FORD CONTOUR 1997 2.G Owners Manual

204
%*
[MC19000(ALL)01/96
]
Tire Rotation
*
[MC19100(ALL)01/96]
Because your vehicle's front and rear tires perform different
jobs, they often wear differently. To make sure your tires wear
evenly and last longer, rotate them as indicated in the following
diagram.
*
[MC19200(ALL)01/96]
Do not include the spare tire as part of your rotation.
[MC19300(ALL)03/96]
For tire rotation intervals, see theMaintenance Schedulebooklet.
If you notice that the tires wear unevenly, have them checked.
[MC19400(ALL)12/95]
13-1/2 pica
art:0001224-A
Rotating the tires
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
205
%*
[MC19500(ALL)01/96
]
Replacing the Tires
*
[MC19600(ALL)01/96]
Replace any tires that show wear bands. When your tire shows
a wear band, it has only 1/16 inch (2 mm) of tread left.
[MC19700(ALL)12/95]
7-1/2 pica art:0001317-A
A worn-out tire
*
[MC19800(ALL)02/96]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread.
*
[MC19900(ALL)01/96]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
*
[MC20000(ALL)01/96]
Tires that are larger or smaller than your vehicle's original tires
may also affect the accuracy of your speedometer.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

206
%*
[MC21000(ALL)01/96
]
Information About Tire Quality Grades
*
[MC21100(ALL)01/96]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) molded into the tire's sidewall. These
Tire Quality Grades are determined by standards that the
United States Department of Transportation has set.
*
[MC21200(ALL)01/96]
Tire Quality Grades apply to new pneumatic tires for use on
passenger cars. They do not apply to deep tread, winter-type
snow tires, space-saver or temporary use spare tires, tires with
nominal rim diameters of 10 to 12 inches or limited production
tires as defined in Title 49 Code of Federal Regulations Part
575.104(c)(2).
*
[MC21300(ALL)01/96]
U.S. Department of Transportation Ð Tire quality grades:The
U.S. Department of Transportation requires Ford to give you the
following information about tire grades exactly as the
government has written it.
%*
[MC21400(ALL)01/96
]
Treadwear
*
[MC21500(ALL)01/96]
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course. For example, a tire graded 150
would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100. The relative
performance of tires depends upon the actual conditions of their
use, however, and may depart significantly from the norm due
to variations in driving habits, service practices and differences
in road characteristics and climate.
*
[MC21600(ALL)01/96]
Traction A B C
*
[MC21700(ALL)05/96]
The traction grades, from highest to lowest, are A, B, and C,
and they represent the tire's ability to stop on wet pavement as
measured under controlled conditions on specified government
test surfaces of asphalt and concrete. A tire marked C may have
poor traction performance.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
207
*
[MC21750(ALL)05/96]
RWARNING
The traction grade assigned to this tire is based on
braking (straightahead) traction tests and does not
include cornering (turning) traction.
*
[MC21800(ALL)01/96]
Temperature A B C
*
[MC21900(ALL)05/96]
The temperature grades are A (the highest), B, and C,
representing the tire's resistance to the generation of heat and
its ability to dissipate heat when tested under controlled
conditions on a specified indoor laboratory test wheel. Sustained
high temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive temperature can
lead to sudden tire failure. The grade C corresponds to a level
of performance which all passenger car tires must meet under
the Federal Motor Vehicle Safety Standard No. 109. Grades B
and A represent higher levels of performance on the laboratory
test wheel than the minimum required by law.
*
[MC21925(ALL)05/96]
RWARNING
The temperature grade for this tire is established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading,
either separately or in combination, can cause heat
buildup and possible tire failure.
*
[MC21950(ALL)03/96]
RWARNING
Driving too fast for conditions creates the possibility of
loss of vehicle control. Driving at very high speeds for
extended periods of time may result in damage to vehicle
components.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

