Page 17 of 254
GETTING TO KNOW YOUR CAR
16
ELECTRONIC
ALARM
(for versions/markets, where provided)
The vehicle is equipped with an elec-
tronic alarm with perimeter (external)
protection and volumetric (internal)
protection. To switch on the alarm,
press the button A-fig. 8on the re-
mote control.
This will be accompanied by the di-
rection indicator flashing and then the
red led on the dashboard A-fig. 9
flashing.
Door locking by turning the key
does not activate the alarm. When the alarm is triggered
The siren comes on, the direction in-
dicators and the headlights flash for
about 30 seconds when:
– - the doors, bonnet, boot or sun-
roof (for versions/markets, where
provided) are opened;
– a variation in the volume inside the
vehicle is experienced (do not leave the
windows open or animals inside the ve-
hicle when the alarm is switched on);
– if an attempt is made to neutralise
the alarm system without the remote
control.Switching the alarm system off
To switch the alarm system off, press
button B-fig. 8on the remote con-
trol.
The direction indicators will flash
rapidly for about 2 seconds.
If the alarm system has triggered, led
A-fig. 9will flash rapidly.
fig. 8
F0B0405b
fig. 9
F0B0003b
001-077 ULYSSE ING:001-077 ULYSSE ING 5-11-2009 12:11 Pagina 16
Page 113 of 254
GETTING TO KNOW YOUR CAR
112
LUGGAGE SEPARATING NET
fig. 159
(for versions/markets, where provided)
To install the luggage separating net,
proceed as follows:
– lift caps A, one on each side, next
to the second row supporting handles;
– fasten the net hooks Bto retain-
ers C;
– insert hooks D, one on each side,
in holes Eon the floor behind the sec-
ond row seats.B ONNET
To open the bonnet:
– lift cover A-fig. 160with the lever
next to the driver’s seat;
– pull lever B-fig. 160in the direc-
tion of the arrow;
– press lever C-fig. 161on the bon-
net;
Open the bonnet only
when the vehicle is sta-
tionary.
Warning. The bonnet
might fall violently if the
support rod is not posi-
tioned properly.
fig. 159
F0B0106bfig. 160
F0B0109b
fig. 162
F0B0110b
– lift the bonnet and, at the same
time, release the support rod D-
fig. 162from its clip E;
– place the tip of the rod Din recess
F-fig. 162in the engine compartment.
fig. 161
F0B0454b
078-135 ULYSSE ING 10-03-2009 11:39 Pagina 112
Page 114 of 254
GETTING TO KNOW YOUR CAR
113
To close the bonnet:
– keep the bonnet up with one hand
and with the other remove the sup-
port rod from the recess and replace
it in its clip;
– Lower the bonnet at approx. 20
cm from the engine compartment and
then let it drop, ensuring that it is ful-
ly closed and not just held in position
by the safety catch. If the bonnet does
not close properly do not push it
down but open it again and repeat the
above procedure.LUGGAGE
AND SKI RACKS
fig. 163
(for versions/markets, where provided)
To use them, proceed as follows:
– hooks are arranged in a special run-
ner along the roof of the vehicle;
– attach the roof rack with the brack-
ets Aplaced at the rack inside base
(2 for each bar). Absolutely prevent
shoes, ties and loose gar-
ments from coming into
contact with moving parts: they
could become entangled and
cause body harm.
If the engine is hot, be
very careful when you put
your hands under the
bonnet as you risk burning your-
self. Remember that while the
engine is hot, the electric fan can
start up and cause injury. Wait
for the engine to cool.
For safety reasons the
bonnet shall always be
perfectly closed when
travelling. Always check for prop-
er bonnet locking. If the bonnet
is left inadvertently open, stop
the car immediately and close
the bonnet.Always make sure the
bonnet is closed properly
so as to prevent it from
opening while travelling.
“Bonnet open” indication
(only available together with
alarm optional)
If, with engine running, the bonnet
is not shut properly, the multifunction
display will show a dedicated message
and the buzzer will sound.
fig. 163
F0B0179b
078-135 ULYSSE ING 10-03-2009 11:39 Pagina 113
Page 157 of 254
IN AN EMERGENCY
156
CHANGING A WHEEL
Please note:
– the jack weighs 3.4 kg;
– the jack requires no adjustments;
– the jack cannot be repaired. If it
breaks it must be replaced with a new
jack;
– no tool with the exception of the
handle can be fitted on the jack.
Proceed as follows:
1) Stop the car in a position that is
not dangerous for oncoming traffic
where you can change the wheel safe-
ly. The ground should be flat and ad-
equately firm. 2) Turn the engine off and pull up the
handbrake.
3) Engage first gear or reverse or, for
versions with automatic electronic
gear, select P.
4) Lift the boot mat (see the relative
instructions in the “Bonnet” paragraph
of “Getting to know your car” chap-
ter).
5) Remove lever A-fig. 3.6) Remove protective cover Band
use ring Cto release the elastic band
D, then extract jack E.
7) Close the bonnet and place the
tools next to the wheel to be changed.
8) Open the tailgate and use ringA-
fig. 4to lift and turn cap Bprotect-
ing the spare wheel lock bolt C.
fig. 3
F0B0118b
fig. 4
F0B0119b
153-183 ULYSSE ING:153-183 ULYSSE ING 13-11-2009 10:07 Pagina 156
Page 181 of 254
IN AN EMERGENCY
180
WITH AN ARM HOIST
Jack up the vehicle by arranging the
ends of the arms in the areas shown
in fig. 41:
A- front arm;
B- rear arm.TOWING THE CAR
A tow hitch is provided with the car
and is placed in the engine compart-
ment.
