climate control FORD CONTOUR 2000 2.G Owners Manual

7
Instrumentation
Page 25
Instrument panel dimmer
switch
On various models, the
appearance and location of
some items may differ from
those shown here. However,
the page references given
still apply.
OFF LO PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWER AUDIO AM/FM
SCAN
SEEK 31245ANSSIDE 1-2EJECTVOLUMECLOCK
Page 26
Climate control system
Page 34
Electronic sound system Page 72
Anti-theft system status
indicator*
*if equipped
12CInen 17.6.99 10:41 Uhr Seite 7

Controls and features
26Climate control system
Vents
Airflow from the vents may be
adjusted by moving the horizontal
control or vertically adjusting the
vent (except passenger side outer
vent) according to your airflow
preference.
Your vehicle has one of the
following climate control systems:
• Manual heating system
• Manual heating and air
conditioning system
In some modes, the two systems
function similarly. In modes where
the systems do not function
similarly, the different functions
are noted.
OFF LO PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWER AUDIO AM/FM
SCAN
SEEK 31245ANSSIDE 1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
10 0
110
120
13 0MPH20 406055
80120 10 0
14 0
160
18 0
200EF12
03x 1000
4
5
6
7
8
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
MIRRORS
CLOCK
TRACTION
ROL
CH
13CCfen 17.6.99 10:52 Uhr Seite 26

Controls and features
28• FLR/DEF – Distributes outside
air through the floor ducts and the
windshield defroster ducts.
• DEF – Distributes outside air
through the windshield defroster
ducts. It can be used to clear ice or
fog from the windshield.
Operating tips
• In humid weather, select DEF
before driving. This will help to
reduce fogging on your windshield.
After a few minutes, select any
desired position.
• To reduce humidity buildup
inside the vehicle, don’t drive with
the climate control system in the
OFF position.
• Don’t put objects under the front
seat that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves
from the air intake area (at the
bottom of the windshield under the
hood).
• Do not place objects over the
defroster outlets. These objects
can block airflow and reduce your
ability to see through your
windshield. Also, avoid placing
small objects on top of your
instrument panel. These objects
can fall down into the defroster
outlets and block airflow and
possibly damage your climate
control system.
13CCfen 17.6.99 10:52 Uhr Seite 28

Controls and features
30Under normal conditions, your
vehicle’s climate control system
should be left in any position other
than MAX A/C or OFF when the
vehicle is parked. This allows the
vehicle to “breathe” through the
outside air inlet duct.
In snowy or dirty conditions, leave
the mode selector in the OFF
position when the ignition is off.
• MAX A/C – Uses recirculated air
to cool the vehicle. MAX A/C is
noisier than A/C but more
economical and will cool the inside
of the vehicle faster. Airflow will be
from the instrument panel
registers. This mode can also be
used to prevent undesirable odors
from entering the vehicle.
• A/C – Uses outside air to cool the
vehicle. It is quieter than MAX A/C
but not as economical. Airflow will
be from the instrument panel
registers.
• PANEL – Distributes outside air
through the instrument panel
registers. However, the air will not
be cooled below the outside
temperature because the air
conditioning does not operate in
this mode.
• OFF – Outside air is shut out and
the fan will not operate. For short
periods of time only, use this mode
to prevent undesirable odors from
entering the vehicle.
13CCfen 17.6.99 10:52 Uhr Seite 30

Controls and features
32• DEF – Distributes outside air
through the windshield defroster
ducts. It can be used to clear ice or
fog from the windshield. If the
temperature is about 10°C (50°F)
or higher, the air conditioner will
automatically dehumidify the air to
reduce fogging.
Operating tips
• In humid weather, select DEF
before driving. This will reduce
fogging on your windshield. After a
few minutes, select any desired
position.
• To reduce humidity buildup
inside the vehicle, don’t drive with
the climate control system in the
OFF position.
• Don’t put objects under the front
seat that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves
from the air intake area (at the
bottom of the windshield under the
hood).
• If your vehicle has been parked
with the windows closed during hot
weather, the air conditioner will do
a much faster job of cooling if you
drive for two or three minutes with
the windows open. This will force
most of the hot, stale air out of the
vehicle. Then operate your air
conditioner as you would normally.
13CCfen 17.6.99 10:52 Uhr Seite 32