208
%*
[MC22000(ALL)01/96]
Snow Tires and Chains
*
[MC22100(ALL)01/96]
During the winter months in some climates, you may need to
use snow tires and occasionally chains for your tires.
*
[MC22200(ALL)01/96]
RWARNING
Snow tires must be the same size and grade as the tires
you currently have on your vehicle.
*
[MC22300(ALL)01/96]
Use chains on the tires only in an emergency or if the law
requires them where you live. If you choose to use chains on
your vehicle's tires, be aware of the following:
*
[MC22400(ALL)01/96]
n
Tire chains may scratch or chip aluminum wheels. IT IS
RECOMMENDED THAT TIRE CHAINS ARE INSTALLED
ON STEEL WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before using tire chains
to avoid scratches or damage.
[MC22500(ALL)12/95]
n
Tire chains cannot be fitted with 205/60R tires.
*
[MC22600(ALL)01/96]
n
Local regulations may prohibit or restrict the use of tire
chains. Investigate the laws and regulations in your area
before installing chains.
*
[MC22700(ALL)01/96]
n
Put the chains on the front tires tightly with the ends held
down securely. Retighten the chains after driving 1/2 mile
(1 km). Follow the chain manufacturer's instructions.
*
[MC22800(ALL)01/96]
n
Do not drive faster than 30 mph (50 km/h) or the chain
manufacturer's recommended speed limit, whichever is
lower. Avoid bumps, holes and sharp turns. If you can hear
the chains rub or bang against your vehicle, remove the
chains to prevent damage to your vehicle.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
209
*
[MC22900(ALL)01/96]
n
Tire chains may affect vehicle handling. Drive carefully and
avoid hard braking.
*
[MC23000(ALL)01/96]
n
Do not use chains on temporary spare tires. They may
damage the vehicle and the tire.
*
[MC23100(ALL)01/96]
n
Remove tire chains at the first opportunity after using them
on snow and ice. Do not use the chains on dry roads.
%*
[MC23200(ALL)01/96]
Filling the Fuel Tank
*
[MC23900(ALL)12/95]
The fuel door is outside the car on the passenger side near the
back. To fill the fuel tank:
*
[MC24000(ALL)03/96]1.
After opening the fuel filler door, remove the cap carefully
and slowly by turning it counterclockwise 1/2 to 3/4 turn. If
a hissing sound is heard, wait until it stops, then continue
turning until the cap is free.
*
[MC24100(ALL)01/96]
RWARNING
The fuel system may be under pressure. If the fuel cap is
venting vapor or if you hear a hissing sound, wait until
it stops before completely removing the cap.
*
[MC24200(ALL)01/96]2.
Put the nozzle all the way inside the fuel filler pipe before
pumping the fuel.
*
[MC24300(ALL)01/96]
NOTE: If you spill any fuel on the body of your vehicle,
clean it off immediately. The fuel may dull or soften
the paint if you do not wash it off.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

