High beams
– bulb replacement .......................... 138
– control ............................................ 49
– flashing ............................................ 49
High mounted brake lights
– bulb replacement .......................... 141
Identification data .............................. 178
Ignition................................................... 182
In an emergency............................ 123
Instrument board ................................ 6
Instrument panel ................................. 5
Instruments .......................................... 15
Interior equipment ............................. 58
Interior .................................................. 175
Isofix seat ............................................. 93
Jack ........................................................ 129
Keys ...................................................... 8
Lamps
– bulb types ....................................... 135
– general ............................................ 134
– interior bulb replacement .......... 142
– outer lighting bulb replacement 137
Lane change function ......................... 50
Low beams
– bulb replacement .......................... 138
– control ............................................ 49
Luggage rack/ski rack ......................... 72
Maintenance and care................ 155 – heavy duty use of vehicle ............ 161
– routine checks .............................. 161
– routine maintenance .................... 156
– service plan .................................... 157
Manual AC system ............................. 46
Max. speeds ......................................... 189
Multifunctional display ....................... 22
Number plate light
– bulb replacement .......................... 141
Oddments compartment.................. 58
Outer lights .......................................... 49
Paintwork (maintenance) ................ 174
Park sensors ........................................ 77
Parking lights
– bulb replacement .......................... 137
– control ............................................ 49
Performance ........................................ 189
Power socket ...................................... 59
Prolonged inactivity ............................ 110
Radio transmitters
and mobile telephones .................... 80
Raising the vehicle .............................. 153
Rear fog light
– bulb replacement .......................... 140
– control rear roof lights ..... 143-144
Rear view mirrors
– external .......................................... 39 Fluids and lubricants ........................... 193
Fog lights
– bulb replacement .......................... 139
– control ............................................ 56
Follow me home (device) ................. 50
Front roof lights ........................142-143
Front seat arm rest ............................ 58
Fuel cap ................................................. 82
Fuel system .......................................... 182
Fuel
– consumption .................................. 195
– economy ......................................... 106
– system shutoff ............................... 57
Fuel feed ............................................... 182
Fuses (replacement) ........................... 145
Glass cleaning ..................................... 51
Glove box ............................................ 58
Handbrake .......................................... 104
Hazard warning lights ........................ 56
Head rests ............................................ 38
Headlamps
– beam adjustment abroad ............73
– beam alignment ............................. 73
– leveling ............................................ 73
– trim adjust ...................................... 73
Heater system/
Heating and ventilation ................... 43
199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 200

201
WARNING
LIGHTS AND
MESSAGES
DASHBOARDAND CONTROLS
SAFETY
STARTING
AND DRIVING
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
Steering column controls
– left lever ......................................... 49
– right lever ....................................... 51
Steering lock ........................................ 14
Steering wheel ..................................... 38
Sun visors ............................................. 60
Suspensions .......................................... 183
Symbols ................................................. 7
Technical specifications............. 177
Tyres
– inflation pressures ........................ 186
– replacement ................................... 127
– snow tires .............................109-186
– standard .......................................... 186
– tire data .......................................... 184
Towing the vehicle ............................. 154
Trailer towing ...................................... 108
Transmission ........................................ 182
Trip computer ..................................... 31
Trunk
– emergency opening ...................... 67
– extension ........................................ 69
– load restraint ................................. 70
– shelf removal ................................. 68
Turn signal lights
– control ............................................ 50– front bulb replacement ............... 138
– lane change function .................... 50
– rear bulb replacement ................. 140
– side bulb replacement ................. 139
Ventilation .......................................... 41
Warning lights and messages.. 111
Weights ................................................ 190
Wheel (changing) ................................ 125
Wheel geometry ................................. 184
Wheel rims (correct reading) ..........185
Wheels and tyres ......................169-184
Window winders ................................ 66
Windshield washer
– control ............................................ 51
– liquid level ...................................... 164
Windshield wiper
– blades .............................................. 171
– control ............................................ 51
– intelligent wash ............................. 51
– nozzles ............................................ 172
Wiper blades ..............................171-172 – interior ........................................... 39
– power-operated ........................... 40
Refuelling .............................................. 81
Removable roof lamp ........................ 55
Right hand drive versions .......... 197
Roof lights
– bulb replacement
– on/off control ......................53-54-55
Roof struts
– retentions ....................................... 72
Rubber hoses ....................................... 170
Safety.................................................. 83
Saving fuel ............................................. 106
SBR system .......................................... 85
Seat belt pretensioners ..................... 86
Seat belts (use) .................................... 84
Seats
– adjustments .................................... 33
– cleaning ........................................... 176
– foldaway passenger seat .............. 34
– heated ............................................. 33
Snow chains ......................................... 110
Spark plugs (type) ............................... 181
Specifications ....................................... 177
Starting and driving...................... 101
Stationary vehicle ............................... 104
Steering ................................................. 183
199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 201

PROVISIONS FOR THE PROCESSING OF A VEHICLE
AT THE END OF ITS LIFE-CYCLE
For years now Fiat has been developing its global commitment towards the safeguarding and protection of the Environment through
the continuous improvement of its production processes and the making of increasingly more “eco friendly” products. With a view
to guaranteeing the best possible service to clients in full observance of environmental standards and in response to the obligations
imposed by European Directive 2000/53/EC on end-of-life vehicles, Fiat offers its clients the possibility to hand in their vehicle* at
the end of its life span without additional costs.
The European Directive, in fact, provides for the take-back of the vehicle without the last holder or owner of the same incurring
expenses due to the fact that the market value of the vehicle is zero or negative. In particular, in almost all of the countries of the
European Union, up until 1st January 2007, take-back of the vehicle free of charge only applies to vehicles registered from 1 July 2002
on, while, from 2007 on, take-back will be carried out free of charge, independently of the year of registration, provided that the
vehicle still contains all its essential component parts (especially engine and body) and is free from additional waste materials.
Our contracted network of authorised treatment facilities has been carefully selected in order to provide a quality service to our
customers by de-polluting and recycling “End of Life Vehicles” to approved environmental standards. To find out the location of your
nearest authorised treatment facility, offering free of charge take-back, simply contact one of our dealers or refer to the Fiat web
site or call the toll free number 00800 3428 0000.
*
Passenger transportation vehicles to seat a max. of nine persons, having a total admissible weight of 3.5 t
199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 202

N N
O O
T T
E E
S S
199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 203

199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 204

199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 205

199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 206

199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 207

ENGINE OIL CHANGE
1.4-1.3 Multijet
Tank capacity45
Reserve6÷7
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
FUEL CAPACITIES (litres)
Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia) - Print n. 603.81.344 - 01/2008 - 2ndediition
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
When running over 160 km/h, inflate tyres at full load inflation values.
1.4 1.3 Multijetlitres kg litres kg
Fuel tank 2.7 2.4 3.0 2.6
Engine sump and filter 3.0 2.6 3.2 2.8
COLD TYRE INFLATION PRESSURES (bar)
175/70 R14 2.5 2.5 2.5 2.5 2.5 2.5
185/65 R15 2.3 2.5 2.3 2.5 2.3 2.5 Tyre size TYRES SUPPLIED
Loadless Medium load Full load
Front Rear Front Rear Front Rear
199-208 Fiorino GB 2ed 8-02-2008 16:47 Pagina 208
