technical specifications FIAT QUBO 2009 1.G Natural Power Manual

18
FIAT FIORINO/QUBO NATURAL POWER
Modifications or repairs to the fuel supply system that are not carried out properly or do not take the system’s
technical specifications into account can cause malfunctions leading to the risk of fire.
TRANSMISSION1.4
Gearbox
Clutch
Drive
SUSPENSION1.4
Front
Rear
BRAKES1.4
Service brakes:
– front
– rear
Parking brake
IMPORTANT Water, ice and salt on the roads may become deposited on the brake discs, reducing braking efficiency the first time
the brakes are applied.Disc
Drum
Controlled by hand lever, acting on rear brakes
Independent, McPherson type
Torsion beam
STEERING1.4
Type
Turning circle
(kerb to kerb) mRack and pinion with hydraulic power steering
9.95
Five forward speeds plus reverse with synchronisers for selecting forward gears
Hydraulic drive
Front
603.97.591 FiorinoQubo Nat P 1ed EN 1-12-2009 14:36 Pagina 18

22
FIAT FIORINO/QUBO NATURAL POWER
FUEL SYSTEM (methane)
Electronic injection specifically for meth -
ane.
Type: timed, sequential Multipoint.
Injection pressure: approx. 6 bar.
Stoichiometric metering of the air/meth -
ane gas mixture.
The methane injection system is con-
trolled by the dedicated control unit us-
ing the sensors already on the vehicle, in-
cluding the Lambda sensor for controlling
the fuel metering.
IGNITION
Static advance, electronic, integrated with
the injection.ENGINE COOLING SYSTEM
Engine cooling system with pressure re-
duction unit heating circuit subject to ex-
treme cooling during operation.
PERFORMANCE
Top speed in km/h.
Running on petrol:
– Cargo versions: .............................. 157
– Combi versions: ............................. 155
– Qubo versions: ................................ 155
Running on methane: ......................... 149
Modifications or repairs to
the fuel system that are not
carried out properly or do not take
the system technical specifications in-
to account can cause malfunctions
leading to a fire risk.
IMPORTANT
CO2EMISSIONS
CO2emissions according to the
current European directive (g/km)
CO2EMISSIONS Operation Operationpetrol methane
Combined 158 119
Urban 207 154
Extra-urban 129 98
Cargo/Combi/Qubo versions
603.97.591 FiorinoQubo Nat P 1ed EN 1-12-2009 14:36 Pagina 22

24
FIAT FIORINO/QUBO NATURAL POWER
Fiat Group Automobiles S.p.A. – Customer Services – Technical Services – Service Engineering
Largo Senatore G. Agnelli, 5 – 10040 Volvera – Torino (Italia)
Print No. 603.97.591 – 11/2009 – 1 Edition
For petrol engines running on methane, we recommend using the original product formulated specifically for this type of use.
The use of products with specifications below ACEA C3 – SAE 5W-40 could cause damage to the engine not covered by the warranty. Lubricants for
petrol/methane
enginesSAE 5W-40 ACEA C3
grade totally synthetic lubricant.
FIAT 9.55535-T2specification.SELENIA MULTIPOWER
GAS 5W-40
Contractual Technical
Reference No. F922.E09According
to annual maintenance
and inspection plan
FLUIDS AND LUBRICANTS
SPECIFICATIONS AND RECOMMENDED PRODUCTS
Use Quality specifications of fluids Genuine lubricants Interval
and lubricants for correct vehicle operation and fluids original replacement
