This Owner Handbook describes all Fiat SEDICI versions. As a consequence, you should consider only the
information which is related to the engine and bodywork version of the vehicle you purchased. Dear Customer,
Thank you for selecting Fiat and congratulations on your choice of a Fiat SEDICI.
We have written this handbook to help you get to know all your new vehicle features and use it in the best possible way.
You should read it right through before taking the road for the first time.
You will find information, tips and important warnings regarding the driving of your vehicle to help you derive the maximum from
your Fiat SEDICI technological features.
What’s more every single component of the Fiat SEDICI is fully recyclable. At the end of your vehicle’s useful lifespan any Fiat
Dealership will be pleased to make arrangements for your vehicle to be recycled and nature benefits in two ways: there’s no pol-
lution from waste disposal and the demand for raw materials is reduced.
The enclosed Warranty Booklet lists the services that Fiat offers to its Customers:

the Warranty Certificate with terms and conditions for maintaining its validity

the range of additional services available to Fiat Customers.
Best regards and good motoring!
