7
%*
[IN06000(ALL)01/95]
Breaking Your Vehicle In
*
[IN06100(ALL)03/95]
Your new vehicle goes through an adjustment or
break-in period during the first 1,000 miles
(1,600 km) that you drive it. During the break-in
period, you need to pay careful attention to how
you drive your vehicle.
%*
[IN06300(ALL)01/95]
q
Avoid sudden stops.Because your vehicle
has new brake linings, you should take these
steps:
*
[IN06400(ALL)01/95]
Ð Watch traffic carefully so that you can
anticipate when to stop.
*
[IN06500(ALL)01/95]
Ð Begin braking well in advance.
*
[IN06600(ALL)01/95]
Ð Apply the brakes gradually.
*
[IN06700(ALL)01/95]
The break-in period for new brake linings
lasts for 100 miles (160 km) of city driving or
1,000 miles (1,600 km) of highway driving.
*
[IN06750(ALL)12/93]
q
Wheel lug nuts must be retightened to proper
torque specifications at 500 miles/800 km of
new vehicle operation. Proper torque
specifications are provided in this guide. Also
retighten to proper torque specification at 500
miles/800 km after any wheel change or any
other time the wheel lug nuts have been
loosened.
%*
[IN06800(ALL)01/95]
q
Use only the type of engine oil that Ford
recommends.SeeEngine oil recommendations
in the Index. Do not use special ªbreak-inº
oils.
File:02cpina.ex
Update:Tue Aug 29 17:33:02 1995

83 %
*
[LG07500(ALL)05/94]
Engine Oil Pressure Gauge
*
[LG07601(ALL)06/93]
This gauge indicates the engine's oil pressure,
not the oil level. However, if your engine's oil
level is low, it could affect the oil pressure. With
the engine running, the pointer should move
into the NORMAL band. If the pointer drops
below the NORMAL band while the engine is
running, you have lost oil pressure and
continued operation will cause severe engine
damage.
*
[LG07701(ALL)03/95]
If you lose engine oil pressure:
*
[LG07801(ALL)03/95]
1. Pull off the road as soon as safely possible.
*
[LG07901(ALL)04/95]
2. Shut off the engine immediately or severe
engine damage could result.
*
[LG08001(ALL)02/95]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil. Refer toEngine oilin the Index. If you
do not follow these instructions, you or
others could be injured. To assure an
accurate reading, your vehicle should be on
level ground.
*
[LG08051(ALL)03/93]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
*
[LG08200(ALL)03/93]
quarter page art:0020057-D
Engine oil pressure gauge
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

226
*
[RE00910(ALL)07/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE00950(ALL)06/95]
RWARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[RE01000(ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01100(ALL)03/95]
Preparing Your Vehicle
*
[RE01200(ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300(ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01400(ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
File:12cprea.ex
Update:Tue Aug 29 17:46:27 1995

269
*
[SV03800(ALL)08/94]
To close the hood, raise it so that the support
rod comes away from the slotted hole in the
hood. Place the support rod in its retaining clip
and close the hood with enough force to make it
latch. Be sure to oil the hood latch every six
months to maintain smooth operation.
*
[SV03900(ALL)05/90]
Always attempt to lift the hood after closing to
be sure it is securely latched.
%
*
[SV04500(ALL)04/95]
Engine Compartment
*
[SV04600(ALL)05/94]
Your vehicle has one of the following types of
engines:
*
[SV05455(ALL)08/95]
q
A 3.0 Liter SEFI, V-6 engine or
*
[SV05460(ALL)08/95]
q
A 4.0 Liter SEFI, V-6 engine.
*
[SV05500(ALL)11/94]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:15cpsva.ex
Update:Tue Aug 29 17:51:51 1995

282
%*
[SV13600(ALL)02/95]
Engine Oil Recommendations
*
[SV13610(ALL)03/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13650(ALL)03/95]
one third page art:0060021-E
The API Certification Mark
*
[SV13670(ALL)01/95]
Neveruse:
*
[SV13680(ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690(ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700(ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[SV13710(ALL)06/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13750(ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:15cpsva.ex
Update:Tue Aug 29 17:51:51 1995

283 %
*
[SV13775(ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800(ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[SV13900(ALL)03/95]
Checking the engine oil level:
*
[SV14000(ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14050(ALL)03/95]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[SV14100(ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200(ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300(ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[SV14400(ALL)06/95]
quarter page art:0095016-A
Engine oil dipstick
File:15cpsva.ex
Update:Tue Aug 29 17:51:51 1995