Controls and features
33 Cabin air filter
Your vehicle is equipped with an air
filter that removes pollen and road
dust from outside air before it is
directed to the interior of the
vehicle. Refer to the Maintenance
and carechapter for maintenance
of this filter. • Do not place objects over the
defroster outlets. These objects
can block airflow and reduce your
ability to see through your
windshield. Also, avoid placing
small objects on top of your
instrument panel. These objects
can fall down into the defroster
outlets and block airflow and
possibly damage your climate
control system.
13CCfen 17.6.99 10:52 Uhr Seite 33

Maintenance and care
186Checking wiper blades
Check the wiper blades on your
vehicle for roughness by running
the tips of your fingers over the
edge of the blade.
Traces of grease, silicone and fuel
prevent wiper blades from
functioning properly. We
recommend Ford cleaning
solutions or equivalent to clean
wiper blades.
Change the wiper blades on your
vehicle at least once a year.
Cabin air filter replacement
In your climate control system, you
have a filter that cleans the air
before it enters the interior of the
vehicle. This filter should be
replaced at the intervals in the
“Scheduled Maintenance Guide“.
To replace the cabin air filter:
1. Unscrew the nut in the base of
each windshield wiper arm.
Remove the windshield wiper arms.
31CMCen 17.6.99 11:15 Uhr Seite 186

Maintenance and care
189 Treadwear
The treadwear grade is a
comparative rating based on the
wear rate of the tire when tested
under controlled conditions on a
specified government test course.
For example, a tire graded 150
would wear one and one-half
(1 1/2) times as well on the
government course as a tire graded
100. The relative performance of
tires depends upon the actual
conditions of their use, however,
and may depart significantly from
the norm due to variations in
driving habits, service practices,
and differences in road
characteristics and climate.
Traction AA A B C
The traction grades, from highest
to lowest are AA, A, B, and C.
Those grades represent the tire’s
ability to stop on wet pavement as
measured under controlled
conditions on specified government
test surfaces of asphalt and
concrete. A tire marked C may
have poor traction performance.
The traction grade assigned
to this tire is based on
straight-ahead braking traction
tests, and does not include
acceleration, cornering,
hydroplaning, or peak traction
characteristics.
31CMCen 17.6.99 11:15 Uhr Seite 189

Index
242APage
Accessory position on
the ignition . . . . . . . . . . . . . . . . . .54
Additives, engine oil . . . . . . . . .169
Air bag supplemental
restraint system
and child safety seats . . . . . . . .87
description . . . . . . . . . . . . . . . . .87
disposal . . . . . . . . . . . . . . . . . . .92
indicator light . . . . . . . . . . .15, 91
operation . . . . . . . . . . . . . . . . . .89
wearing safety belts . . . . . . . . .87
Air conditioning
(see Climate control system)
Alarm, activating panic . . . . . . . .69
Antenna, radio
(see Audio system) . . . . . . . . . . .53
Anti-lock brake system (ABS) .116
Anti-theft system (see Passive
Anti-Theft System)
Antifreeze (see Engine coolant)
Audio system . . . . . . . . . . . . . . . .34
Automatic transaxle
driving with . . . . . . . . . . . . . . .121
fluid, adding . . . . . . . . . . . . . . .179
fluid, checking . . . . . . . . . . . . .179
fluid, refill capacities . . . . . . . .224
fluid, specification . . . . . . . . . .225
B
Backing up . . . . . . . . . . . . .123, 129
Battery
charging system warning light . .9
jumping a disabled battery . . .154
proper disposal, recycling . . . .184
replacement, specifications . .223
servicing . . . . . . . . . . . . . . . . . .182
Brake fluid
checking and adding . . . . . . . .172
specifications . . . . . . . . . . . . . .225
Brake-shift interlock . . . . . . . . .121
Brakelamps
(see Bulb replacement)BPage
Brakes
anti-lock brake system (ABS) 116
brake warning light . . . . . . . . . .14
fluid, checking and adding . . .172
fluid, refill capacities . . . . . . . .224
fluid, specification . . . . . . . . . .225
parking . . . . . . . . . . . . . . . . . . .116
Built-in child seat
folding up the seat . . . . . . . . .102
inspection after a collision . . .102
interlock safety feature . . . . . . .98
operation . . . . . . . . . . . . . . . . . .97
retractors . . . . . . . . . . . . . . . . . .98
Break-in period . . . . . . . . . . . . . . .2
Bulbs, replacing
foglamps . . . . . . . . . . . . . . . . .208
headlamps . . . . . . . . . . . . . . . .206
high-mounted brake lamp . . . .210
license plate lamp . . . . . . . . . .209
rear lamps . . . . . . . . . . . . . . . .209
specifications . . . . . . . . . . . . . .212
C
Cabin air filter . . . . . . . . . . .33, 186
Capacities for refilling fluids . . .224
Carbon monoxyde in exhaust . .110
Catalytic converter . . . . . . . . . .202
Chains, tires . . . . . . . . . . . . . . . .194
Changing a tire . . . . . . . . . . . . .150
Charging system warning light . . .9
Child safety restraints
built-in child seat . . . . . . . . . . .97
child safety seats . . . . . . . . . . .103
children and safety belts . . .93, 95
Child safety seats
and air bags . . . . . . . . . . . . . . . .88
attaching with tether straps . .104
automatic locking mode . . . . . .79
Childproof safety locks . . . . . . . .65
Chimes . . . . . . . . . . . . . . . . . . . . .19
Circuit breakers . . . . . . . . . . . . .143
4CInden 17.6.99 11:32 Uhr Seite 242

