182
*
[DR11100( ALL)06/94]
Forced Downshifts
*
[DR11200( ALL)04/95]
To gain extra acceleration injOverdrive or
Drive (O/D OFF), push the accelerator to the
floor. The transmission will automatically
downshift to the appropriate gear: third, second
or first.
*
[DR11235( ALL)03/94]
Power Braking
*
[DR11275( ALL)03/94]
Increasing the engine speed above idle without
vehicle movement (such as holding the brake) in
a forward or reverse gear causes transmission
stall.
*
[DR11285( ALL)03/94]
NOTE: Continued operation in the stall
condition can result in transmission
overheat, malfunction or fluid
expulsion.
*
[DR11300(B F )03/95]
Driving with a Manual
Transmission
%*
[DR11400(B F )03/95]
Using the Clutch
*
[DR11500(B F )01/95]
Make sure the gearshift lever is in the N
(Neutral) position and your right foot is holding
down the brake pedal. Then press the clutch
pedal to the floor with your left foot. Manual
transmission vehicles have a starter interlock
switch. The starter will not crank until the clutch
pedal is fully depressed. Start the engine and
allow it to idle for a few seconds. Move the
gearshift into 1 (First) or R (Reverse).
*
[DR11600(B F )03/91]
To move the vehicle, release the clutch slowly
and at the same time press down slowly on the
accelerator so that the vehicle accelerates.
*
[DR11700(B F )03/95]
Do not drive with your foot resting on the
clutch pedal and do not use the clutch to hold
your vehicle at a standstill while waiting on a
hill. These actions will seriously reduce clutch
life.
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995
ProCarManuals.com

313
*
[SV33305( ALL)05/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
%*
[SV33400( ALL)05/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
*
[SV33500( ALL)01/95]
Automatic Transmission Fluid
*
[SV33601( ALL)04/95]
Under normal driving conditions automatic
transmission fluid should be changed every
30,000 miles (48,000 km) or 21,000 miles
(34,000 km) if under severe duty conditions.
However, if the transmission is not working
properly, for instance, the transmission may slip
or shift slowly, or you may notice some sign of
fluid leakage, the fluid level should be checked.
[SV33605( ALL)04/95]
NOTE: Except E4OD transmission, there is no
30,000 mile (48,000 km) sheduled
transmission fluid change requirement.
[SV33615( ALL)05/95]
Transmission fluid, filter and seal assembly
should be changed every 21,000 miles
(34,000 km) only under any of the following
conditions.
[SV33620( ALL)04/95]
q
Extended periods of high speed driving
during hot weather at/or above+90ÊF
(+30ÊC).
[SV33625( ALL)04/95]
q
Towing a trailer for distances over 1,000 miles
(1,600 km) per trip.
[SV33630( ALL)04/95]
q
Accumulating 5,000 miles (8,000 km) or more
per month.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

314 [SV33635( ALL)04/95]q
Continuous operation and/or extensive idling
(a delivery service as an example).
[SV33640( ALL)04/95]
q
Operating in severe dust conditions.
[SV33645( ALL)04/95]
NOTE: Use of a transmission fluid other than
specified could result in transmission
malfunction and/or failure. Refer to
ªAdding automatic transmission fluidº,
ªRefill capacitiesº and ªlubricant
specificationsº for further information.
%*
[SV33651( ALL)02/95]
Checking the Automatic Transmission
Fluid
*
[SV33701( ALL)02/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (32 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (32 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
*
[SV33801( ALL)01/95]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off for about 30 minutes to
allow the fluid to cool before checking.
*
[SV33910( ALL)12/91]
With the vehicle on a level surface, start the
engine and move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage. Securely latch
the transmission shift selector in the Park (P)
position, fully set the parking brake and leave
the engine running.
*
[SV33920(B F )06/94]
NOTE: Vehicles equipped with the 4x4 option
must have the 4x4 shift selector in any
position other than neutral.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

315
*
[SV33930( ALL)10/89]
RWARNING
Your vehicle should not be driven if the
fluid level is below the bottom hole on
the dipstick and outside temperatures are
above50ÊF (10ÊC).
*
[SV33940( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
*
[SV33950( ALL)03/90]
When checking fluid at normal operating
temperature, the fluid level should be within the
crosshatched area on the dipstick. When the
vehicle has not been driven, and outside
temperature is above50ÊF (10ÊC), thefluid level
should be between the holes on the dipstick.
%*
[SV33960( ALL)05/95]
Adding Automatic Transmission Fluid
*
[SV33970( ALL)03/94]
The fluid type is stamped on the dipstick. Before
adding any fluid, be sure that the correct type
will be used.
*
[SV33980( ALL)10/89]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level to the correct
area on the dipstick. If an overfill occurs, excess
fluid should be removed by a qualified
technician.
%*
[SV33990( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

316
*
[SV34000(B FM)06/92]
quarter page art:0020372-E
Automatic transmission dipstick
[SV34400(B F )01/95]
Manual Transmission and
Transfer Case Fluid
[SV34600(B F )01/95]
Checking the fluid
*
[SV34700(B F )12/91]
Clean the filler plug on the side of the case.
Remove the filler plug. The fluid level should be
up to the bottom of the filler plug hole.
*
[SV34800(B F )03/91]
If additional fluid is required:
[SV34900(B F )01/95]
1. Add enough fluid through the filler plug
hole to bring the level up to the bottom of
the hole. Use only fluid certified to meet
Ford Motor Company lubricant specification
as listed underA Quick Reference for Refill
Capacities and Motorcraft Parts, later in this
section.
*
[SV35000(B F )03/91]
2. Replace the filler plug in its original
position, making sure it is fully seated.
%
*
[SV35100(B F )02/95]
The Clutch
*
[SV35200(B F )03/91]
The clutch on your vehicle is automatically
self-adjusting and should not require any routine
service.
*
[SV35301(B F )03/91]
During normal operation the fluid level in the
clutch reservoir will slowly rise. If for any
reason the fluid level drops, maintain the fluid
level at the step in the reservoir body.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