210
[MC24400(ALL)12/95]3.
Replace the fuel cap completely when you are finished. Turn
it clockwise until it is tight. It will click when it is fully
tightened.
*
[MC24500(ALL)01/96]4.
Push the fuel door closed.
*
[MC24600(ALL)01/96]
If you lose the fuel cap, replace it with an authorized Motorcraft
or equivalent part.
%*
[MC24700(ALL)01/96
]
RWARNING
If you do not use the proper fuel cap, the pressure in the
fuel tank can damage the fuel system or cause it to work
improperly in a collision.
*
[MC24800(ALL)01/96]
NOTE: If you replace your fuel cap with an aftermarket fuel
filler cap, the customer warranty may be void for any
damage to the fuel tank and/or fuel system.
%*
[MC24900(ALL)01/96
]
Choosing the Right Fuel
*
[MC25000(ALL)03/96]
Use only UNLEADED FUEL. Using leaded fuel is prohibited by
federal law and could damage your vehicle. The damage may
not be covered by your warranty.
*
[MC25100(ALL)05/96]
Your vehicle was not designed to use fuel containing
manganese-based additives such as MMT. Additionally, vehicles
certified to California emission standards (indicated on the
underhood Vehicle Emissions Control Information label) are
designed to operate on California reformulated gasolines. If
California reformulated gasoline is not available when you
refuel, your vehicle can be operated on non-California fuels.
However, even though your engine will perform adequately on
other gasolines, the performance of the emission control devices
and systems may be adversely affected. Repair of damage
caused by using a fuel that your vehicle was not designed for
may not be covered by your warranty.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
211
%*
[MC25200(ALL)04/96]
Octane recommendation
*
[MC25300(ALL)05/96]
Your vehicle is designed to use regular gasoline with an
(R+M)/2 octane rating of 87.We do not recommend gasolines
labeled as ªregularº in high altitude areas that are sold with
octane ratings of 86 or even less.
*
[MC25400(ALL)02/96]
6 pica art:0040193-A
Typical octane rating label
*
[MC25600(ALL)05/96]
Do not be concerned if your vehicle sometimes knocks lightly.
However, if it knocks heavily under most driving conditions on
the recommended octane fuel, see your dealer or a qualified
service technician to prevent any engine damage.
%*
[MC25650(ALL)05/96
]
Fuel quality
*
[MC25675(ALL)05/96]
If you are experiencing starting, rough idle or hesitation
problems try a different brand of fuel. If the condition persists,
see your dealer or a qualified service technician.
*
[MC25700(ALL)05/96]
The American Automobile Manufacturers Association (AAMA)
issued a gasoline specification to provide information on high
quality fuels that optimize the performance of your vehicle. We
recommend the use of gasolines that meet the AAMA
specification if they are available.
*
[MC25725(ALL)05/96]
It should not be necessary to add any aftermarket products to
your fuel tank if you continue to use a high-quality fuel.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

212
*
[MC25800(ALL)05/96]
Cleaner Air
*
[MC25900(ALL)05/96]
Ford approves the use of gasolines to improve air quality,
including reformulated gasolines that contain oxygenates such as
a maximum of 10% ethanol or 15% MTBE. There should be no
more than 5% methanol with cosolvents and additives to protect
the fuel system.
*
[MC26000(ALL)04/96]
Reformulated fuel is also required in certain areas of the U.S.
These fuels are designed to further reduce the emissions from
your vehicle.
*
[MC26100(ALL)05/96]
Generally, you should not experience difficulties operating your
vehicle on fuels containing oxygenates. We encourage you to
use these fuels.
%*
[MC26200(ALL)01/96
]
Safety Information Relating to Automotive Fuels
*
[MC26300(ALL)01/96]
RWARNING
Automotive fuels can cause serious injury or death if
misused or mishandled.
*
[MC26400(ALL)05/96]
n
Turn vehicle off when refueling.
*
[MC26500(ALL)08/95]
n
Do not smoke when refueling. Fuels are extremely
flammable.
*
[MC26600(ALL)08/95]
n
Do not siphon any fuel by mouth.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
213
*
[MC26700(ALL)02/96]
RWARNING
Gasoline or gasoline blended with methanol can cause
blindness and possible death when swallowed. If any
fuel is swallowed, call a physician or poison control
center immediately.
*
[MC26800(ALL)08/95]
n
Avoid breathing vapors while refueling.
*
[MC26900(ALL)08/95]
n
If fuel is splashed on the skin, wash with soap and water.
*
[MC27000(ALL)08/95]
n
If fuel is splashed in the eyes, remove contact lenses (if
worn), flush with water for 15 minutes, and seek medical
attention.
*
[MC27100(ALL)01/96]
Gasoline and gasoline blends may contain small amounts of
carcinogens, such as benzene. Long-term exposure to unleaded
gasoline vapors has caused cancer in laboratory animals.
*
[MC27200(ALL)01/96]
If you are taking the medication ªAntabuseº or other forms of
disulfiram for the treatment of alcoholism, vapor or skin contact
with a gasoline-methanol blend may cause the same kind of
adverse reaction as drinking an alcoholic beverage. In sensitive
individuals, serious personal injury or sickness could result.
Consult a physician promptly if you experience an adverse
reaction.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996
