Page 14 of 310
11 % [IS03300( ALL)04/96]
Anti-Lock Brake System Light
(If equipped)
[IS03400( ALL)12/95]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than five seconds, you should shut off your
engine and restart. If the anti-lock brake light
stays on, this indicates that the anti-lock feature
is disabled and should receive immediate
attention by a qualified service technician.
Normal braking is not affected unless the brake
warning light is also lit.
*
[IS03500( ALL)03/96]
The Anti-Lock Brake System has self-check
capabilities. As previously described, the system
turns on the anti-lock light each time you start
your engine. After the engine is started and the
anti-lock light is out, the system performs
another test the first time the vehicle reaches
14 mph (22 km/h). The system turns on the
Anti-Lock Brake System (ABS) pump motor for
approximately 1/2 second. At this time a
mechanical noise may be heard. This is a normal
part of the self-check feature. If a malfunction is
found during this check the anti-lock light will
come on.
[IS03600( ALL)04/96]
one inch art:0011194-B
The anti-lock brake system light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996
Page 15 of 310
12
*
[IS03700( ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[IS03800( ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
%*
[IS04600( ALL)03/96]
Safety Belt Warning Light and Chime
*
[IS04700( ALL)03/96]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
*
[IS04900( GV)03/96]
q
If the driver's safety belt is not buckled when
the ignition is turned to the ON position, the
light will turn on for 1 to 2 minutes and the
chime will sound for 4 to 8 seconds.
*
[IS05200( GV)03/96]
q
If the driver's safety belt is buckled while the
light is on or the chime is sounding, both the
light and the chime will turn off.
*
[IS05400( GV)03/96]
q
If the driver's safety belt is buckled before the
ignition is turned to the ON position, neither
the light nor the chime will turn on.
[IS05600( ALL)04/96]
one inch art:0010118-A
The safety belt warning light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996
Page 44 of 310
41 % [IS34500( GV)04/96]
Anti-Lock Brake System Light
(If equipped)
*
[IS34600( GV)03/96]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than 5 seconds, you should shut off your engine
and restart. If the anti-lock brake light stays on,
this indicates that the anti-lock feature is
disabled and should receive immediate attention
by a qualified service technician. Normal braking
is not affected unless the brake warning light is
also lit.
*
[IS34700( GV)03/96]
The Anti-Lock Brake System has self-check
capabilities. As previously described, the system
turns on the anti-lock light each time you start
your engine. After the engine is started and the
anti-lock light is out, the system performs
another test the first time the vehicle reaches
14 mph (22 km/h). The system turns on the
Anti-Lock Brake System (ABS) pump motor for
approximately 1/2 second. At this time a
mechanical noise may be heard. This is a normal
part of the self-check feature. If a malfunction is
found during this check the anti-lock light will
come on.
[IS34800( GV)05/96]
one inch art:0010642-E
The anti-lock brake system light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996
Page 45 of 310
42
*
[IS34900( GV)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[IS35000( GV)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
%*
[IS35100( GV)03/96]
Brake System Light
*
[IS35200( GV)03/96]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by a
qualified service technician.
[IS35300( GV)05/96]
one inch art:0011354-B
The brake system light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996
Page 52 of 310
50 [AS10376( GV)10/95]NOTE: If there are fewer than six strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band. After all stations have been
filled, the radio will begin playing the
station stored on memory button 1.
*
[AS10377( GV)03/96]
To deactivate the Auto Memory Store mode and
return to the manually-set memory button
stations, simply push the ªAUTOSETº button.
Display will show ªAUTOº then ªOFFº. The
next time Auto Memory Store is activated on
that band, the radio will store the next set of six
strong stations.
*
[AS10378( GV)03/96]
Adjusting the tone balance of your radio
*
[AS10379( GV)03/96]
q
Increasing or decreasing bass and treble
response
*
[AS10380( GV)03/96]
Push the ªBASS/TREBº popout knob to gain
access to the bass and treble controls. Bass
control allows you to adjust the lower, bass
frequencies to your preference. The outer ring
of the ªBASS/TREBº knob adjusts the bass
(turn clockwise to increase bass;
counterclockwise to decrease bass).
*
[AS10381( GV)03/96]
Treble control allows you to adjust the
higher, treble frequencies of your radio to
your preference. The inner ring of the
ªBASS/TREBº knob adjusts the treble (turn
clockwise to increase treble; counterclockwise
to decrease treble).
File:04rcasv.ex
Update:Mon Sep 23 14:37:45 1996
Page 53 of 310
51
*
[AS10382( GV)03/96]
q
Adjusting speaker balance and speaker fader
*
[AS10383( GV)03/96]
Push the ªBAL/FADEº popout knob to gain
access to the speaker balance and fader
controls. Balance control allows you to adjust
the sound distribution between the right and
left speakers. The outer ring of ªBAL/FADEº
knob adjusts the speaker balance control.
(Turn clockwise to shift the sound to the
right speakers, and turn counterclockwise to
shift the sound to the left speakers.)
*
[AS10384( GV)03/96]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. The inner ring of the ªBAL/FADEº
knob adjusts the speaker fader. (Turn
clockwise to shift the sound to the rear
speakers, and turn counterclockwise to shift
the sound to the front speakers.)
*
[AS10385( V)03/96]
Using the Digital Signal Processing (DSP)
Feature
[AS10386( V)03/96]
Push the ªDSPº button to activate the feature.
The display will indicate which signal mode is
in effect. To change the signal mode press either
the left
bor right
aside of the selector button
(located under the ªDSPº button).
