò 5 seater (120 HP), long wheelbase, high roof,
reinforced suspension6.0 4.9 5.3
208
TECHNICAL DATA

.
VERSIONS CONSUMPTION
2.0 Multijet Euro 5+ TREKKING Urban Extra-urban Combined
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop7.3 5.2 6.0
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop - Reinforced suspension7.3 5.2 6.0
.
VERSIONS CONSUMPTION
2.0 MultiJet 135 HP Euro 5 / Euro 5+ NO Start&Stop Urban Extra-urban Combined
Cargo short wheelbase / Cargo short wheelbase,
increased payload / Cargo long wheelbase7.2 5.1 5.9
Combi 5-seater, short wheelbase / Combi 5-seater, long
wheelbase / Doblò 5/7-seater7.3 5.1 5.9
Cargo, short wheelbase, high roof, increased payload /
Cargo short wheelbase, high roof7.8 5.5 6.3
Cargo, short wheelbase, high roof / increased payload /
Doblò 5-seater, high roof7.4 5.5 6.2
Combi 5-seater, long wheelbase, high roof 7.8 5.5 6.3
Cargo, long wheelbase, high roof 7.4 5.5 6.2
Doblò 5-seater, long wheelbase 7.3 5.1 5.9
Flatbed, short wheelbase / long wheelbase, low roof 7.8 6.6 7.0
.
NOTE The consumption values of the Natural Power versions when running on methane are indicated in m3/100 km.
211

1.6 Multijet Euro 5+ TREKKING Combined
Combi 5-seater Short Wheelbase Low Roof - Start&Stop 146
Combi 5-seater Short Wheelbase Low Roof - Eco Pack 134
Combi 5-seater Short Wheelbase Low Roof (No Start&Stop -
Reinforced suspension)154
Combi 5-seater Short Wheelbase Low Roof - Start&Stop (Reinforced
suspension)146
Combi 5-seater Short Wheelbase Low Roof - Eco Pack (Reinforced
suspension)134
1.6 Multijet 90 HP with COMFORT-MATIC transmission Combined
Cargo short wheelbase130
Cargo Short Wheelbase High roof / Cargo
Short Wheelbase Increased Payload High
RoofF.C.
(*) 1470140
F.C.
(*) 1590145
Cargo Short Wheelbase, Increased Payload / Long Wheelbase 133
Combi Short Wheelbase133
Combi Long Wheelbase135
(*) F.C.: flywheel class
1.6 Multijet 90 HP NO Start&Stop with COMFORT-MATIC transmission Combined
Cargo short wheelbase138
Cargo Short Wheelbase High roof / Cargo
Short Wheelbase Increased Payload High
RoofF.C.
(*) 1470150
F.C.
(*) 1590156
Cargo Short Wheelbase, Increased Payload / Long Wheelbase 141
Combi Short Wheelbase / Long Wheelbase141
(*) F.C.: flywheel class
219

Versions with DUALOGIC™transmission Combined
1.6 Multijet
133 / 147(*)
1.6 Multijet NO Start&Stop
141 / 157(*)
(*) High roof versions
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 NO Start&Stop Combined
Doblò 5/7 seater, short wheelbase, low roof 137
Doblò 5 seater, long wheelbase, low roof, reinforced suspension 144
Doblò 5 seater, short wheelbase, low roof, reinforced suspension 152
Doblò 5 seater (120 HP), long wheelbase / high roof / reinforced
suspension152
Cargo, short wheelbase, low roof 134
Cargo, short wheelbase, high roof, increased payload 135
Cargo, short wheelbase, high roof / Cargo, short wheelbase, high
roof, increased payload135
Cargo, long wheelbase, low roof / Cargo, long wheelbase, low roof
(700 kg)135
Cargo, long wheelbase, high roof 149
Combi, short wheelbase, low roof / Combi, short wheelbase, low roof,
increased payload136
Combi, long wheelbase, low roof 139
Combi, long wheelbase, high roof 149
Truck, long wheelbase, low roof 149
Flatbed, short wheelbase / long wheelbase, low roof 149
Flatbed, short wheelbase / long wheelbase, low roof — Increased
payload153
220
TECHNICAL DATA

1.6 Multijet 95 HP/105 HP/120 HP Euro 6 Start&Stop Eco Pack Combined
Doblò 5/7 seater, short wheelbase, low roof 124
Doblò 5 seater, long wheelbase, low roof, reinforced suspension 130
Doblò 5 seater, short wheelbase, low roof, reinforced suspension 140
Doblò 5 seater (120 HP), long wheelbase / high roof / reinforced
suspension140
Cargo, short wheelbase, low roof 120
Cargo, short wheelbase, high roof, increased payload 121
Cargo, short wheelbase, high roof / Cargo, short wheelbase, high
roof, increased payload121
Cargo, long wheelbase, low roof / Cargo, long wheelbase, low roof
(700 kg)121
Cargo, long wheelbase, high roof 133
Combi, short wheelbase, low roof / Combi, short wheelbase, low roof,
increased payload122
Combi, long wheelbase, low roof 125
Combi, long wheelbase, high roof 133
Truck, long wheelbase, low roof 133
Flatbed, short wheelbase / long wheelbase, low roof 133
1.6 Multijet Euro 6 TREKKING Combined
Doblò 5-seater Short Wheelbase Low Roof - No Start&Stop 144
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 132
Doblò 7-seater Short Wheelbase Low Roof - No Start&Stop 144
Doblò 7-seater Short Wheelbase Low Roof - Eco Pack 132
221

2.0 MultiJet 135 HP Euro 5 / Euro 5+ Combined
Cargo, short wheelbase, high roof / increased payload / Doblò
5-seater, high roof163
Combi 5-seater, long wheelbase, high roof 167
Doblò 5-seater, long wheelbase 156
Flatbed, short wheelbase / long wheelbase, low roof 185
2.0 Multijet Euro 5+ TREKKING Combined
Combi 5-seater Short Wheelbase Low Roof (No Start&Stop) 158
Combi 5-seater Short Wheelbase Low Roof (No Start&Stop -
Reinforced suspension)158
1.4 T-JET Natural Power Combined
Doblò 5-seater Short Wheelbase / Long Wheelbase
173(*) / 134 (**)
Cargo, short wheelbase, high roof
175(*) / 136 (**)
(*) Running on petrol
(**) Running on methane
223