To fasten the tow hitch:
– open the bonnet (see the instruc-
tions given in the “Bonnet” paragraph
of “Getting to know your car” chapter);
– remove the tow hitch A-fig. 42
from its supports B;– remove cap Cclipped on the front
fig. 43or rear bumper fig. 44;
– fasten the hitch Aon the thread-
ed pin.
fig. 41
F0B0043b
fig. 42
F0B0044bfig. 43
F0B0156b
fig. 44
F0B0157b
153-183 ULYSSE ING:153-183 ULYSSE ING 13-11-2009 10:07 Pagina 180
Page 186 of 254
SERVICE SCHEDULE
30 60 90 120 150 180
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●
●●●
●
●●●●●●
CAR MAINTENANCE
185
Thousands of kilometres
Check tyre conditions/wear and adjust pressure if required
Check light system operation
(headlights, direction indicators, hazard lights, boot lights, passenger
compartment lights, glovebox lights, warning lights, horn)
Check windscreen wiper/washer operation, adjust nozzles if required
Check windscreen/rear window blade position/wear
Check front disk brake pad conditions and wear and pad wear
indicator operation
Check rear disk brake pad conditions and wear
Sight inspect the conditions of: body external parts, underbody protection, pipes
and hoses (exhaust - fuel - brakes), rubber parts (boots, sleeves, bushes, etc.)
Check cleanness of locks, bonnet and boot and lever cleanness and lubrication
Check and top up, if required, fluid levels (brakes/hydraulic clutch,
windscreen/rear window washer, battery, engine coolant, etc.)
Check and adjust handbrake lever stroke, if required
Sight inspect accessory drive belt conditions
Check accessory drive belt tension (for engines without automatic belt tightener)
Sight inspect timing belt conditions
Check exhaust emissions/smoke
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 185
Page 189 of 254
CAR MAINTENANCE
188
Should prevailing use of the vehicle
be under one of the following special-
ly heavy conditions:
– trailer or caravan towing;
– dusty roads;
– short distances (less than 7-8 km)
repeated and with external tempera-
tures below zero;– frequently idling engines or long
distance low speed driving (e.g. door-
to-door deliveries) or in case of a long
term inactivity;
– driving in the city;
carry out the following checks more
frequently than required in the Service
Schedule:
– check front disk brake pad condi-
tions and wear;– check cleanness of locks, bonnet
and boot and lever cleanness and lu-
brication;
– sight inspect the conditions of: en-
gine, gearbox, transmission, pipes and
hoses (exhaust - fuel - brakes), rubber
parts (boots, sleeves, bushes, etc.);
– check battery charge and fluid lev-
el (electrolyte);
– visual check on various drive belt
conditions;
– check and replace pollen filter, if re-
quired;
– check and replace air cleaner, if re-
quired.
HEAVY-DUTY
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 188
Page 190 of 254
Scarves, ties and loose
clothing may be caught in
the moving parts.Be careful not to mix up
the various types of fluids
when you are topping up:
they are all mutually incompati-
ble and could damage the vehicle.
CAR MAINTENANCE
189
CHECKING FLUID
LEVELS
IMPORTANT Open the engine
compartment according to the pro-
cedure described in the “Bonnet”
paragraph in the chapter “Getting to
know your vehicle”.Important. If the bonnet
support rod is not posi-
tioned correctly the bon-
net may fall violently.
Do not smoke while
working in the engine
compartment: the pres-
ence of flammable gas and
vapour could cause a fire.
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 189
Page 193 of 254
CAR MAINTENANCE
192
ENGINE OIL fig. 3-4
Check engine oil with the car on lev-
el ground and while the engine is still
warm (approximately five minutes af-
ter stopping the engine).
Extract dipstick Aand clean it, then
fully insert it again and check that the
level is between the MINand MAX
reference lines on the dipstick.
The space between the MINand the
MAXreference corresponds to ap-
proximately one litre of oil.Do not add oil with dif-
ferent specifications from
the oil already in the en-
gine.If the engine is hot, be
very careful when you put
your hands under the
bonnet as you risk burning your-
self. Remember that when the
engine is hot, the fan can start up
and cause injuries.
fig. 3
F0B0164b
fig. 4 - Versions 2.2 JTD
F0B0601b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 192
Page 204 of 254
CAR MAINTENANCE
203
USEFUL ADVICE FOR
LENGTHENING THE LIFE
OF YOUR BATTERY
To preserve the battery charge and
its functions, observe the following in-
structions:
– when you park the car, ensure the
doors, tailgate and bonnet are closed
properly. The ceiling lights must be off;
– the battery cables must be well fas-
tened;
– do not keep accessories (e.g.:
sound system, hazard lights, etc.)
switched on for a long time when the
engine is not running;
– before performing any operation
on the electrical system, disconnect
the battery negative cable.IMPORTANTA battery which is
kept at a charge of less than 50% for
any length of time will be damaged by
sulphation leading to a reduction in
cranking power and a higher risk of
the battery electrolyte freezing (this
may even occur at –10°C). If the car
is inactive for a long period of time, re-
fer to “Storing the car”, in “Getting to
know your car” section.If after buying the car, you want to
install electric accessories which re-
quire permanent electric supply, con-
tact a Fiat Dealership, whose qual-
ified personnel, in addition to sug-
gesting the most suitable devices be-
longing to the Lineaccessori Fiat, will
evaluate the overall electric absorp-
tion, checking whether the vehicle’s
electric system is capable of with-
standing the load required, or whether
it should be integrated with a more
powerful battery.
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 203