243
Index
CPage
Cleaning your vehicle
engine compartment . . . . . . . .219
exterior lamps . . . . . . . . . . . . .220
fabric . . . . . . . . . . . . . . . . . . . .221
instrument panel . . . . . . . . . . .221
plastic exterior parts . . . . . . . .220
safety belts . . . . . . . . . . . . . . .222
wheels . . . . . . . . . . . . . . . . . . .218
wiper blades . . . . . . . . . . . . . .220
Climate control system
air conditioning . . . . . . . . . . . . .29
controlling airflow . . . . . . . . . . .26
defrosting . . . . . . . . . . . . . . . . . .38
temperature . . . . . . . . . . . . . . . .27
vents . . . . . . . . . . . . . . . . . . . . . .26
Clock . . . . . . . . . . . . . . . . . . . . . .45
Clutch
operation . . . . . . . . . . . . . . . . .127
recommended shift speeds . . .128
Cold engine starting . . . . . . . . .114
Controls
instrument panel . . . . . . . . . . . .20
power seats . . . . . . . . . . . . . . . .75
steering column . . . . . . . . . . . . .55
Customer assistance . . . . . . . . .229
D
Daytime running lights . . . . . . . .23
Defects, reporting . . . . . . . . . . .241
Defrost
rear window . . . . . . . . . . . . . . . .24
windshield . . . . . . . . . . . . . . . . .32
Dipstick, engine oil . . . . . . . . . .167
Door mounted controls . . . . . . . .64
Driving under special conditions
heavy load . . . . . . . . . . . . . . . .133
towing a trailer . . . . . . . . . . . .134
E
Electrical system
fuses . . . . . . . . . . . . . . . . . . . . .143EPage
Emergencies, roadside
fuel pump shut-off switch . . . .141
jump starting . . . . . . . . . . . . . .154
towing . . . . . . . . . . . . . . . . . . .160
Emergency brake (see Parking
brake)
Emission control system . . . . . .202
Engine
check engine warning light . . . .12
fuel pump shut-off switch . . . .141
lubricant specifications . . . . . .225
preparing to start . . . . . . . . . .111
refill capacities . . . . . . . . . . . .224
starting . . . . . . . . . . . . . . . . . . .114
Engine block heater . . . . . . . . .115
Engine coolant
checking and adding . . . . . . . .174
disposal . . . . . . . . . . . . . . . . . .178
low coolant warning light . . . . .11
refilll capacities . . . . . . . . . . . .224
specifications . . . . . . . . . . . . . .225
Engine fan . . . . . . . . . . . . . . . . .163
Engine oil
changing oil and filter . . . . . . .170
checking and adding . . . . . . . .169
dipstick . . . . . . . . . .167, 168, 169
disposal . . . . . . . . . . . . . . . . . .171
engine oil pressure
warning light . . . . . . . . . . . . . . .18
filter specifications . . . . . . . . .223
refill capacities . . . . . . . . . . . .224
specifications . . . . . . . . . . . . . .225
Exhaust fumes . . . . . . . . . .110, 202
F
Fan (see Engine fan)
Flasher, hazard . . . . . . . . . .56, 141
Flashing the lights . . . . . . . . . . . .57
Floor mats . . . . . . . . . . . . . . . . . .67
Fluid refill capacities . . . . . . . . .224
Foglamps . . . . . . . . . . . . . . .23, 208
4CInden 17.6.99 11:32 Uhr Seite 243
