FORD CONTOUR 1997 2.G Owners Manual

184
%*
[MC04500(ALL)01/96]
Engine Oil Recommendations
*
[MC04600(ALL)01/96]
We recommend using Motorcraft oil or an equivalent oil
meeting Ford Specification WSS-M2C153-F and displaying the
American Petroleum Institute CERTIFICATION MARK on the
front of the container.
*
[MC04700(ALL)01/96]
10-1/2 pica
art:0001314-A
The API Certification Mark
*
[MC04800(ALL)01/96]
Neveruse:
*
[MC04900(ALL)01/96]
n
ªNon-Detergentº oils
*
[MC05000(ALL)02/96]
n
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC05100(ALL)01/96
]
n
Additional engine oil additives, oil treatments or engine
treatments
%*
[MC05200(ALL)03/96
]
Engine oils with anSAE 5W-30viscosity arePREFERREDfor
your vehicle. They provide the best engine performance, fuel
economy and engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC05300(ALL)03/96
]
Synthetic engine oils which are CERTIFIED and of the preferred
viscosity may be used in your engine. The engine oil and oil
filter must still be changed according to the maintenance
schedule.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
185
%*
[MC05400(ALL)01/96
]
Checking and Adding Engine Oil
*
[MC05500(ALL)01/96]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[MC05600(ALL)01/96
]
Checking the engine oil level:
*
[MC05700(ALL)01/96]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
*
[MC05800(ALL)01/96]2.
Set the parking brake fully and make sure that the gearshift
is securely latched in P (Park) (automatic transaxle) or 1
(First) (manual transaxle).
*
[MC05900(ALL)01/96]3.
Open the hood. Protect yourself from engine heat.
*
[MC06000(ALL)01/96]4.
Locate the engine oil dipstick (highlighted in yellow) and
carefully pull it out of the engine.
*
[MC06100(ALL)01/96]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
[MC06200(ALL)12/95]
6 pica art:0001305-A
Engine oil dipstick (2.0L engine)
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

186
[MC06300(ALL)12/95]
6 pica art:0001245-A
Engine oil dipstick (2.5L engine)
[MC06400(ALL)12/95]6.
2.0L engine:Carefully, pull the dipstick out again. If the oil
level is below the lower notch, add engine oil as necessary.
If the oil level is beyond the upper notch, engine damage
and/or high oil comsumption may occur and some oil must
be removed from the engine.
[MC06500(ALL)12/95]
2.5L engine:Carefully, pull the dipstick out again. If the oil
level is below the MIN line, add engine oil as necessary. If
the oil level is above the letter M in MAX, engine damage
and/or high oil consumption may occur and some oil must
be removed from the engine.
*
[MC06600(ALL)01/96]7.
Put the dipstick back in and make sure it is fully seated.
*
[MC06700(ALL)01/96]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[MC06800(ALL)01/96]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
[MC06900(O )04/96]
Nearly all engines will consume engine oil. As a result, it may
be necessary to add some oil between oil changes.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
187
%*
[MC07000(ALL)01/96
]
Changing the Engine Oil and the Oil Filter
[MC07100(ALL)04/96]
Change the engine oil and oil filter per the following, whichever
occurs first.
[MC07200(ALL)12/95]
twelve pica
chart:0001472-A*
[MC07300(ALL)02/96]
Refer to theMaintenance Schedulebooklet for additional
information.
%*
[MC07400(ALL)05/96
]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
*
[MC07500(ALL)01/96]
RWARNING
Continuous contact with USED motor oil has caused
cancer in laboratory mice.
*
[MC07600(ALL)01/96]
Protect your skin by washing with soap and water.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

188
%*
[MC07700(ALL)05/96]
Brake Fluid
*
[MC07800(ALL)01/96]
Under normal circumstances, your vehicle should not use up
brake fluid rapidly. However, expect the level of the brake fluid
to slowly fall as you put more mileage on your vehicle and the
brake lining wears.
[MC07900(ALL)12/95]
You should check the brake fluid at every scheduled engine oil
change, but be sure to check it at least once a year. You can do
this by looking at the fluid level in the plastic reservoir on the
master cylinder. (SeeThe Engine Typesin this chapter to locate
the brake fluid reservoir.) The fluid level should be at or near
the MAX mark.
*
[MC08000(ALL)01/96]
RWARNING
Brake fluid is toxic.
*
[MC08100(ALL)01/96]
If brake fluid contacts eyes, flush eyes with running water for
15 minutes. Get medical attention if irritation persists. If taken
internally, drink water and induce vomiting. Get medical
attention immediately.
*
[MC08200(ALL)12/95]
If the fluid is low, carefully clean and remove the cap from the
reservoir. Fill the reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AB or equivalent
DOT 3 fluid meeting Ford specification ESA-M6C25-A.
*
[MC08300(ALL)01/96]
RWARNING
If you use a brake fluid that is not DOT 3, you will
cause permanent damage to your brakes.
*
[MC08400(ALL)01/96]
Do not fill the reservoir above the MAX line.
*
[MC08500(ALL)01/96]
If you find that the fluid level is excessively low Ð below the
seam or ridge on the outside of the plastic reservoir Ð have the
brake system inspected.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
189
*
[MC08600(ALL)01/96]
RWARNING
Do not let the reservoir for the master cylinder run dry.
This may cause the brakes to fail.
[MC08700(ALL)12/95]
10-1/2 pica
art:0000671-B
The brake fluid reservoir
%*
[MC08800(ALL)02/96]
Windshield Washer Fluid
%*
[MC08900(ALL)03/96
]
Washer Fluid
*
[MC09000(ALL)01/96]
Check the level of the windshield washer fluid every time you
stop for fuel. The reservoir for washer fluid is located on the
passenger's side of the engine compartment. Visual inspection
can determine if the washer fluid is adequate. Do not operate
the washer when the reservoir is empty.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

