PANORAMA VERSIONS
Adjustment of passenger seat
reclining backrest
Turn the knob A fig. 21.
Access to second row seats
To access the second row of seats,
operate the lever B fig. 21 on the right
outside seat in the first row and tilt
the backrest forward, accompanying it
with your left hand.When the seat is restored to its normal
position, it engages with the retaining
device without the need to operate the
lever again.
On the one-piece Panorama seat in the
second row both side seats are fixed.
Folding middle seat backrest (2nd -
3rd row)
Lift the lever C fig. 21 and tilt the
backrest forward.
A hard surface on the back of the
middle seat is for use as an armrest
and table with cup holders.
Operate the lever to reposition the
backrest.
To lower the backrest of the middle
seat in the second row, remove the
head restraint to make it easier to
adjust the backrest of the middle seat
in the first row.COMBI VERSIONS
Easy Entry position
Lift the lever A fig. 22 and tilt the
backrest forward.
Stacked position
Proceed as follows:
– remove the head restraints from the
easy entry position;
– lift the lever B fig. 23 (located under
the lever A fig. 22) with your right hand;
– turn the backrest 5° towards the
rear area;
– fold the backrest forward with your
left hand.
24)
Removing the bench
IMPORTANT At least two people are
needed to remove the bench.
20F1A0041
21F1A0034
22F1A0035
18
KNOWING YOUR VEHICLE
