AIR VENTS
❒Diffusers ............................................. 29
LEFT STALK
❒External lights ..................................... 48
INSTRUMENT PANEL
❒Control panel and on-board
instruments .........................................114
❒Warning lights .....................................132
RIGHT STALK
❒Window cleaning ................................ 53
RADIO
❒System ...............................................107
STORAGE COMPARTMENT /
FRONT PASSENGER SIDE AIRBAG
❒Interior fittings ..................................... 64
❒Front airbag ........................................170
GLOVE COMPARTMENT
❒Interior fittings ..................................... 64
HEATER/CLIMATE CONTROL
SYSTEM
❒Heating and ventilation ........................ 28
❒Manual climate control system ............ 32
❒Automatic climate control system ....... 35
DASHBOARD CONTROLS
❒Operation ........................................... 60
GEAR LEVER
❒Operation ...........................................183
STEERING WHEEL
❒Adjustment ......................................... 25
❒Driver side front airbag ........................170
RADIO
MEDIA
PHONEINFO
A-B-C
MENU
123 4 56
3F1A5002
7

CUP HOLDER - CAN
HOLDER - BOTTLE
HOLDER ON
DASHBOARD
(for versions/markets, where
provided)
On a few versions, two cup holders
/ can holders / bottle holders (0.5
/ 0.75 litres) fig. 87 are available on
the central dashboard in the place
of the storage compartment.MOBILE PHONE
HOLDER
(for versions/markets, where
provided)
It is located on the central tunnel in
the position shown in fig. 88
DOOR POCKETS
There are oddment/document
pockets fig. 89 located in each of
the door panels.COMPARTMENT
BENEATH PASSENGER
SIDE FRONT SEAT
Proceed as follows to use the
compartment:
❒Open the flap A fig. 90 and remove it
as illustrated;
❒turn the lock knob B anticlockwise
and remove it to allow the
compartment to be removed.
REAR PARTITION
The vehicle may be equipped with
a solid rear partition or with a sliding
glass partition.
To open/close the sliding glass
partition use the knob A fig. 91.
86F1A0092
87F1A0327
88F1A0343
89F1A0093
90F1A0095
65

Certain outfits are equipped with a
protective grille on the window of
the partition inside the load
compartment.
CUP HOLDER - CAN
HOLDER
The cup/can holder is located in the
centre of the dashboard fig. 92.CIGAR LIGHTER
It is located in the centre of the
dashboard fig. 93.
Press button on the cigarette lighter
to switch it on when the ignition
key is turned to MAR-ON.
After about 15 seconds the button
will return to its original position
automatically and the cigar lighter is
ready for use.
31)
IMPORTANT Always check that the
cigar lighter has switched off.USB PORTS
(for versions/markets where
provided)
They can be located:
❒in the centre of the dashboard in
place of the cigar lighter and can
be used only as a charging source for
external devices;
❒on the central tunnel, above the
mobile phone holder fig. 94, to
connect to USB/iPod external
devices (see the Uconnect
Supplement).
91F1A0096
92F1A0307
93F1A0309
66
KNOW YOUR VEHICLE
94F1A0395