190
[MC09100(ALL)12/95]
10-1/2 pica
art:0001222-A
The windshield washer fluid reservoir
*
[MC09200(ALL)01/96]
Adding washer fluid
*
[MC09300(ALL)01/96]
RWARNING
Do not put windshield washer fluid in the container for
the engine coolant.
*
[MC09400(ALL)05/96]
If sprayed to clean the glass, engine coolant or antifreeze could
make it difficult to see through the windshield.
%*
[MC09500(ALL)02/96
]
Use specially formulated windshield washer fluid rather than
plain water, because specially formulated washer fluids contain
additives that dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such as methanol
should be used in freezing weather (temperatures below32ÊF
[0ÊC]). State or local regulations on Volatile Organic Compounds
(VOCs) may restrict use of the most common antifreeze,
methanol. Washer fluids containing non-methanol antifreeze
agents should be used only if they provide cold weather
protection without damaging the vehicle's paint finish, wiper
blades, and windshield washer system.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
191
%*
[MC09600(ALL)01/96]
Engine Coolant
%*
[MC09700(ALL)01/96
]
Checking the Engine Coolant
*
[MC09800(ALL)05/96]
NOTE: Be sure to read and understandPrecautions When
Servicing Your Vehicleat the beginning of this chapter.
*
[MC09900(ALL)01/96]
RWARNING
The cooling fan is automatic and may come on at any
time. Always disconnect the negative terminal of the
battery before working near the fan.
[MC10000(ALL)12/95]
13-1/2 pica
art:0000336-D
The engine coolant recovery reservoir (2.5L shown Ð 2.0L similar)
%*
[MC10100(ALL)12/95
]
Your vehicle's coolant protects your engine from overheating in
the summer and from freezing in the winter. Check the level of
the coolant at least once a month. Simply look at the engine
coolant reservoir located in the engine compartment. To locate
the reservoir, see the diagram of your vehicle's engine under
Engine Type, in this chapter.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

192
*
[MC10200(ALL)12/95]
Check the engine coolant level in the engine coolant reservoir at
least once a month using the following guidelines.
[MC10300(ALL)12/95]
When your vehicle's engine is cool, the coolant level in the
engine coolant recovery reservoir should be at or above the
MIN mark. When the engine is hot, the coolant level should be
at the MAX mark. If the level is below the indicator mark in
either condition, coolant may need to be added.
*
[MC10400(ALL)02/96]
The coolant additives also protect the entire cooling system from
internal passageway corrosion and these additives lubricate the
water pump. The coolant should be serviced as noted in the
Maintenance Schedulebooklet.
*
[MC10500(ALL)01/96]
Adding Engine Coolant
*
[MC10601(ALL)05/96]
RWARNING
Do not put engine coolant in the container for the
windshield washer fluid.
*
[MC10611(ALL)05/96]
If sprayed on the windshield, engine coolant could make it
difficult to see through the windshield.
*
[MC10621(ALL)05/96]
When the engine is cool, add a 50/50 mixture of engine coolant
and water to the engine coolant recovery reservoir Ð DO NOT
ADD DIRECTLY TO THE RADIATOR. Add straight water only
in an emergency, but you should replace it with a 50/50
mixture of coolant and distilled water as soon as possible.
*
[MC10631(ALL)05/96]
Check the coolant level in the coolant recovery reservoir the
next few times you drive the vehicle. If necessary, add enough
of a 50/50 mixture of coolant and water to bring the liquid
level to the fill line on the reservoir.
*
[MC10641(ALL)05/96]
RWARNING
Never remove the coolant recovery cap while the engine
is running or hot.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
193
*
[MC10651(ALL)05/96]
If you must remove the coolant recovery cap, follow these steps
to avoid personal injury:
*
[MC10661(ALL)05/96]1.
Before you remove the cap, turn the engine off and let it
cool.
*
[MC10671(ALL)05/96]2.
When the engine is cool, wrap a thick cloth around the cap.
Slowly turn cap counterclockwise to the first stop.
*
[MC10681(ALL)05/96]3.
Step back while the pressure releases.
*
[MC10691(ALL)05/96]4.
When you are sure that all the pressure has been released,
use the cloth to press the cap down, turn it counterclockwise,
and remove it.
*
[MC10701(ALL)05/96]
Use Ford Premium Cooling System Fluid E2FZ-19549-AA (in
Canada, Motorcraft CXC-8-B) or an equivalent premium engine
coolant that meets Ford specification ESE-M97B44-A. Ford
Premium Engine Coolant is an optimized formula that will
protect all metals and rubber elastomers used in Ford cooling
systems for 4 years or 50,000 miles (80,000 km).
*
[MC10711(ALL)05/96]
Do not use alcohol or methanol antifreeze or any engine
coolants mixed with alcohol or methanol antifreeze. Do not use
supplemental coolant additives in your vehicle. These additives
may harm your engine cooling system. The use of an improper
coolant may void the warranty of your vehicle's engine cooling
system.
*
[MC10721(ALL)05/96]
Recycled engine coolant
*
[MC10731(ALL)05/96]
Ford Motor Company recommends that Ford and
Lincoln-Mercury dealers use recycled engine coolant produced
by Ford-approved processes. Not all coolant recycling processes
produce coolant which meets Ford specification ESE-M97B44-A,
and use of such coolant may harm engine and cooling system
components.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996
