maintenance schedule FORD BRONCO 1988 Owners Manual

3
*
[IN01600( ALL)04/95]
Finding Information in This Guide
[IN01700( ALL)04/95]
After you have read this guide once, you will
probably return to it when you have a specific
question or need additional information. To help
you find specific information quickly, you can
use the table of contents or the index.
*
[IN01800(BEF )05/95]
TheQuick Indexat the end of the book
provides a page number following each item
which indicates where detailed information can
be found.
*
[IN02000( ALL)05/95]
This guide has atable of contentsat the
beginning of the book to show chapter titles.
*
[IN02100( ALL)04/95]
To use theIndex, turn to the back of the book
and search in the alphabetical listing for the
word that best describes the information you
need. If the word you chose is not listed, think
of other related words and look them up. We
have designed the Index so that you can find
information under a technical term.
%*
[IN02200( ALL)04/95]
Canadian Owners Ð French Version
*
[IN02300( ALL)05/95]
French Owner Guides can be obtained from your
dealer or by writing to Ford Motor Company of
Canada, Limited, Service Publications, P.O. Box
1580, Station B, Mississauga, Ontario L4Y 4G3.
*
[IN02400( ALL)04/95]
Your Maintenance Schedule and
Record Booklet
*
[IN02500( ALL)03/95]
TheMaintenance Schedule and Recordbooklet lists
the services that are most important for keeping
your vehicle in good condition. A record log is
also provided to help you keep track of all
services performed.
File:ltinb.ex
Update:Fri Jun 9 15:32:32 1995
ProCarManuals.com

233
*
[DR38925( ALL)01/95]
Servicing your vehicle if you tow
*
[DR38950( ALL)08/93]
If you tow a trailer for a long distance, your
vehicle will need to be serviced more frequently
than usual. Refer to theMaintenance Schedule and
Recordbooklet for additional information.
*
[DR39000( ALL)01/93]
Trailer towing tips
*
[DR39100( ALL)11/89]
Before starting on a trip, practice turning,
stopping and backing in an area away from
heavy traffic. Get to know the ªfeelº of the
vehicle/trailer combination.
*
[DR39200( ALL)05/90]
Practice backing up. Back up very slowly, with
someone outside at the rear of your trailer to
guide you. Place your hand at the bottom of the
steering wheel and move it in the direction you
want the rear of the trailer to swing. Slight
movement of the steering wheel results in a
much larger movement of the rear of the trailer.
*
[DR39300( ALL)11/89]
Allow more room for stopping with a trailer
attached. Trailer brakes should be applied first,
whether manually or automatically controlled,
when approaching a stop.
*
[DR39400( ALL)11/89]
For a good handling truck-trailer combination,
the trailer tongue load should be approximately
10-15% of the loaded trailer weight.
*
[DR39500( ALL)05/95]
Make a thorough check of your equipment
before starting out on the road. After you have
traveled about 50 miles (80 km) stop in a
protected area and double-check your hitch and
electrical connections. Also check trailer wheel
lug nuts for tightness.
File:ltdrb.ex
Update:Fri Jun 9 15:26:57 1995
ProCarManuals.com

249
*
[RE22300(BEF )01/95]
7. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration.
*
[RE22400(B )12/89]
quarter page art:0020312-B
Lug nut tightening sequence
*
[RE23400(BEF )05/95]
RWARNING
Use of wheels or lug nuts other than
original equipment could cause damage to
the wheel or mounting system and allow
the wheels to come off while the vehicle
is in motion.
*
[RE23500(BEF )01/95]
8. Replace any wheel covers, ornaments, or hub
caps that your vehicle has. Make sure that
they are screwed or snapped into place.
[RE23615(BEF )02/95]
9. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
*
[RE23700(BEF )01/95]
10. Unblock the wheels.
*
[RE23800(B )06/93]
Retighten the wheel lug nuts to the specified
torque at 500 miles (800 km) of new vehicle
operation and at intervals specified in the
Maintenance Schedule and Recordbooklet.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

275
Servicing Your Bronco
%*
[SV00300( ALL)03/95]
Service Made Easy
*
[SV00400(BEF )01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(BEF )01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(BEF )01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(BEF )01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(BEF )01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(BEF )05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000( ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100( ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

276
*
[SV01300( ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
vehicle. In addition to the conditions listed in
theOwner Maintenance Checklist, be alert for any
unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice
something unusual, see that your vehicle is
serviced promptly.
*
[SV01600(BEF )03/95]
Precautions When Servicing Your
Vehicle
*
[SV01700(BEF )01/95]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[SV01900( ALL)03/95]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[SV02000(BEF )01/95]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[SV02100(BEF )01/95]
q
Never get under a vehicle while it is
supported by a jack only. If you must work
under a vehicle, use safety stands.
*
[SV02200(BEF )01/95]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[SV02500( ALL)03/95]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