ACCESSORIES
PURCHASED BY THE
OWNER
If after buying the car, you decide to
install electrical accessories that
require a permanent electric supply
(alarm, satellite antitheft system,
etc.) or accessories that in any case
burden the electric supply, contact
a Fiat Dealership, whose qualified
personnel, besides suggesting
the most suitable devices from
Lineaccessori Fiat, will also evaluate
the overall electric consumption,
checking whether the car's
electrical system is able to
withstand the load required, or
whether it needs to be integrated
with a more powerful battery.
91)
INSTALLING
ELECTRICAL/
ELECTRONIC DEVICES
Electrical and electronic devices
installed after buying the car in the
context of after-sales service must
carry the following label: fig. 138.Fiat Auto S.p.A. authorises the
installation of transceivers provided
that installation is carried out at a
specialised centre, in a
workmanlike fashion and in
compliance with manufacturer's
specifications.
IMPORTANT Traffic police may not
allow the car on the road if devices
have been installed which modify
the features of the car. This may
also cause invalidation of warranty
in relation to faults caused by the
change either directly or indirectly
related to it.
Fiat Auto S.p.A. shall not be liable
for damage caused by the
installation of accessories either not
supplied or recommended by Fiat
Auto S.p.A. and/or not installed
in compliance with the instructions
provided.RADIO TRANSMITTERS
AND MOBILE PHONES
Radio transmitter equipment
(vehicle mobile phones, CB radios,
amateur radio etc.) cannot be
used inside the car unless a
separate aerial is mounted
externally.
IMPORTANT The use of these
devices inside the passenger
compartment (without an external
aerial) may cause the electrical
systems to malfunction. This could
compromise the safety of the car
in addition to constituting a
potential hazard for passengers'
health.
In addition, transmission and
reception of these devices may be
affected by the shielding effect of
the car body.
As far as the use of EC-approved
mobile phones is concerned (GSM,
GPRS, UMTS), follow the usage
instructions provided by the mobile
phone manufacturer.
138DISPOSITIVI-ELETTRONICI
108
KNOW YOUR VEHICLE

WARNING
114) Do not apply stickers or other objects to the steering wheel, the dashboard in the passenger side airbag area and
the seats. Never put objects (e.g. mobile phones) on the passenger side of the dashboard since they could interfere
with correct inflation of the passenger airbag and also cause serious injury to the passengers.
115) When an active passenger airbag is fitted, DO NOT install rear facing child restraint systems on the front seat.
Deployment of the airbag in an accident could cause fatal injuries to the child regardless of the severity of the
impact. Therefore, always deactivate the passenger airbag when a rear facing child restraint system is installed on
the front passenger seat. The front passenger seat must also be positioned back as far as possible in order to prevent
the child restraint system from coming into contact with the dashboard. Immediately reactivate the passenger airbag
as soon as the child restraint system has been removed.
174
SAFETY

IN AN EMERGENCY
A punctured tyre or a burnt-out
bulb?
At times, a problem may interfere
with our journey.
The pages on emergencies can
help you to deal with critical
situations independently and with
calm.
In an emergency we recommend
that you call the freephone number
found in the Warranty Booklet.
It is also possible to call the 00 800
3428 0000 freephone number to
search the nearest Fiat Dealership.STARTING THE ENGINE .................198
REPLACING A WHEEL ...................199
FIX & GO AUTOMATIC QUICK
TYRE REPAIR KIT ...........................204
CHANGING A BULB .......................208
REPLACING AN EXTERIOR BULB ..211
CHANGING AN INTERIOR BULB ....216
REPLACING FUSES........................217
BATTERY RECHARGING ................225
LIFTING THE VEHICLE....................226
TOWING THE VEHICLE ..................226
197

WARNING
189) Battery liquid is poisonous and
corrosive. Avoid contact with skin
and eyes. Keep naked flames
and sources of sparks away from
the battery: risk of explosion and
fire.
190) Using the battery with
insufficient fluid irreparably
damages the battery and may
cause an explosion.
191) Before performing any
operation on the electrical system,
disconnect the negative battery
cable through the suitable
terminal, after having waited at
least one minute from turning the
ignition key to STOP.
192) Always wear appropriate
goggles when working on or near
the battery.
IMPORTANT
52) Incorrect assembly of electrical
and electronic devices may cause
severe damage to your vehicle.
Contact a Fiat Dealership if you
want to install accessories after
purchasing the vehicle (alarms,
radiophone, etc.): they will
suggest the most suitable devices
and advise you whether a higher
capacity battery needs to be
installed.
53) If the vehicle needs to be off the
road for a long period under
conditions of intense cold, remove
the battery and take it to a
heated location, otherwise it may
freeze.
IMPORTANT
4) Batteries contain substances
which are very dangerous for the
environment. To replace your
battery, we recommend
contacting your Fiat Dealership to
dispose of your old battery in full
respect of the environment and in
compliance with all applicable
laws and regulations.
244
SERVICING AND MAINTENANCE
