warning light FIAT GRANDE PUNTO 2008 199 / 1.G Dualogic Transmission Manual

2 2
CONTENTS
DUALOGIC GEARBOX .................................................................................................................................................................................... 3
HOW TO MOVE OFF ....................................................................................................................................................................................... 3
OPERATION ......................................................................................................................................................................................................... 4
WARNING LIGHTS AND MESSAGES ........................................................................................................................................................... 10
TOWING THE CAR ........................................................................................................................................................................................... 13
IF A FUSE BLOWS ............................................................................................................................................................................................... 13
SERVICE SCHEDULE .......................................................................................................................................................................................... 14
CHECKING OIL LEVEL ...................................................................................................................................................................................... 14
AIR CLEANER ...................................................................................................................................................................................................... 14
ENGINE CODES - BODYWORK VERSIONS .............................................................................................................................................. 15
PERFORMANCE .................................................................................................................................................................................................. 15
TRANSMISSION .................................................................................................................................................................................................. 16
WEIGHTS .............................................................................................................................................................................................................. 17
CAPACITIES .......................................................................................................................................................................................................... 18
CO
2EMISSIONS .................................................................................................................................................................................................. 18
FUEL CONSUMPTION ...................................................................................................................................................................................... 19

5
To return to manual mode, set the gear
lever back to A/M.
With the car stationary and the key re-
moved, it is possible to shift the lever
with/without the brake pedal pressed. The
system will perform no actuation when
shifting the lever and the gear engaged will
be the one stored before removing the ig-
nition key.
IMPORTANT With the engine running, any
error between lever position and gear en-
gaged is indicated by a buzzer sounding un-
til restoring proper condition.MANUAL OPERATION
(MANUAL)
In this operating mode, the decision to
change gear is left to the driver who de-
cides the most appropriate moment.
To change gears in MANUAL operating
mode proceed as follows:
❒move the gear lever to +(UP)
fig. 1to engage higher gear;
or
❒move the gear lever to –(DOWN)
fig. 1to engage lower gear.
When shifting gears it is not necessary to
release the accelerator pedal.
The system will cut in preventing gearshift-
ing if the request to change gear could im-
pair regular operation of engine and trans-
mission.
The system will warn the driver that the
required gear will not be engaged through
the sound of the buzzer and a dedicated
message on the reconfigurable multifunc-
tion display (see paragraph “Warning
lights and messages”).
The system will shift gears automatically
when the engine reaches idle rpm (e.g.:
at slowing down).Do not rest your hand on the
gear lever when your are not
shifting gears or if you are in
Auto/Manual mode.
AUTOMATIC OPERATION
(AUTO)
For engaging/disengaging the automatic
operating mode (AUTO), move lever to
A/M fig. 3: automatic mode activation is
indicated by message AUTO fig. 5and
gear engaged on the reconfigurable multi-
function display.
fig. 5F F0
0M
M1
10
01
17
7g
g

7
If the ECOfunction is on, the reconfig-
urable multifunction display will show E
(Economy) next to the gear engaged
fig. 6.
IMPORTANT If after 10 seconds (with ig-
nition key to MAR) the display does not
show the gear engaged, turn the ignition
key to STOPand wait for the display to
turn off, then repeat system switch on. If
the fault persists, contact Fiat Dealership.STARTING THE ENGINE
The engine can be started either with a
gear engaged or in neutral (N); with gear
engaged always press the brake pedal first.
Before starting the engine, you are rec-
ommended to set the gear lever to neu-
tral (N).
After starting:
❒the gearbox sets to neutral (N) auto-
matically
❒lever keeps the same position it had be-
fore starting
❒the reconfigurable multifunction display
shows (N) and a buzzer will indicate if
the lever position and the gear engaged
are not matching
❒gears that can be engaged are: 1st, 2nd or
reverse gear (R), with brake pedal
pressed.IMPORTANT When trying to start the
engine with gearbox not in neutral (any
gearshift lever position other than N) and
without pressing the brake pedal, the re-
configurable multifunction display will
show a dedicated message (see paragraph
“Warning lights and messages”). In this
event, to start the engine just repeat op-
eration keeping the brake pedal pressed.
IMPORTANT Opening the driver’s door
will make the system activate the hydraulic
section in order to prepare it for next en-
gine starting.
fig. 6F F0
0M
M1
10
01
18
8i
i
If the engine fails to start with
the gear engaged, the driver
is informed of the potential-
ly dangerous situation due to
the fact that the gearbox is in neutral
by the buzzer.

10
WARNING LIGHTS
AND MESSAGESREDUCE GEARS
Warning light comes on (together with
the message on the reconfigurable multi-
function display) to warn the driver of the
incorrect use of the gearbox.
In this event, the system could automati-
cally activate system protection proce-
dure.MANUAL MODE NOT
AVAILABLE
The message on the reconfigurable mul-
tifunction display comes on when, with en-
gine on, the MANUALmode cannot be
selected. “DUALOGIC”
TRANSMISSION
FAILURE (red)
Turning the ignition key to MAR
the warning light shall come on, but it
should go off a few seconds after.
The warning light comes on flashing on the
cluster (together with the message on the
reconfigurable multifunction display and
the buzzer) to indicate a gearbox failure.
t
In the case of a gearbox
fault, contact Fiat Dealer-
ship as soon as possible to
have the system checked.
If the warning light continues
to stay on (together with the
message on the reconfig-
urable multifunction display),
contact Fiat Dealership.If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.
