FORD CONTOUR 2000 2.G Owner's Manual

Instrumentation
21
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF12
03
x 1000
4
5
6
7
8
O/D
OFFCHECK
ENGINE
BRAKE
TRACTION
CONTROL
CH
Tachometer (if equipped)
Indicates the engine speed in
revolutions per minute (rpm).
12
03
x 1000
4
5
6
7
8
EF
Fuel gauge
The fuel gauge displays
approximately how much fuel is in
the tank (when the key is in the
ON position). The fuel gauge may
vary slightly when the vehicle is in
motion. The ignition should be in
the OFF position while the vehicle
is being refueled. When the gauge
first indicates empty, there is a
small amount of reserve fuel in the
tank. When refueling the vehicle
from empty indication, the amount
of fuel that can be added will be
less than the advertised capacity
due to the reserve fuel.
12CInen 17.6.99 10:41 Uhr Seite 21

Controls and features
22
MIRRORS
OFF LO PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWER AUDIO AM/FM
SCAN
SEEK 31245ANSSIDE 1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
10 0
110
120
13 0MPH20 406055
80120 10 0
14 0
160
18 0
200EF12
03
x 1000
4
5
6
7
8
BRAKE
CHECK
ENGINEO/D
OFFTRACTION
CONTROL
CLOCK
CH
INSTRUMENT PANEL
CONTROLS
Headlamp control
Lamps off.
Turn one position clockwise:
Parking lamps, instrument panel
lamps, license plate lamps, and tail
lamps on.
Turn two positions clockwise:
Headlamps on.
13CCfen 17.6.99 10:52 Uhr Seite 22

Controls and features
23 Daytime running lights (DRL)
(Canadian vehicles only)
The DRL system turns on the
highbeam headlamps, with a
reduced light output, when:
• the vehicle is running and the
ignition is in the on position and
• the headlamp system is in the off
position.
The daytime running light
(DRL) system will not
illuminate the tail lamps and
parking lamps. Turn on your
headlamps at dusk. Failure to do
so may result in a collision.
Foglamp control
(if equipped)
Pull out the control while the
headlamps are on to turn the
foglamps on.
Push in the control to deactivate
the foglamps.
13CCfen 17.6.99 10:52 Uhr Seite 23

Controls and features
24Rear window defroster
(if equipped)
Press the defroster control to clear
the rear window of thin ice and fog.
The ignition must be in the on
position to operate the rear
window defroster.
The defroster turns off
automatically after 10 minutes or
when the ignition is turned to the
off position. To manually turn off
the defroster, push the control
again.
Traction control system
(if equipped)
This button turns the traction
control system off and on. See
Driving for more information.
OFFPNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWER AUDIO AM/FM
SCAN
SEEK 31245ANSSIDE 1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
10 0
110
120
13 0MPH20 406055
80120 10 0
14 0
160
18 0
200EF12
03
x 1000
4
5
6
7
8
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
CLOCK
MIRRORS
TRACTION
TROL
CH
13CCfen 17.6.99 10:52 Uhr Seite 24

Controls and features
25 Panel dimmer control
Adjust the control to vary the
intensity of the panel lighting.
Operates only when the exterior
lights are switched on.
To switch on the interior lamp,
rotate the control completely to the
left.
Power mirrors (if equipped)
The control can be swivelled and
turned.
Turn the control counterclockwise
to adjust the driver’s side mirror,
clockwise to adjust the passenger
side mirror. Adjust the selected
mirror by moving the center
control in the desired direction.
Then turn the control back to the
center position.
MIRRORS
MIRRORS
13CCfen 17.6.99 10:52 Uhr Seite 25