*
[AS10387( V)03/96]
The following signal modes may be selected:
*
[AS10388( V)03/96]
1. ªHALLº Ð Rectangular concert hall capacity
of about 2,000.
*
[AS10389( V)03/96]
2. ªCHURCHº Ð Church with a high vault.
*
[AS10390( V)03/96]
3. ªJAZZº Ð Jazz club with clearly reflected
sounds.
*
[AS10391( V)03/96]
4. ªSTADIUMº Ð Outdoor stadium with a
capacity of about 30,000.
*
[AS10392( V)03/96]
5. ªNEWSº Ð ªVoice-onlyº type of sound with
a limited audio band.
File:04rcasv.ex
Update:Mon Sep 23 14:37:45 1996
Page 72 of 310
71
Controls and Features
%*
[CF00200( ALL)01/96]
The main controls for the climate control system,
clock, and radio are on the instrument panel.
%*
[CF00300( ALL)03/96]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
*
[CF00400( ALL)03/96]
Your vehicle has a variety of features designed
for your comfort, convenience and safety. Read
this chapter to find out about standard and
optional features.
%
*
[CF00500( ALL)03/96]
The Climate Control Systems
[CF00600( ALL)12/95]
Your vehicle has one of two different climate
control systems. The two systems are:
[CF00900( BCGV)12/95]
q
a manual heating and air conditioning system
[CF01100( GV)12/95]
q
an electronic automatic temperature control
system
*
[CF01200( ALL)12/95]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
% [CF03500( BCGV)12/95]
The Manual Heating and Air Conditioning
System
[CF03600( BCGV)04/96]
You can heat the inside of your vehicle, defrost
the windshield, and turn on the air conditioning
with the three controls in the center of the
instrument panel:
[CF03700( BCGV)12/95]
q
FAN
[CF03800( BCGV)12/95]
q
TEMP
[CF03900( BCGV)12/95]
q
SELECT
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997
Page 73 of 310
72 [CF04000( GV)12/95]
one third page art:0010621-EThe controls for the manual heating and air conditioning
system
[CF04200( GV)12/95]
For maximum heating, move the SELECT knob
to FLOOR, move the TEMP knob to the end of
the red range (full clockwise) and move the fan
speed to HI.
% [CF04400( GV)12/95]
To heat the interior of your vehicle and defrost
the windshield at the same time, move the
SELECT knob to MIX and select the temperature
and fan speed desired.
[CF04600( GV)12/95]
For maximum defrosting, move the SELECT
knob to DEFROSTV, move the temperature to
the end of the red range (full clockwise) and
operate the fan as necessary to provide the
volume of air required.
% [CF04800( GV)12/95]
For ventilation, move the SELECT knob to VENT
and select the temperature and blower speed
desired.
[CF05000( GV)12/95]
To cool the inside of your vehicle quickly, in
warm weather, move the SELECT knob to MAX
A/C, move the TEMP knob to the end of the
blue range (full counterclockwise) and move the
fan to HI.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997
Page 74 of 310
73 [CF05200( GV)12/95]
If the inside of the vehicle is very warm, drive
for the first few minutes with the windows open
to force the hot, stale air out of the vehicle.
[CF05400( GV)12/95]
Fan speed can be reduced, after a comfortable
temperature has been reached, to provide quieter
system operation.
[CF05600( GV)12/95]
To cool your vehicle using outside air, move the
SELECT knob to NORM A/C, move the TEMP
knob to the end of the blue range (full
counterclockwise) and set the fan to the desired
speed. Cooling your vehicle in this way provides
quieter operation, but it is not as economical as
MAX A/C.
[CF05800( GV)12/95]
The instrument panel registers may be adjusted
to control the quantity and direction of air being
discharged. The thumbwheel controls the volume
of air and the knob in the center of the register
directs the air up and down or side to side.
[CF06000( GV)12/95]
When the SELECT knob is moved to OFF, the
system is off and the fan will not operate.
% [CF06100( BCGV)12/95]
Adjusting the panel register airflow
[CF06200( BCGV)04/96]
The instrument panel registers may be adjusted
to your comfort needs. The thumbwheel controls
the volume of air and the control in the center
of the register controls direction up or down or
side to side.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997
Page 85 of 310
84
*
[CF13500( GV)12/95]
NOTE: The outside temperature reading is
most accurate when the vehicle is
moving. Higher readings may be
obtained when the vehicle is not
moving. The readings that you get may
not agree with temperatures given on
the radio due to differences in vehicle
and station locations.
*
[CF13600( GV)01/96]
Operating tips
*
[CF13700( GV)01/96]
The following tips will help you to get the most
satisfaction from your Electronic Automatic
Temperature Control system.
*
[CF13800( GV)01/96]
q
In humid weather, select DEFVbefore
starting your engine. This will help to
prevent windshield fogging. After a few
minutes of operation, switch to AUTOMATIC
or an override selection of your choice.
*
[CF13900( GV)01/96]
q
To prevent humidity buildup inside your
vehicle, always drive with the EATC System
turned on.
*
[CF14000( GV)01/96]
q
Do not put objects under the front seats that
interfere with the flow of air to the back seat
area.
*
[CF14100( GV)12/95]
q
Remove any snow, ice, or leaves from the air
intake area of your EATC System which
could block the air intake. The intake area is
located at the bottom of the windshield,
under the hood at the passenger side rear
corner.
*
[CF14200( GV)01/96]
Service
*
[CF14300( GV)01/96]
If your EATC is not operating as described here,
take it to your dealer to have it checked. System
diagnostics are built in which will allow your
dealer to readily identify problems that might
occur.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997
