Maintenance and care
170The bulbs for the low beam, high
beam, turn signals and side lamps
are housed in the lamp assembly.
To replace a bulb, the complete
lamp assembly has to be removed
as follows:
1. Switch off the lamps.
2. Open the hood.
3. Remove the lower screw (2)
from the headlamp housing.
4. Remove the two upper screws
(1) from the headlamp housing.
5. Gently pull the headlamp
housing outward.
6. Replace the headlamp bulbs. BULB REPLACEMENT
Handle a halogen headlamp
bulb carefully and keep out
of children’s reach.Grasp the bulb
only by its plastic base and do not
touch the glass. The oil from your
hand could cause the bulb to
break the next time the
headlamps are operated.
1
1
2
Removing the headlamps
assembly
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 170

Maintenance and care
171 Reinstalling the headlamp
assembly
The gasket lining must be seated
properly around the lamp assembly
when reinstalling.
All bulb connectors must be
correctly connected.
Install in the reverse order.
Headlamps – low beam
Disconnect the electrical connector
and replace the bulb.
Do not touch the glass part of the
bulb and pay attention to the tab
guides when replacing.
Headlamp alignment
Check the headlamp alignment
after each replacement of a bulb.
Refer to Aiming the headlamps. Headlamps – high beam
Replacement instructions are the
same as for the low beam
headlamp.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 171

Maintenance and care
175 Reading lamps (if equipped)
Open the lamp assembly.
The bulbs can be replaced after the
contact plate has been hinged
back.
Interior lamps
Switch off the interior lamps
(middle switch position). Pry out
the lamp assembly with a flat
screwdriver, release the reflector at
the side and replace the festoon
bulb.
To install, fit the new bulb in
reverse sequence.
FunctionTrade number
3457 NA
9005
9006
893
1157
1156 Front /turn lamp
Headlamp (high)
Headlamp (low)
Foglamp
Rear tail/turn/brake lamp
Backup lamp
Bulb specifications
2723
C5W High-mounted brake lamp
License plate lamp
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 175

Maintenance and care
176Aiming the headlamps
Your vehicle is equipped with a
Vehicle Headlamp Aim Device
(VHAD) on each headlamp body.
Each headlamp may be properly
aimed in the horizontal direction
(left/right) and the vertical position
(up/down).
A non-zero bubble reading does not
necessarily indicate out-of-aim
headlamps. If your vehicle is not
positioned on a level surface, the
slope will be included in the level
indicator. Therefore, vertical
headlamp adjustment should be
performed only when beam
direction appears to be incorrect
and a level surface can be verified. AIMING THE HEADLAMPS
The alignment of your headlamps
should be checked if:
•Oncoming motorists frequently
signal you to deactivate your high
beams, and your high beams are
not activated.
•The headlamps do not seem to
provide enough light for clear
night vision.
•The headlamp beams are pointed
substantially away from a slightly
down and to the right position.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 176

Maintenance and care
177
Adjusting the horizontal aim
1. Make sure the vehicle is on a
level surface.
2.With the hood open, locate the
horizontal indicator and adjusting
screw.
3. Turn the horizontal adjusting
screw until the reference mark on
the reflector extension aligns with
the “0” reference mark on the
horizontal indicator when viewed
directly from above.
4. When the horizontal aim has
been adjusted, close the headlamp
access panel. The horizontal aim must be
adjusted first. You will need one 7
mm box wrench, open end wrench
or T-15 Torx drive.
The following procedures assumes
that the vehicle’s front structure is
properly aligned. If the vehicle has
been in an accident requiring the
front end of the vehicle to be
repaired, the horizontal indicator
should be recalibrated by your
dealer or a qualified service
technician.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 177

Maintenance and care
178
Adjusting the vertical aim
The numbers shown on the vial
indicate beam direction in degrees
up or down.
1. Do not adjust the vertical aim
until after adjusting the horizontal
aim.
2. With the hood open, locate the
bubble level vertical aim indicator.
It is visible when viewed from the
above rear of the headlamp.
3. Turn the vertical adjusting screw
until the reference mark on the
reflector extension aligns with the
“0” reference mark on the vertical
indicator when viewed from
directly above.
4. Close the hood.