Controls and features
26Climate control system
Vents
Airflow from the vents may be
adjusted by moving the horizontal
control or vertically adjusting the
vent (except passenger side outer
vent) according to your airflow
preference.
Your vehicle has one of the
following climate control systems:
• Manual heating system
• Manual heating and air
conditioning system
In some modes, the two systems
function similarly. In modes where
the systems do not function
similarly, the different functions
are noted.
OFF LO PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWER AUDIO AM/FM
SCAN
SEEK 31245ANSSIDE 1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
10 0
110
120
13 0MPH20 406055
80120 10 0
14 0
160
18 0
200EF12
03x 1000
4
5
6
7
8
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
MIRRORS
CLOCK
TRACTION
ROL
CH
13CCfen 17.6.99 10:52 Uhr Seite 26

Controls and features
27 Heater only system
(if equipped)
OFF LO PNL/FLR
PANEL FLOOR
DEF FLR
DEF
HI/
LO
HI
Temperature control knob
Controls the temperature of the
airflow inside the vehicle. On
heater-only systems, the air cannot
be cooled below the outside
temperature.
Mode selector control
Controls the direction of the
airflow to the inside of the vehicle.
• PANEL – Distributes outside air
through the instrument panel
registers.
• OFF – Outside air is shut out and
the fan will not operate.
• PNL/FLR – Distributes outside
air through the instrument panel
registers and the floor ducts.
• FLOOR – Allows for maximum
heating. Distributes outside air
through floor ducts.
Fan speed control
Controls the volume of air
circulated in the vehicle.
13CCfen 17.6.99 10:52 Uhr Seite 27

Controls and features
28• FLR/DEF – Distributes outside
air through the floor ducts and the
windshield defroster ducts.
• DEF – Distributes outside air
through the windshield defroster
ducts. It can be used to clear ice or
fog from the windshield.
Operating tips
• In humid weather, select DEF
before driving. This will help to
reduce fogging on your windshield.
After a few minutes, select any
desired position.
• To reduce humidity buildup
inside the vehicle, don’t drive with
the climate control system in the
OFF position.
• Don’t put objects under the front
seat that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves
from the air intake area (at the
bottom of the windshield under the
hood).
• Do not place objects over the
defroster outlets. These objects
can block airflow and reduce your
ability to see through your
windshield. Also, avoid placing
small objects on top of your
instrument panel. These objects
can fall down into the defroster
outlets and block airflow and
possibly damage your climate
control system.
13CCfen 17.6.99 10:52 Uhr Seite 28

Controls and features
29 Manual heating and air
conditioning system
(if equipped)
OFF LO PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
LO
HIFan speed control
Controls the volume of air
circulated in the vehicle.
Temperature control knob
Controls the temperature of the
airflow inside the vehicle.
OFF PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C/Mode selector control
Controls the direction of the
airflow to the inside of the vehicle.
The air conditioning compressor
will operate in all modes except
PANEL, PNL/FLR, and FLOOR.
However, the air conditioning will
only function if the outside
temperature is about 10°C (50°F )
or higher.
Since the air conditioner removes
considerable moisture from the air
during operation, it is normal if
clear water drips on the ground
under the air conditioner drain
while the system is working and
even after you have stopped the
vehicle.
13CCfen 17.6.99 10:52 Uhr Seite 29

Controls and features
30Under normal conditions, your
vehicle’s climate control system
should be left in any position other
than MAX A/C or OFF when the
vehicle is parked. This allows the
vehicle to “breathe” through the
outside air inlet duct.
In snowy or dirty conditions, leave
the mode selector in the OFF
position when the ignition is off.
• MAX A/C – Uses recirculated air
to cool the vehicle. MAX A/C is
noisier than A/C but more
economical and will cool the inside
of the vehicle faster. Airflow will be
from the instrument panel
registers. This mode can also be
used to prevent undesirable odors
from entering the vehicle.
• A/C – Uses outside air to cool the
vehicle. It is quieter than MAX A/C
but not as economical. Airflow will
be from the instrument panel
registers.
• PANEL – Distributes outside air
through the instrument panel
registers. However, the air will not
be cooled below the outside
temperature because the air
conditioning does not operate in
this mode.
• OFF – Outside air is shut out and
the fan will not operate. For short
periods of time only, use this mode
to prevent undesirable odors from
entering the vehicle.
13CCfen 17.6.99 10:52 Uhr Seite 30
