FAST DEMISTING AND/OR DEFROSTING
Windscreen and side windows
1) Air temperature knob: pointer on red sector
(turned fully to the right).
2) Fan knob: pointer at maximum speed.
3) Air distribution knob: pointer at
-.
4) Air recirculation slider on
H, outside air enters the
passenger compartment.
In brief, to demist/defrost quickly, bring all the
pointers on the symbol
-.
When the windscreen and windows have been
demisted, adjust the controls to maintain the required
degree of comfort and visibility.
Rear window
Press button
(. The electric mirror demisting device
also comes on.
As soon as the rear window is clear, switch off the
button.VENTILATION
1) Centre and side vents: fully open.
2) Air temperature knob: pointer on blue sector.
3) Fan knob: pointer on required speed.
4) Air distribution knob: pointer on
¥.
5) Air recirculation slider on
H, outside air enters the
passenger compartment.
Extra heater
For very cold climates the diesel version can be fitted
with an extra heater that is fully automatic and ensures
maximum comfort inside the passenger compartment.
RECIRCULATION
With slider on
Tonly the inside air is circulated.
IMPORTANT This function is particularly useful when
the outside air is heavily polluted (in a traffic jam,
tunnel, etc.) However, it is better not to use it for long
periods, especially if there are several people in the
car.
IMPORTANT Do not use the air recirculation function
on rainy/cold days as it would considerably increase
the possibility of the windows misting inside.
