headlamp FORD ASPIRE 1996 1.G Owners Manual

47
*
[ST04500(ALL)03/95]
Starting Your Vehicle
%*
[ST05000(ALL)05/94]
Preparing to Start Your Vehicle
*
[ST05100(ALL)05/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST05200(ALL)01/95]
Before you start your vehicle, do the following:
*
[ST05300(ALL)07/95]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST05400(ALL)03/95]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[ST05500(ALL)02/92]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
*
[ST05600(ALL)07/93]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
*
[ST05800(ALL)03/95]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to theWarning
Lights and Gaugeschapter.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

62
*
[LG04500(ALL)01/95]
High Beam Light
*
[LG04600(ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
*
[LG04700(ALL)01/92]
one inch art:0030174-A
High beam light
*
[LG05300(ALL)03/95]
Check Engine Warning Light
*
[LG05400(ALL)05/95]
This light comes on when the electronic engine
control system is not working properly. This is
the computer system that controls the operating
conditions of the engine.
*
[LG05450(ALL)09/93]
one inch art:0030175-B
Check engine warning light
*
[LG05600(ALL)05/95]
This light comes on briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
File:05iclgf.ex
Update:Wed Jan 24 14:32:51 1996

78
*
[IP17700(ALL)01/92]
Interior Lights
*
[IP20500(ALL)01/95]
Lighting Up the Interior and Instrument
Panel
*
[IP20600(ALL)01/92]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[IP20700(ALL)09/93]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[IP20850(ALL)09/93]
quarter page art:0032171-B
Dimmer control thumbwheel
[IP20900(ALL)09/93]
The dimmer control thumbwheel is located to
the right of the steering wheel on the instrument
panel.
[IP21800(ALL)05/93]
Interior Courtesy Lamp
[IP22500(ALL)07/95]
Your vehicle is equipped with an interior
courtesy lamp with a three-position switch.
[IP22600(ALL)05/95]
q
OFF-light will not turn on
[IP22700(ALL)05/95]
q
DOOR-light will turn on when the door is
open
[IP22800(ALL)05/95]
q
ON-light is always on in this position
File:06icipf.ex
Update:Wed Jan 24 14:47:07 1996

81
Steering Column Controls
*
[SC00300(ALL)01/95]
The controls on the steering column and wheel
are designed to give you easy access to the
controls while you are driving.
*
[SC00400(ALL)01/95]
The Turn Signal Lever
*
[SC00500(ALL)01/95]
You can use the turn signal lever on the left side
of the steering column to:
*
[SC00600(ALL)08/91]
q
operate the headlamps and parking lamps
*
[SC00700(ALL)03/95]
q
operate the turn signals and cornering lamps
*
[SC00800(ALL)01/95]
q
turn the high beams on/off
*
[SC00900(ALL)05/95]
q
flash the lamps
*
[SC00950(ALL)08/91]
Headlamps and Parking Lamps
*
[SC00975(ALL)01/92]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[SC01000(ALL)09/93]
FIRST STOP Ð Turning the knob to the first
stop will turn on the license plate lamps,
parking lamps, side marker lamps, tail lamps,
and instrument panel lamps.
[SC01050(ALL)09/93]
SECOND STOP Ð Turning the knob to the
second stop will turn on the headlamps, license
plate lamps, parking lamps, side marker lamps,
tail lamps, and instrument panel lamps.
File:07icscf.ex
Update:Wed Jan 24 14:50:00 1996

82 [SC01075(ALL)05/93]
quarter page art:0032172-AHeadlamp and parking lamp control
[SC01090(ALL)05/93]
Headlamps On Chime
[SC01100(ALL)05/93]
This chime will sound when a door is opened
while the headlamps or parking lamps are on.
[SC01104(ALL)04/95]
Cleaning the Exterior Lamps
[SC01106(ALL)04/95]
Do not use dry paper towel, chemical solvents
or abrasive cleaner to clean the lamps, as they
may cause scratches or crack the lights.
*
[SC01110(ALL)01/95]
Daytime Running Light System
*
[SC01115(ALL)03/95]
(Canadian vehicles only)
*
[SC01120(ALL)06/95]
In Canada, certain regulations require vehicles to
be driven with lights illuminated during daytime
operation. The Daytime Running Light system
(DRL) automatically illuminates when the
ignition switch is turned to the ON position. The
daytime running lights are switched off under
the following conditions:
*
[SC01130(ALL)05/95]
q
when the headlamps are switched on
*
[SC01140(ALL)01/92]
q
when the parking brake is applied
*
[SC01150(ALL)01/92]
q
when the flash-to-pass system is used
File:07icscf.ex
Update:Wed Jan 24 14:50:00 1996