321
*
[SV38600(B F )10/90]
quarter page art:0020386-B
Power steering reservoir
*
[SV38800( ALL)07/94]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
*
[SV38900(BEF )01/95]
Use only power steering fluid that:
*
[SV39000(BEF )01/95]
q
meets Ford's Specification ESW-M2C33-F,
such as Ford Premium Power Steering Fluid,
E6AZ-19582-AA or an equivalent Type F
Automatic Transmission Fluid with a Ford
registration number (an 8-digit number
beginning with ª2Pº printed on the fluid
container).
*
[SV39200( ALL)01/95]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[SV39300( ALL)03/95]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
*
[SV39400( ALL)02/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately 50 to85ÊF (10 to 30ÊC).
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

Index 363
Index
A
ABS warning light
(see Anti-lock brake system)....... 77
Accessory position on the ignition..... 60
Accessory power source,
power point outlet.......... 148
Additives, engine oil.......... 291
Air bag supplemental restraint system
description............... 25
disposal................ 32
driver air bag............. 25
indicator light............. 81
operation............... 27
proper seating............. 27
service and information labels...... 32
tone generator............. 29
wearing safety belts........... 26
Air conditioning, manual heating and air
conditioning system........... 90
Alarm, activating remote personal.... 122
Alcohol, in fuel............. 285
Ambulance packages........... 5
Antifreeze (see Engine coolant)...... 295
Anti-lock brake system (ABS)
description.............. 204
noise................ 205
see also Brake............ 203
warning light.............. 77
Assistance (see Customer assistance) . . . 255
Audio system
(see Electronic sound system)..... 149
Automatic transmission, fluid, refill capacities 344
Automatic transmission
driving an automatic overdrive.... 175
fluid, adding............. 315
File:ltixb.ex
Update:Fri Jun 9 15:21:14 1995
ProCarManuals.com

364 Index
Automatic transmission (continued)
fluid, checking............ 314
fluid, specification........... 347
Axle
lubricant specifications......... 347
traction lok............212, 305
B
Backing up............... 178
Basic vehicle warranty........... 4
Battery
acid, treating emergencies.....237, 312
battery saver............. 125
charging system warning light...... 81
how to service............ 311
jumping a disabled battery....... 237
maintenance-free........... 311
proper disposal, recycling....... 312
replacement, specifications....... 346
voltage gauge.............. 82
when storing your vehicle....... 352
Brake fluid
brake warning light........... 76
specifications............. 319
Brakelamp, high-mount brakelamp . . 101, 336
Brakes
adjustment.............. 203
anti-lock............... 204
anti-lock brake system (ABS)
warning light............. 77
applying the brakes.......... 207
brake warning light........... 76
fluid, checking and adding....... 318
fluid, refill capacities......... 344
fluid, specifications.......... 319
front disc............... 203
if brakes do not grip well....... 206
new brake linings............ 7
parking............... 208
stopping distances........... 207
File:ltixb.ex
Update:Fri Jun 9 15:21:14 1995
ProCarManuals.com

Index 367
Controls
instrument panel............ 89
mirrors............... 139
steering column........... 105
Coolant (see Engine coolant)
checking and adding......... 295
drain and flush............ 299
preparing for storage......... 352
proper solution............ 297
refill capacities............ 344
specifications............. 298
temperature gauge........... 85
Cruise control (see Speed control).... 111
Customer Assistance Center, Ford (U.S.). . 257
Customer Assistance Centre,
Ford of Canada............ 257
D
Dashboard (see Instrument panel)..... 89
Daytime running light system....... 99
Defrost, rear window........... 97
Dipstick
automatic transmission fluid....313, 315
power steering fluid......... 320
Dispute Settlement Board........ 258
Doors................. 119
Driveline universal joint and slip yoke . . 317
Driving under special conditions
bad weather............. 211
heavy load.............. 214
high speed.............. 211
high water.............. 213
slippery roads............ 211
E
Electrical system
circuit breakers............ 332
fuses................ 322
operating when the engine is off..... 60
File:ltixb.ex
Update:Fri Jun 9 15:21:14 1995
ProCarManuals.com

374 Index
Lug nuts, tightening sequence...... 249
Lumbar support, seats.......... 134
M
Maintenance schedule and record
(see separate Maintenance Schedule
and Record booklet)........... 3
Maintenance (see Servicing)....... 275
Manual transmission
clutch................ 316
driving................ 182
fluid, checking and adding....... 316
lubricant specifications......... 347
shifting gears............. 183
shift speeds.............. 185
Master cylinder, brakes......... 318
Mileage, calculating fuel economy..... 289
Mirrors
automatic dimming rearview mirror . . 136
dual electric remote control...... 139
rearview............... 135
side view mirrors (manual)...... 137
Motorcraft parts............. 346
N
National Highway Traffic Safety
Administration............ 262
O
Octane rating.............. 284
Odometer................. 87
Off road driving, 4-wheel drive...... 200
Oil filter................ 346
Oil (see Engine oil)........... 290
On-board diagnostic (OBD II) system . . . 341
Order forms, service information..... 267
Overdrive................ 179
File:ltixb.ex
Update:Fri Jun 9 15:21:14 1995
ProCarManuals.com
