technical specifications FIAT FIORINO 2019 Owner handbook (in English)

Use Features SpecificationOriginal fluids and
lubricantsApplications /
Replacement
frequency
Protective agent for
radiatorsRed protective with
antifreeze action, based
on inhibited monoethyl
glycol with organic
formula. Exceeds CUNA
NC 956-16, ASTM D
3306 specifications.9.55523orMS.90032PARAFLUUP(*)
Contractual Technical
Reference N° F101.M01Percentage of use: 50%
demineralised water 50%
PARAFLU
UP(**)
Fuel additiveAdditive for diesel
antifreeze, protecting
diesel engines.—PETRONAS DURANCE
DIESEL ART(***)Contractual Technical
Reference N° F601.C06To be mixed with diesel
(25 cc per 10 litres)
Windscreen/rear
window washer fluidMixture of alcohol, water
and surfactants CUNA NC
956-II.9.55522orMS.90043PETRONAS DURANCE
SC 35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in windscreen
washer/wiper systems
Additive for diesel
emissions (UREA)Water-UREA solutionDIN 70 070orISO
22241–1
AdBlue®To be used for filling the
tank UREA on vehicles
equipped with system of
Selective Catalytic
Reduction (SCR).
(*)IMPORTANT Do not top up or mix with other fluids which have different specifications from those described.
(**)When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60%PARAFLUUPand 40% demineralised water.
(***) Recommended product.
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used to
top up; in this case optimal performance of the engine is not guaranteed.
For petrol engines running on methane, we recommend using the original product formulated specifically for this type of use.
The use of products with specifications below SAE 5W-40 ACEA C3 could cause damage to the engine not covered by the
warranty.
184
TECHNICAL DATA

In case of loss of the car radio
passport, contact the Fiat Dealership,
taking an ID document and the vehicle
ownership documents.
SETUP
The system consists of:
radio supply leads;
front door panel speaker cables;
rear speaker wires (located next to
parcel shelf) (for versions/markets,
where provided)
radio housing;
antenna wires.
SYSTEM TECHNICAL
SPECIFICATIONS
The system consists of:
radio supply leads;
front door panel speaker cables;
rear speaker wires (located next to
parcel shelf) (for versions/markets,
where provided)
2 tweeter located on rear-view mirror
trim;
2 mid-woofer Ø130 mm located on
the door;
rear speakers (optional, for
versions/markets, where provided);
2 full-range Ø100 mm speakers
located on the parcel shelf;
anti-theft protection system;
aerial;
radio with CD MP3 player.
190
MULTIMEDIA

WARNING
INTERIOR FITTINGS
Never travel with the glove compartment open: it could injure the passenger in the event of a crash.
The cigar lighter gets extremely hot. Handle it carefully and make sure children don't touch it: risk of fire and/or burning.
Do not use the ashtray as a waste paper basket: it may catch fire in contact with cigarette stubs.
Do not use the book rest in a vertical position with the vehicle in motion.
ROOF RACK/SKI RACK
Fully comply with the regulations in force concerning maximum clearance.
After travelling for a few kilometres, check to ensure that the fixing screws for the attachments are well tightened.
INTERIOR
Never use flammable products, such as petroleum ether or modified petrol, to clean the inside of the vehicle. The electrostatic charges
which are generated by rubbing during the cleaning operation may cause a fire.
Do not keep aerosol cans in the vehicle: they might explode. Aerosol cans must not be exposed to temperatures of more than 50°C.
When the vehicle is exposed to sunlight, the temperature inside can greatly exceed this value.
EOBD SYSTEM
If, when the ignition key is turned to MAR, thewarning light does not switch on, switches on constantly or flashes when driving (on
certain versions together with the message on the display), contact a Fiat Dealership as soon as possible. The operation of thewarning
light may be checked by the traffic police using specific devices. Comply with the laws and regulations of the country where you are driving.
WHEELS AND TYRES
You must not exceed 160 km/h on snow tyres with a “Q” mark; in any case, make sure you stick to the rules of the highway code.
POWER SUPPLY
Modifications or repairs to the supply system that are not carried out correctly or do not take the system technical specifications into
account can cause malfunctions leading to the risk of fire.
RIM PROTECTOR TYRES
DO NOT fit wheel hub caps when using integral hub caps fixed (with springs) to the steel rim and after sale tyres provided with a Rim
Protector. Use of unsuitable tyres and wheel caps may cause sudden decrease of tyre pressure.
203

WARNING
ROOF RACK/SKI RACK
Distribute the load evenly and pay attention to side winds when driving.
Never exceed the maximum permitted loads (see chapter "Technical specifications").
INSTRUMENT PANEL
If the needle for the engine coolant temperature reaches the red area, stop the engine immediately and contact a Fiat Dealership.
“COMFORT-MATIC" TRANSMISSION Messages on the display
If the warning light(together with the message in the display) continues to remain on in the panel, go to a Fiat Dealership.
If the message is still shown in the display, contact a Fiat Dealership.
To keep the clutch in good condition, do not use the accelerator to keep the car stationary (e.g. when stopped facing uphill); the clutch
could be damaged by overheating. Use the brake pedal instead and operate the accelerator only when you are ready to set off.
BODYWORK
Some automatic systems equipped with old generation blades and/or with a poor maintenance can damage the paint, promoting the
creation of microscoring which give an opaque/coated appearance to the paint, especially on dark colours. In this case, just lightly polish with
specific products.
WARNING
BODYWORK
Detergents pollute the environment. The vehicle should be washed in areas equipped for collecting and purifying the liquid used in the
washing process.
204