83
*
[SC01175(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system
will not illuminate the tail lamps and
parking lamps. Turn on your headlamps
at dusk. Failure to do so may result in a
collision.
*
[SC02075(ALL)05/95]
High Beams and Flashing the Lamps
*
[SC02080(ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
[SC02085(ALL)02/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
*
[SC02090(ALL)07/95]
Flashing the Lights
*
[SC02091(ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
[SC02092(ALL)03/94]
quarter page art:0032173-B
High beam and flash-to-pass operation
File:07icscf.ex
Update:Wed Jan 24 14:50:00 1996

101
*
[FV18200(ALL)01/95]
Mirrors
[FV18250(ALL)07/95]
Rearview Mirror
[FV18400(ALL)05/95]
You can adjust your rearview mirror in any
direction. The special swivel bracket lets you
move the mirror up or down and from side to
side.
*
[FV18500(ALL)07/95]
You can tilt the mirror from day to night
position to reduce the glare from the headlamps
of vehicles behind you. Move the tab toward
you for the night position and away from you
for the day position.
[FV18900(ALL)12/93]
one third page art:0030106-B
The day/night rearview mirror
*
[FV19100(ALL)05/95]
Side View Mirrors
[FV19150(ALL)02/95]
Your vehicle has left-hand and right-hand side
view mirrors. The mirrors can either be adjusted
manually or remotely with the control levers,
depending on the type your vehicle has. The
mirror heads can be folded rearward to prevent
damage when using an automatic car wash.
File:08icfvf.ex
Update:Wed Jan 24 14:51:07 1996

173
Servicing Your Aspire
*
[SV00300(ALL)03/95]
Service Made Easy
*
[SV00400(ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(ALL)01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(ALL)01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(ALL)01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(ALL)01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(ALL)05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV00925(ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
[SV00930(ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

224
*
[SV38800(ALL)03/95]
Lights and Bulb Replacement
*
[SV38900(ALL)01/95]
It is a good idea to check the operation of the
following lights frequently:
*
[SV39000(ALL)01/95]
q
headlamps
[SV39050(ALL)02/95]
q
high mount brakelamp
*
[SV39100(ALL)01/95]
q
tail lamps
*
[SV39200(ALL)01/95]
q
brakelamps
*
[SV39300(ALL)01/95]
q
hazard flasher
*
[SV39400(ALL)01/95]
q
turn signals
*
[SV39500(ALL)01/95]
q
side markers
*
[SV39600(ALL)01/95]
q
license plate lamp
*
[SV39700(ALL)02/95]
q
fog lamps
*
[SV39800(ALL)01/95]
The alignment of your headlamps should be
checked if:
*
[SV39900(ALL)01/95]
q
oncoming motorists frequently signal you to
turn off your vehicle's high beams when you
do not have the high beams on
*
[SV40000(ALL)01/95]
q
the headlamps do not seem to give you
enough light to see clearly at night
*
[SV40100(ALL)01/95]
q
the headlamp beams are pointed substantially
away from a position slightly down and to
the right
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

225
*
[SV40200(ALL)03/95]
Headlamp Bulb
*
[SV40400(ALL)01/95]
The headlamps on your vehicle use replaceable
bulbs. When the lamp burns out, simply replace
the bulb, rather than the whole lamp.
*
[SV40500(ALL)05/95]
RWARNING
Handle a halogen headlamp bulb carefully
and keep out of children's reach. Grasp
the bulb only by its plastic base and do
not touch the glass. The oil from your
hand could cause the bulb to break the
next time the headlamps are operated.
*
[SV40600(ALL)01/95]
Do not remove the burned-out bulb unless you
can immediately replace it with a new one. If a
bulb is removed for an extended period of time,
contaminants may enter the headlamp housing
and affect its performance.
*
[SV40700(ALL)03/95]
Removing the headlamp bulb
*
[SV40800(ALL)05/95]
1. Make sure that the headlamp knob is in the
OFF position.
*
[SV40900(ALL)02/95]
2. Lift the hood and find the bulb in the
headlamp socket.
[SV41000(ALL)05/93]
3. Remove the electrical connector from the
bulb housing by pushing the locking tabs on
either side and pulling out the connector.
[SV41100(ALL)05/93]
4. Remove the retaining ring by turning it 1/8
of a turn to free it from the socket. Then
slide the ring off.Keep the ring.You must
use it again to hold the new bulb in place.
[SV41125(ALL)05/93]
5. Remove the rubber boot. Save it because
you'll need it to cover the new bulb.
[SV41150(ALL)05/93]
6. Release the metal retaining clip that holds
the bulb in place.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996