290
*
[SV12500( ALL)05/95]
Improving Fuel Economy
*
[SV12600( ALL)05/95]
Fuel economy is affected by a number of
variables which can reduce efficiency. You can
improve fuel economy by understanding these
variables and minimizing their effect.
*
[SV12700( ALL)05/95]
The following decrease fuel economy:
*
[SV12800( ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12900( ALL)05/95]
q
Driving with your foot on the brake
*
[SV13000( ALL)05/95]
q
Sudden stops
*
[SV13100( ALL)05/95]
q
Excessive speed
*
[SV13200( ALL)05/95]
q
Extended engine idling
*
[SV13300( ALL)05/95]
q
Heavy loads
*
[SV13400( ALL)05/95]
q
Underinflated tires
*
[SV13500(BEF )05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13550(BEF )05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
*
[SV13600( ALL)02/95]
Engine Oil Recommendations
*
[SV13610( ALL)04/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

291
*
[SV13655( ALL)03/95]
one third page art:0060020-D
The API Certification Mark
*
[SV13670( ALL)01/95]
Neveruse:
*
[SV13680( ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690( ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700( ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
[SV13701(B )06/95]
For vehicles with 5.8L engines
*
[SV13710(BEF )03/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13725( ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
[SV13735(B )03/95]
For vehicles with 5.0L engines
[SV13740( ALL)04/95]
Engine oils with anSAE 10W-30viscosity are
PREFERREDfor your vehicle which provide the
best engine protection for all climates down to
-5ÊF (-20ÊC). SAE5W-30 engine oils may also be
used down to-15ÊF (-25ÊC).
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

292 [SV13745( ALL)02/95]Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
*
[SV13900( ALL)03/95]
Checking the engine oil level:
*
[SV14000( ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14050(B F )03/95]
2. Set the parking brake, making sure that the
gearshift is securely latched in P (Park)
(automatic transmission) or 1 (First) (manual
transmission).
*
[SV14100( ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200( ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300( ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
*
[SV14400( ALL)05/94]
quarter page art:0010364-D
Engine oil dipstick
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

294
*
[SV16625( ALL)03/95]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
*
[SV16650(BEF )03/95]
If you are using your Ford vehicle in a manner
which allows it to remain stationary while the
engine is running for long periods (door to door
delivery, taxi, police, power/utility company
trucks, or similar duty), then Ford recommends
you increase the frequency of oil and filter
changes to an interval equivalent to 200
ENGINE HOURS of use. Since most vehicles are
not equipped with hourmeters, it may be
necessary for you to approximate your idle time
and plan oil/filter changes accordingly.
*
[SV16800( ALL)04/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
%*
[SV17250( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV17275( ALL)05/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17280( ALL)05/95]
Protect your skin by washing with soap and
water.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com

304
*
[SV26000( ALL)03/95]
Checking the pressure of the tires
*
[SV26100( ALL)11/89]
At least once a month, check the pressure in all
your vehicle's tires, including the spare. Use an
accurate tire pressure gauge. Check the tire
pressure when tires are cold, that is, after the
vehicle has been parked for at least one hour or
has been driven less than 3 miles (5 km). You
can find the proper cold pressure on the Safety
Compliance Certification Label.
*
[SV26150( ALL)05/95]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
*
[SV26200( ALL)02/95]
Tire inspection and maintenance
*
[SV26300( ALL)02/95]
Inspect the tire treads, and remove stones, nails,
glass or other objects that may be wedged in the
tread grooves. Check for holes or cuts that may
permit air to leak from the tire, and make the
necessary repairs.
*
[SV26400( ALL)10/89]
Inspect the tire side walls for cuts, bruises and
other damage. If you suspect internal damage to
the tire, have it demounted and checked. You
may need to repair or replace it.
*
[SV26410( ALL)11/89]
Wheel inspection and maintenance
*
[SV26420( ALL)11/89]
Check for damage that would affect the runout
of the wheels. Wobble or shimmy will eventually
damage the wheel bearings.
*
[SV26430( ALL)06/93]
Front wheel bearings require periodic repacking
and adjustment as specified in theMaintenance
Schedule and Recordbooklet. Loose or worn front
wheel bearings tend to let the vehicle wander or
shimmy, and can eventually cause excessive tire
wear.
File:ltsvb.ex
Update:Tue Jun 20 16:56:22 1995
ProCarManuals.com
