FIAT PANDA 2007 169 / 2.G Owners Manual

– snow tyres ..................................... 111
– standard tyres................................ 186
– understanding tyre marking ....... 184
Using the manual gearbox .............. 105
Ventilation ...............................39-41-46
Warning lights and messages ......... 113
Weights ................................................ 189
Wheel ................................................... 184
– changing .......................................... 126
– spare wheel ................................... 184
Wheel geometry ................................. 184
Wheel rims .......................................... 184
– understanding rim marking ........ 185
Window (washing/cleaning) ............. 174
Window winders................................. 59
Windscreen/rear window
washer fluid level ............................. 164
Windscreen/rear window
wiper blades ...................................... 172
Windscreen washer............................ 49
– control ............................................ 49
– fluid level ........................................ 164
Windscreen wiper............................... 49
– blades .............................................. 172
– control ............................................ 49
– nozzles ............................................ 179 – emergency start-up ...........103-124
– ignition switch ............................... 11
– jump starting .................................. 125
– petrol engines ............................... 102
– stopping the engine....................... 104
– warming up the engine ................ 103
Steering.................................................. 183
Steering column lock ......................... 12
Steering wheel (adjustment) ............ 36
Sunroof.................................................. 55
Sun visors ............................................. 53
Suspensions .......................................... 183
Symbols ................................................. 7
Tailgate ................................................ 60
Technical specifications ..................... 177
Third brake light ................................. 143
Tools ..................................................... 128
Top speeds ........................................... 188
Towing the car .................................... 153
Towing trailers .................................... 107
– tow hook installation ................... 108
Transmission ........................................ 182
Trip computer...................................... 29
Tyre pressure ...................................... 186
Tyres ..................................................... 184
– changing .......................................... 126
– inflation pressure .......................... 186
– maintenance .................................. 170
200
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
197-204 Panda New GB 21-06-2007 13:54 Pagina 200

PROVISIONS FOR THE PROCESSING OF A VEHICLE
AT THE END OF ITS LIFE-CYCLE
For years now Fiat has been developing its global commitment towards the safeguarding and protection of the Environment through
the continuous improvement of its production processes and the making of increasingly more “eco friendly” products. With a view
to guaranteeing the best possible service to clients in full observance of environmental standards and in response to the obligations
imposed by European Directive 2000/53/EC on end-of-life vehicles, Fiat offers its clients the possibility to hand in their vehicle* at
the end of its life span without additional costs.
The European Directive, in fact, provides for the take-back of the vehicle without the last holder or owner of the same incurring
expenses due to the fact that the market value of the vehicle is zero or negative. In particular, in almost all of the countries of the
European Union, up until 1st January 2007, take-back of the vehicle free of charge only applies to vehicles registered from 1 July 2002
on, while, from 2007 on, take-back will be carried out free of charge, independently of the year of registration, provided that the
vehicle still contains all its essential component parts (especially engine and body) and is free from additional waste materials.
Our contracted network of authorised treatment facilities has been carefully selected in order to provide a quality service to our
customers by de-polluting and recycling “End of Life Vehicles” to approved environmental standards. To find out the location of your
nearest authorised treatment facility, offering free of charge take-back, simply contact one of our dealers or refer to the Fiat web
site or call the toll free number 00800 3428 0000.
*
Passenger transportation vehicles to seat a max. of nine persons, having a total admissible weight of 3.5 t
197-204 Panda New GB 21-06-2007 13:54 Pagina 201

197-204 Panda New GB 21-06-2007 13:54 Pagina 202

197-204 Panda New GB 21-06-2007 13:54 Pagina 203

FUEL CAPACITIES (litres)
1.1 1.2 1.3 Multijet
Tank capacity 35 35 35
Reserve 5 5 5
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
Fiat Group Automobiles S.p.A. - Quality - Assistenza Tecnica - Ingegneria Assistenziale
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print N:. 603.81.224 - 07/2007 - 1
stEdition
COLD TYRE INFLATION PRESSURE (bar)
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm.
In any case, check the correct value again when the tyres are cold.
Medium load
Full load
Front
2.0
2.0
2.2
2.2
2.0Rear
1.8
1.8
1.8
1.8
1.8Front
2.2
2.2
2.3
2.3
2.2Rear
2.2
2.2
2.2
2.2
2.2Space-saverspare
wheel
2.8
2.8 Tyre
155/80 R 13 79T
165/65 R 14 79T (*)
155/80 R 13 79T
165/65 R 14 79T (*)
155/80 R 13 79T M+S
165/65 R 14 79T M+SVersions
Petrol
Multijet
Snow tyres
(*) Standard on Emotion versions and optional on Dynamic versions.
ENGINE OIL CHANGE (litres)
1.1 1.2 1.3 Multijet
Engine sump 3.1 2.5 2.85
Engine sump and filter 3.5 2.8 3.0