284
*
[SV14500(ALL)03/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QTº line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in Full, engine damage
or high oil consumption may occur and
some oil must be removed from the engine.
*
[SV14600(ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
%*
[SV14700(ALL)03/95]
Adding engine oil
*
[SV14800(ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000(ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%
*
[SV17300(ALL)03/95]
Engine Coolant
%*
[SV17400(ALL)03/95]
Checking the Engine Coolant
*
[SV17500(ALL)02/95]
NOTE: Be sure to read and understand
Precautions When Servicing Your
Vehicleat the beginning of this chapter.
*
[SV17700(ALL)08/95]
Your vehicle's engine coolant protects the engine
from overheating in the summer and from
freezing in the winter. Check the level of the
engine coolant at least once a month, but
preferably each time you stop for fuel. Simply
look at the engine coolant recovery reservoir
located in the engine compartment. To locate
this reservoir, see the diagram of your vehicle's
engine underEngine Compartmentin this chapter.
File:15cpsva.ex
Update:Tue Aug 29 17:51:51 1995

331
%*
[SV48600(ALL)03/95]
Emission Control System
*
[SV48700(ALL)05/95]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[SV48800(ALL)05/95]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[SV48900(ALL)01/95]
q
Use only unleaded fuel.
*
[SV49000(ALL)01/95]
q
Avoid running out of fuel.
*
[SV49100(ALL)01/95]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[SV49200(ALL)03/95]
q
Have the services listed in yourMaintenance
Schedule and Recordbooklet performed
according to the specified schedule.
*
[SV49300(ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[SV49400(ALL)05/95]
RWARNING
On vehicles without original equipment
floor covering or insulation, do not let
passengers ride in your truck in a manner
that allows contact between skin and the
metal floor.
*
[SV49500(ALL)05/95]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
File:15cpsva.ex
Update:Tue Aug 29 17:51:51 1995

343
*
[SV56600(ALL)01/95]
Body
*
[SV56700(ALL)01/95]
q
Wash vehicle thoroughly to remove dirt,
grease, oil, tar or mud from exterior surfaces,
rear wheel housing and underside of front
fenders.
*
[SV56800(ALL)01/95]
q
Periodically wash vehicles stored in exposed
locations.
*
[SV56900(ALL)01/95]
q
Touch-up raw or primed metal to prevent
rust.
*
[SV57000(ALL)01/95]
q
Cover chrome and stainless steel parts with a
thick coat of auto wax to prevent
discoloration. Re-wax as necessary when the
vehicle is washed.
*
[SV57100(ALL)04/95]
q
Lubricate all hood, door and trunk lid hinges
and latches with a light grade oil.
*
[SV57200(ALL)01/95]
q
Cover interior soft trim to prevent fading.
*
[SV57300(ALL)01/95]
q
Keep all rubber parts free from oil and
solvents.
%*
[SV57350(ALL)01/95]
Engine
*
[SV57400(ALL)01/95]
q
Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature.
*
[SV57500(ALL)01/95]
q
With your foot on the brake, shift through all
the gears while the engine is running.
%*
[SV57600(ALL)01/95]
Fuel system
%*
[SV57700(ALL)07/94]
q
Fill fuel tank with high-quality unleaded fuel
until the first automatic shutoff of the fuel
pump nozzle.
*
[SV57900(ALL)03/95]
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
File:15cpsva.ex
Update:Tue Aug 29 17:51:51 1995

Index 359
Index
A
Accessory position on the ignition..... 61
Additives, engine oil.......... 282
Air bag supplemental restraint system . . . 26
and child safety seats.......... 34
description............. 26,28
disposal................ 32
driver air bag........... 26,28
indicator light............. 81
operation............... 28
proper seating............. 27
service and information labels...... 28
tone generator............. 31
wearing safety belts........... 27
Air cleaner filter
location............... 269
specifications............. 337
Air conditioning
auxiliary heater and air conditioner . . . 98
manual heating and air conditioning
system............... 92
Alcohol, in fuel............. 277
Antenna, radio
(see Electronic sound system) . . . 149, 182
Antifreeze (see Engine coolant)...... 284
Anti-lock brake system (ABS)
description.............. 193
see also Brake............ 193
Appeals (see Dispute settlement board) . . 248
Assistance (see Customer assistance) . . . 245
Audio system
(see Electronic sound system)..... 149
Autolamp system (see Headlamps) . . 102, 104
File:cpixa.ex
Update:Tue Aug 29 17:47:05 1995
