Page 98 of 347
95 [CF66300(ALL)01/96]
5. Once the transmitter is installed, the
actuation peg on the door in line with your
transmitter button may need to be adjusted
for proper function. This can be done using
the button height adjustment pegs (located
on the compartment door). Add one peg at a
time until pressing the door actuates the
transmitter button (Figure 3).
[CF66400(ALL)01/96]
one third page art:0020877-A[CF66500(ALL)01/96]
6. By properly adjusting the actuation peg
height, you will be able to actuate your
garage door by pressing the door as shown
(Figure 4).
[CF66600(ALL)01/96]
one third page art:0020878-AFile:05cpcfa.ex
Update:Mon Jun 24 08:10:35 1996
Page 120 of 347
118
%*
[SS09775(ALL)03/96]
Safety Belt Maintenance
*
[SS09795(ALL)02/96]
Check the safety belt systems periodically to
make sure that they work properly and are not
damaged.
*
[SS09800(ALL)02/96]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
%*
[SS09805(ALL)05/96]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), shoulder belt height
adjusters (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
%*
[SS09875(ALL)01/96]
How to Untwist or Unjam a Safety Belt
Retractor
*
[SS09900(ALL)01/96]
If you should jam the lap belt retractor by
allowing the belt to retract when it is twisted,
you can free the webbing with this procedure:
*
[SS09925(ALL)01/96]
1. Pull on the belt with both hands to tighten it
on the retractor spool.
*
[SS09950(ALL)01/96]
2. Feed the belt back into the retractor until it
is completely retracted. Repeat previous step
if necessary.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996
Page 143 of 347
141 %
*
[SS30000(ALL)01/96]
Built-In Child Seat (If equipped)
[SS30010(ALL)05/96]
The second row bench seat may include an
optional built-in child safety seat. This child
restraint is to be usedonlyby children who are
at least one year old, weigh between 22 and 60
pounds (10 and 27 kilograms) and whose
shoulders (top) are below the shoulder harness
slots in the seatbacks with the headrest in the
full up position.
*
[SS30020(ALL)03/96]
If your child is less than one year old or weighs
less than 10 kilograms (22 pounds),alwaysuse a
rear facing infant or convertible seat because a
child of that size is not sufficiently developed to
withstand crash forces in a front facing position.
Follow the specific manufacturer's instructions
for weight and height restrictions.
*
[SS30030(ALL)08/95]
Children must be properly buckled before riding
in the vehicle. It is the law in every state and
province. This child seat conforms to all
Federal/Canadian motor vehicle safety
standards.
*
[SS30070(ALL)01/96]
Always adjust the lap and shoulder harness belts
provided with this child seat snugly around
your child.
*
[SS30080(ALL)03/96]
RWARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
*
[SS30090(ALL)01/96]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996
Page 165 of 347
165
*
[GF01150(ALL)01/96]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
%*
[GF01200(ALL)01/96]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
*
[GF01250(ALL)03/96]
RWARNING
Modifications to the suspension spring
rates and/or vehicle ride height may
adversely affect vehicle stopping ability.
*
[GF01300(ALL)03/96]
If Brakes Pull
*
[GF01350(ALL)03/96]
q
Check tire pressure.
*
[GF01400(ALL)03/96]
q
Perform the self-adjustment procedure
described underIf Brakes Do Not Grip Well or
Pedal is ªLow.º
*
[GF01450(ALL)03/96]
If pull occurs during the first 500 miles
(800 km), make 10 moderately fast stops from
40 mph (65 km/h) and then perform the
self-adjustment procedure above. It may be
necessary to repeat this operation to properly
seat new brake linings and pads.
%*
[GF01500(ALL)01/96]
Stopping Distances
*
[GF01550(ALL)01/96]
Stopping distances vary with different loads and
driving conditions. Use caution when
encountering new conditions and acquaint
yourself with vehicle performance. Take full
advantage of engine braking power when
slowing down.
File:09cpgfa.ex
Update:Wed Jun 5 12:04:06 1996
