ENGINE OIL
The engine oil level must be checked with the car on level ground and
while the engine is still hot (approximately 5 minutes after turning it off).
❒Remove the dipstick.
❒Clean it with a cloth that does not leave threads or other impurities.
❒Put the dipstick into its seat pushing it down.
❒Take it out, the oil level shall be between the MIN and MAX marks on
the dipstick.
The space between the MIN and MAX marks corresponds to about one
litre of oil.
If the oil level is near or even below the MIN mark, add oil through the
filler neck until reaching the MAX mark.
Oil level shall never exceed the MAX mark.
F0E0166m
F0E0167m
100 16v version
JTD 120 version
